Ultra Thin Track Lighting 48 Volt Magnetic WHITE ► available october 2024 GOLD ► selection available november 2024 Update 1 September 2024
2 Magnetic tracks, only 19mm wide Compact lampadapter 15.5mm
3 ULTRA THIN TRACK LIGHTING ULTRA THIN TRACK LIGHTING Innovative Ultra Thin Track Lighting Enjoy the new design concept of pure minimalism and ultra-thin tracks by Maxx15. The fine appearance hides a precise internal structure, using exquisite innovative technology, with simple installation steps and great interior effect, making each space more elegant with Maxx15. Main Features • Ultra Thin Tracks • 48V Low voltage for safety • Light outpout High CRI>90 • Magnetic System • Easy Installation • Exquisite Design Lighting for the future, long lasting, energy efficient. Magnetic
4
5 ULTRA THIN TRACK LIGHTING ULTRA THIN MAGNETIC LIGHTING TRACK SYSTEM
6
7 ULTRA THIN TRACK LIGHTING Three types ‘Maxx-Track’: Surface Recessed for drywall Recessed for trimless plaster The height of only 13.5mm slim mini magnet track rail, has the abundant installation can be integrated into the wall or ceiling, each equipped with horizontal or vertical corner connectors to meet the requirements of modelling and interior design.
8 Track Standard Lenghts
9 ULTRA THIN TRACK LIGHTING Surface mounting Recessed mounting / Drywall & Plaster SURFACE MOUNT RECESSED PLASTER RECESSED DRYWALL
10 Controlling & Dimming A B D C D F B E
11 ULTRA THIN TRACK LIGHTING A B C D MT15-SSS Surface Mount Black CN15-SSSHO Horizontal Angle Of Surface Mount Black AS15-JT04 Horizontal Angle Energized connector Black AS15-JT03 Flexible Energized connector Black CN15-SSSIN Inner corner Of Surface Mount Black E B F D MT15-SPS Pre-buried Mount Black CN15-SPSHO Horizontal Corner Of Pre-buried Track Black CN15-SPSIN Inner Corner Of Pre-buried Track Black AS15-JT04 Horizontal Angle Energized connector Black AS15-JT03 Flexible Energized connector Black B D E F MT15-STS Recessed Mount Black AS15-JT04 Horizontal Angle Energized connector Black AS15-JT03 Flexible Energized connector Black CN15-SPSHO Horizontal Corner Of recessed track Black CN15-SPSIN Inner Corner Of recessed track Black The Splicing Method Recessed Track Is The Same As Pre-buried Track，when Splicing， The Corresponding Accessories Can Be Steated According To Their Marks. 11
12
13 ULTRA THIN TRACK LIGHTING Colour choices White Black Gold Champagne (2025) Choose between 3 standard housing colours: white, and gold. Other colours are available on request, and depending on quantities.
14
15 ULTRA THIN TRACK LIGHTING Ultra Mini Magnet Track System Lamp Modules
16 Luminaires / Lights Magnetic Track System Wall lights Suspension lamps On track lights Minispots Twin spots Vouwbare armaturen Grille lights - narrow beam Floodlights - wide beam
17 ULTRA THIN TRACK LIGHTING
18 Spotlight 3W SP22 Ø22mm 36° 268 Lumen Spotlight 5W SP32 Ø32mm 36° 473 Lumen Spotlight 7W SP40 Ø40mm 36° 684 Lumen Spotlight 7W SP75 Ø75mm 684 Lumen MT503213-BL BLACK MT503213-WH WHITE MT505213-BL BLACK MT505213-WH WHITE MT507013-BL BLACK MT507013-WH WHITE MT509010-BL BLACK MT509010-WH WHITE SPOT LIGHTING SINGLE
19 ULTRA THIN TRACK LIGHTING SPOT LIGHTING TWIN Spotlight 2 x 3W DS22 Ø22mm 36° 2 x 268 Lumen Spotlight 2 x 5W SP32 Ø32mm 36° 2 x 473 Lumen MT504227-BL BLACK MT504227-WH WHITE MT506227-BL BLACK MT506227-WH WHITE
20 Flood Light 6W FL30 30cm 110° 160 Lumen Flood Light 12W FL60 60cm 110° 320 Lumen Low Glare Grille Light 6W CG06 30cm 36° 300 Lumen Low Glare Grille Light 12W CG12 60cm 36° 600 Lumen MT522113-BL BLACK MT522113-WH WHITE MT522214-BL BLACK MT522214-WH WHITE MT532143-BL BLACK MT532143-WH WHITE MT532154-BL BLACK MT532154-WH WHITE LINEAR LIGHTING Grille Light 6W GL06 30cm 36° 480 Lumen Grille Light 12W GL12 60cm 36° 960 Lumen MT532114-BL BLACK MT532114-WH WHITE MT522123-BL BLACK MT522123-WH WHITE
21 ULTRA THIN TRACK LIGHTING Foldable Grille Light 8W AG08 110mm 40° 398 Lumen Foldable Grille Light 16W AG16 220mm 40° 812 Lumen Compact Grille Light 8W GO 08 110mm 40° 398 Lumen Grille Light Compact 16W GO 16 220mm 40° 812 Lumen LINEAR LIGHTING MT548205-BL BLACK MT548205-WH WHITE MT548309-BL BLACK MT548309-WH WHITE MT548106-BL BLACK MT548106-WH WHITE MT548112-BL BLACK MT548112-WH WHITE
22 ULTRA THIN TRACK LIGHTING Suspension Lamp WHITE GLASS 5W SU01 684 Lumen Suspension Lamp CONE 8W SU04 36° 398 Lumen Suspension Lamp Black Aluminium GLOBE BLACK 6W SU03 Ø72mm Light beam 24° & 40° 352 Lumen MT552110-BL BLACK MT552122-WH WHITE MT552135-GL GOLD MT553220-BL BLACK 24° MT553222-BL BLACK 40° MT554114-BL BLACK Suspension Lamp INNER GLASS 3W LGS80 Ø80mm 240 Lumen MT551114-BL BLACK MT551114-WH WHITE Suspension Lamps
23 ULTRA THIN TRACK LIGHTING Circular Atmosphere Light ROUND RL01 350 Lumen Square Atmosphere Light SQUARE RL02 350 Lumen Tracklamp INNER GLASS TRACK LGS80 Ø80mm 240 Lumen Wall Lighting MT561100-BL BLACK MT561100-WH WHITE MT562310-BL BLACK MT562310-WH WHITE MT562410-BL BLACK MT562410-WH WHITE
24 Features Soft Light Optical Diffuser Strong Magnetic Click-in Advanced Optical System Anti-Glare Optical System Sdcm>3 Superior Lighting
25 ULTRA THIN TRACK LIGHTING Crystal Diamond Appearance, pure and transparent improve light efficiency Advanced Optical System Stainless Steel Damping Shaft Opal Glass Lamp Shade Soft Glazed Glas Cover
26
27 ULTRA THIN TRACK LIGHTING
28
29 ULTRA THIN TRACK LIGHTING M15-SU03 GLOBE BLACK Product Codes MT553220-BL GLOBE BLACK LINE 6W 3000k 352Lm 24° BLACK MT553222-BL GLOBE BLACK LINE 6W 3000k 352Lm 40° BLACK
30
31 ULTRA THIN TRACK LIGHTING M15-LG GLASS LIGHT Product Codes MT561102-BL GLASS Ø8cm 3W 3000k 240Lm BLACK MT561102-WH GLASS Ø8cm 3W 3000k 240Lm WHITE
32 The RL ATMOSPHERE is a luminaire with a subtle atmosphere, available in square and round versions. This wall luminaire radiates warmth and softness with a light colour temperature of 3000K thanks to the reflection technique. An elegant and discreet eye-catcher for any room. It can be personalised in different finishes and colours.
33 ULTRA THIN TRACK LIGHTING M15-RL01 & M15-RL02 ATMOSPHERE Product Codes MT562310-BL ROUND ‘ATMOR’ Ø21cm 5W 3000k 350Lm BLACK MT562410-BL SQUARE ‘ATMOS’ 21.6x21.6cm 5W 3000k 350Lm BLACK
34 PERFECT CONNECTION BETWEEN THE TWO LAMP BODI ES FL30 & FL60 Product Codes MT522113 30cm 6W 160Lm MT522214 60cm 12W 320Lm
35 ULTRA THIN TRACK LIGHTING MODEL POWER VOLTAGE CCT BEAM LIGHT OUTPUT HOUSING COLOUR CONTROL FL30 FL60 6 WAT T 12 WAT T 24VDC | 48VDC 3000k 110° 160 Lm 320 Lm BLACK ON/OFF
36
37 LINEAR LIGHTING DESIGN STRA IGHT L INES
38 M15-GL06 & M15-GL12 Product Codes MT532114 30cm 6W 483Lm MT532123 60cm 12W 966Lm
39 ULTRA THIN TRACK LIGHTING MODEL POWER VOLTAGE CCT BEAM LIGHT OUTPUT HOUSING COLOUR CONTROL M15-GL06 M15-GL12 6 WAT T 12 WAT T 24VDC | 48VDC 3000k 36° 45° 483 Lm 966 Lm BLACK ON/OFF
40
41 ULTRA THIN TRACK LIGHTING
42 M15-CG Anti Glare Grille Light Product Codes MT532143 30cm 6W 408Lm 36° MT532154 60cm 12W 821Lm 36°
43 ULTRA THIN TRACK LIGHTING MODEL POWER VOLTAGE CCT BEAM LIGHT OUTPUT HOUSING COLOUR CONTROL M15-CG06 M15-CG12 6 WAT T 12 WAT T 24VDC | 48VDC 3000k 36° 45° 408 Lm 821 Lm BLACK ON/OFF
44 LINEAR DESIGN
45 ULTRA THIN TRACK LIGHTING R LIGHTING N STRA IGHT L IGHT ING L INES RECESSED MOUNT ING
46 ULTRA THIN TRACK LIGHTING M15-GO Linear Grille Light Product Codes MT548106 30cm 8W 648Lm MT548112 60cm 16W 1232Lm on request
47 ULTRA THIN TRACK LIGHTING MODEL POWER VOLTAGE CCT BEAM LIGHT OUTPUT HOUSING COLOUR CONTROL M15-GO08 M15-GO16 12 WAT T 16 WAT T 24VDC | 48VDC 3000k 24° 40° 648 Lm 1232 Lm BLACK ON/OFF
48 Integrated Grille Diffuser The pursuit of perfection leaving no flaws Golden Ration Grid Distribution. Unique combination of 8 Lights & 16 Lights.
49 ULTRA THIN TRACK LIGHTING
50 M15-AG Adjustable Grille Light Product Codes MT548205 12cm 8W 648Lm MT548309 60cm 16W 1232Lm BL = Black / Zwart WH = White / Wit
51 ULTRA THIN TRACK LIGHTING MODEL POWER VOLTAGE CCT BEAM LIGHT OUTPUT HOUSING COLOUR CONTROL M15-AG08 M15-AG16 8 WAT T 16 WAT T 24VDC | 48VDC 3000k 24° 648 Lm 1232 Lm BLACK ON/OFF
52
53 ULTRA THIN TRACK LIGHTING
54 M15-SP Spotlights Product Codes MT503213 3W 268Lm 36° MT505213 5W 473Lm 36° MT507013 7W 684Lm 36°
55 ULTRA THIN TRACK LIGHTING MODEL POWER VOLTAGE CCT BEAM LIGHT OUTPUT HOUSING COLOUR CONTROL M15-SP20 M15-SP30/32 3 WAT T 7 WAT T 24VDC | 48VDC 3000k 36° 268 Lm BLACK WHI TE ON/OFF 5 WAT T M15-SP07 473 Lm 684 Lm
56 MODEL POWER VOLTAGE CCT BEAM LIGHT OUTPUT HOUSING COLOUR CONTROL M15-SP75 7 WAT T 48VDC 3000k 36° BLACK WHI TE ON /OFF 684 Lm M15-SP is a series of spotlights of a new and innovative 48V system, available in different diameters: 20mm, 30mm, 40mm. Housing in extruded aluminium, powder coated in black or white by Akzo Nobel, specially designed for bright and soft light beam patterns. Available with two different optics: 24° for spot, 40° for flood, for accent and general lighting to enhance interiors and architectural elements. There are also different control options, meaning it is compatible with most control systems including DALI, 0-10V, Triac, Zigbee, Bluetooth/Casambi etc.
57 ULTRA THIN TRACK LIGHTING Horizontal position adjustable with 355 degrees rotation. Vertically adjustable from 0° to 90°.
58
59 ULTRA THIN TRACK LIGHTING M15-SU04 CONE Suspension Lamp Product Code MT552109 Cone Suspension Lamp 8W 2700k 36° 398Lm BLACK MT552110 Cone Suspension Lamp 8W 3000k 36° 398Lm BLACK MT552121 Cone Suspension Lamp 8W 2700k 36° 398Lm WHITE MT552122 Cone Suspension Lamp 8W 3000k 36° 398Lm WHITE MT552133 Cone Suspension Lamp 8W 2700k 36° 398Lm GOLD MT552135 Cone Suspension Lamp 8W 3000k 36° 398Lm GOLD MT552142 Cone Suspension Lamp 8W 2700k 36° 398Lm SILVER MT552144 Cone Suspension Lamp 8W 3000k 36° 398Lm SILVER NEW DESIGN 2024 Control ON/OFF | PHASE | 0-10V | DALI
60 ULTRA THIN TRACK LIGHTING
61 ULTRA THIN TRACK LIGHTING CONE Suspension Lighting 48V 8 Watt 400 Lumen BEAM 36° Warmwhite 3000k
62 DC48V Control Smartwatch Mobile I Pad Infrared Sensing Scene Panel Control Radar Sensors Power Supply Brown Cable: V+ Blue Cable : VGreen Cable: DIM+ Black Cable: DIMInt www.arcllux.com
63 ULTRA THIN TRACK LIGHTING DIMV+ DIM+ VAC220V TRACK + Connect Power Supply DC+ Connect Power Supply DC- No Connect No Connect telligent Control Wiring Mode 75
64 TEC.DRAWINGS 15 11.5 300 TEC.DRAWINGS 15 11.5 600 TEC.DRAWINGS 15 11.5 900 TEC.DRAWINGS 15 11.5 1200 TEC 11.5 300 TEC 11.5 600 TECHNICAL DRAWINGS & IMAGES LINEAR LIGHTING
65 ULTRA THIN TRACK LIGHTING C.DRAWINGS 15 C.DRAWINGS 15 300 15 11.5 TEC.DRAWINGS 600 15 11.5 TEC.DRAWINGS 11. 1
66 TEC.DRAWINGS 150 50 11.2 φ22 15 TEC.D 150 11.2 15 50 φ22 TEC.DRAWINGS L150 11.2 58 φ32 15 TEC.D L150 15 11.2 58 φ32 TEC.DRAWINGS φ75 26 L150 15 11.2 TEC.DRAWINGS L150 11.2 58 φ42 15 TEC.D L150 15 11.2 58 φ42 TECHNICAL DRAWINGS & IMAGES SPOTS SINGLE & TWIN
67 ULTRA THIN TRACK LIGHTING DRAWINGS 5 DRAWINGS TEC.DRAWINGS φ80 150 11.2 15 DRAWINGS
68 TEC.DRAWINGS TEC.DRAWINGS 110 35 16 35 16 220 435 16 35 1 TECHNICAL DRAWINGS & IMAGES GRILLE / SMALL BEAM 30°
69 ULTRA THIN TRACK LIGHTING TEC.DRAWINGS TEC.DRAWINGS 110 87 16 87 220 16
70 TEC.DRAWINGS 19 15.5 13.5 TEC.DRAWINGS 13.5 15.5 50 19 ∅28 15.5 24.1 TEC.DRAWINGS 50 15.5 19 13.5 TECHNICAL DRAWINGS & IMAGES TRACKS TEC.DRAWINGS 19 15.5 13.5 TEC.DRAWINGS 13.5 15.5 50 19 TEC.DRAWINGS ∅28 15.5 24.1 TEC.DRAWINGS 50 15.5 19 13.5 TRACK CONNECTION AND ACC
71 ULTRA THIN TRACK LIGHTING 76 15 11 16 3 TEC.DRAWINGS TEC.DRAWINGS TEC.DRAWINGS TEC.DRAWINGS TEC.DRAWINGS 94 11 TEC.DRAWINGS 42 42 13.5 19 TEC.DRAWINGS 45 45 Φ28 76 15 11 110 15 11 TEC.DRAWINGS 42 42 13.5 39 TEC.DRAWINGS 60 60 13.5 CESSORIES TEC.DRAWINGS TEC.DRAWINGS TEC.DRAWINGS 88 88 11 15 94 94 11 15 76 15 11 76 76 15 11
72 TECHNICAL DRAWINGS & IMAGES TRACK CORNER CONNECTIONS TEC.DRAWINGS 42 42 13.5 19 TEC.DRAWINGS 45 45 Φ28 TEC.DRAWINGS 42 42 13.5 39 TEC.DRAWINGS 60 60 13.5 Subject to printing errors and technical corrections. This Maxx15 catalogue is regularly updated and expanded. Technical information and specifications may still undergo minor changes.
73 ULTRA THIN TRACK LIGHTING TEC.DRAWINGS 34.5 34.5 19 TEC.DRAWINGS 40 40 19 TEC.DRAWINGS 45 45 Φ28 TEC.DRAWINGS 45 45 Φ28 TEC.DRAWINGS 34.5 34.5 39 TEC.DRAWINGS 40 40 39 TEC.DRAWINGS 40 50 40 TEC.DRAWINGS 50 50 50
74 LOW VOLTAGE 48V RAILSYSTEM Ultra Thin Magnetic Track 48V Magnetic by
