WWW.PROLUMIA.COM L E D L I G H T I N G CATALOGUE
PROLUMIA W H E N L I G H T I N G M A T T E R S WWW.PROLUMIA.COM 3 Prolumia is exclusively distributed by: THE NETHERLANDS (HEAD OFFICE) NEDELKO B.V. Postal address: Nedelko B.V., Riga 10, 2993 LW Barendrecht, The Netherlands Telephone: +31 (0)180 64 54 00 E-mail: info@prolumia.nl Showroom visits (only in The Netherlands) by appointment only. BELGIUM NEDELKO BELGIUM N.V. Postal address: Nedelko Belgium N.V., Prins Boudewijnlaan 49, B-2650 Edegem - Antwerpen, Belgium Telephone: +32 (0)3 826 99 99 E-mail: info@prolumia.be CZECH REPUBLIC NEDELKO S.R.O. Postal address: Nedelko S.R.O., Ke Slivenci 48, 154 00 Praha 5 - Lochkov, Czech Republic Telephone: +420 222 563 003 E-mail: info@prolumia.cz GERMANY NEDELKO GERMANY GMBH Postal address: Nedelko Germany GmbH, Heinz-BäckerStraße 27, 45356 Essen, Germany Telephone: +49 (0)201 560 503 50 E-mail: info@prolumia.de DISCOVER PROLUMIA ONLINE: www.prolumia.com Prices shown are valid from 1 February 2023 and may be subject to changes or contain errors. Nedelko B.V. pays the utmost attention to its catalog and reliability and actuality of the information contained therein. Despite all care, inaccuracies and omissions can not always be prevented. Nedelko B.V. is not liable for errors or inaccuracies. For the most current information please contact our sales department. Prolumia Member Licensing Program for LED Luminaires and Retrofit Bulbs EnabLED
PROLUMIA W H E N L I G H T I N G M A T T E R S WWW.PROLUMIA.COM 5 4 PRODUCT INDEX 60 18 106 PRODISC LED STRIP BRONZE 90 PRO-OFFICE LED DRIVERS 22 110 PRODISC II LED STRIP SILVER 94 98 I-PANEL ECO-PANEL BL LED CONTROLLERS 38 PRO-STRIPE 42 118 120 PRO-SPACE LUMIAFLEX II PRO-RIO TRACKLIGHT ECO LINE LED PROFILES 66 LED 3-PHASE RAIL TOP LINE LED PROFILES 34 ECODISC II 28 114 PRODISC III LED STRIP GOLD 102 PRO-SIGN 56 PRO-RIO SURFACE 46 PRO-CEILING 76 DOWNLIGHT ACCENT 70 DOWNLIGHT GENERAL ALUMINIUM LED PROFILES INTERIOR LIGHTING LINEAR LIGHTING 86 PRO-FUSION 140 122 146 LUMIAFLEX 1004 128 132
PROLUMIA W H E N L I G H T I N G M A T T E R S WWW.PROLUMIA.COM 7 6 PRODISC II IP65 PRO-STRADA PRO-BEAM ROCKDISC II ROCKDISC III PRO-STRADA BASIC PRO-CONE PRO-PORTAL PRO-VISION PRO-FIT PRO-TABELLA PRO-FLOOD PRO-FLOOD BASIC URBAN PRO-AQUA II PRO-AQUA III PRO-LINE RETROFIT II PRO-BAY III OUTDOOR LIGHTING INDUSTRIAL LIGHTING PUBLIC LIGHTING 158 226 188 162 166 222 214 170 228 174 230 184 231 198 204 194 208 180
PROLUMIA W H E N L I G H T I N G M A T T E R S WWW.PROLUMIA.COM 9 8 WHEN L I GHT I NG MAT T ERS LED lighting where quality is key. That’s Prolumia. With five extensive product groups, consisting of line lighting, interior and exterior lighting, industrial lighting and public lighting, we can fulfil practically any lighting requirement. We also pursue long-term customer contact, solid specialist advice for every issue and go the extra mile in providing excellent service. Whatever it is, Prolumia makes no concessions. 5 REASONS FOR CHOOSING PROLUMIA WE BREAK INTO EUROPE WITH AFFORDABLE QUALITY LIGHTING FROM OUR 4 LOCATIONS PRICE-CONSCIOUS Prolumia offers the best and most competitive price-quality ratio. Which does not mean that safety, sustainability and service are compromised. On the contrary. COMPETENT Our committed employees have specialist knowledge of all products and are happy to share it. COOPERATION Prolumia believes it’s vital to work together to create a better and more sustainable world and, of course, the best result for every project. EFFICIENT Short lines, holding stock and access to a large distribution network. All these are in place to enable us to switch quickly. SUSTAINABILITY The use of our LED products reduces the burden on the environment, as our products are manufactured to the highest sustainable degree and the materials used are easy to recycle. MISSION With great dedication and through a reliable network of trading partners, our aim is to provide the European LED lighting market with cost-effective, sustainable lighting solutions with products and service of the highest standards. The focus is on cost savings, lighting experience for the customer and care for the environment. VISION Prolumia occupies a competitive position in the European LED lighting market. This is achieved by offering a high-quality range of LED luminaires at a fair price, with a focus on housing corporations, public lighting, parking and utility & warehouses. Our lighting specialists are passionate about providing customers with solid advice, proper product and project support and excellent after-sales service. Our ambition is to be able to comply with a circular economy as much as possible in the future. Together with our price-conscious customers, we aspire a more sustainable society... this is how we make a difference.
PROLUMIA W H E N L I G H T I N G M A T T E R S WWW.PROLUMIA.COM 11 10 STRONG IN 4 CORE SEGMENTS Every location needs to be properly lit. However, every room is different and therefore has different lighting requirements, such as appropriate lighting for a car park or an office space for example. The segments, which consist of residential construction, public lighting, parking and utility and warehouses, each have specific lighting needs and requirements. HOUSING Houses, apartment buildings and similar environments benefit from proper lighting. Having said that, each area of a residential building has a different lighting requirement. For example, the interior of a home needs different lighting than a public area. While interior lighting must primarily provide comfort, lighting of the public areas of residential buildings must be both comfortable and safe. This way everyone can find his or her way around untroubled and without having to grope around in the dark. Whether standard lighting is required or lighting with unique, smart sensor technologies for saving energy, such as daylight sensors, dimmers, twilight switches and more... Prolumia's innovative lighting fixtures offer the right solution for every space. PUBLIC LIGHTING Proper lighting on public roads is essential. It contributes to road safety and comfort. As our road network is quite complex, each public area requires a different type of lighting. At one location, people must be able to cross the road safely, whereas elsewhere, the traffic must flow properly. Prolumia's public LED lighting package is available in various versions, which helps to find a suitable luminaire for every application. This includes smart lighting where, for example, the lighting level can be adjusted as required, allowing considerable energy savings to be made. Also luminaires with a Zhaga socket are available, which set you up for the future. PARKING Proper lighting in car parks or parking spaces is essential. Parking lots often have dark areas or shadows that are difficult to light. This involves a great deal of risk. For example, pedestrians may be overlooked, accidents may occur when parking, or important signage may not be clearly visible. Prolumia offers a wide range of LED lighting for parking areas, ensuring visibility, user experience and safety. UTILITY AND WAREHOUSES Non-residential buildings include offices, schools, banks, town halls and care centres. The people present at such locations are generally in the same place for long periods of time. If the lighting is not right, this can cause fatigue, loss of concentration and ultimately to absenteeism. Proper lighting is therefore essential for optimum performance. Good lighting in warehouses and storerooms is another essential aspect. These areas often consist of long lanes with high racking, which can quickly create dark spots and shadows. In addition to a solid lighting plan, the right LED lighting is required in order to illuminate each area properly. This enables people to work productively and also creates a safe working environment. WE FULFIL ALL YOUR LIGHTING REQUIREMENTS
PROLUMIA W H E N L I G H T I N G M A T T E R S WWW.PROLUMIA.COM 12 13 FROM STRONG ADVICE... With passion, we work every day to find great solutions for our customers and the best options for our prospects. Our team's besteffort mentality ensures that we don’t settle for mediocrity or just being adequate... Together we go for the best result. Not only on product level, but also on service level. PROJECT MANAGEMENT From specialist advice to performing the request and to completion. Prolumia leads you all the way. The team of certified lighting specialists has years of experience in converting extensive LED issues into cost-effective sustainable lighting solutions. We will be happy to provide you with personal advice on completing your project. Our specialists supervise the entire process in accordance with your wishes. In this way, we ensure a perfect end result together. No matter what request you may have... Prolumia is your link and ensures that you can complete your project within the agreed timeframe. AFTER-SALES SERVICE We will also be at your service after the purchase and installation of your Prolumia product. We highly value good customer contact. Do you need technical support or advice, are you looking for more information or do you have a general question? Our specialists will assist you in any way. LIGHT CALCULATIONS Good advice, product information and product support are not the only valuable benefits we provide at Prolumia. We also offer a number of extra services to provide customers with the best possible assistance. One of these services is making light calculations using the Relux simulation programme. Through this programme, our lighting specialists ensure that spaces are fitted with the best possible lighting. Are you also looking for a lighting plan? Let us help you. Based on your descriptions, drawings and the work carried out in the space in question, our lighting specialists can draw up a suitable lighting plan in advance. Since we combine your wishes, ideas and space into a thorough plan, we can tailor your future lighting perfectly to your wishes. ...TO SOLID AFTER-SALES SERVICE
PROLUMIA W H E N L I G H T I N G M A T T E R S WWW.PROLUMIA.COM 14 15 MEASUREMENT IS THE KEY We have the expertise to test, measure and check the quality of our products ourselves. We have various test facilities for this, using high-quality equipment. LABSPHERE As a supplier of professional LED lighting, we have invested in an Integrating Sphere from Labsphere with a diameter of 3 metres, which enables us to (re)measure technical lighting data of luminaires. We are proud to be one of the few suppliers in the Netherlands with a Sphere of this size. This format enables us to measure not only smaller luminaires, but also large luminaires such as public lighting. PHOTOGONIOMETER Besides the Integrating Sphere from Labsphere, we also own a so-called photogoniometer from Radiant Vision Systems. This meter is used to test, record and quantify the exact photometric, radiometric and colorimetric characteristics of our LED lighting in-house. ENSURING QUALITY Affordable products and good quality service are paramount in virtually everything we do. Whether it's our high-quality products that last longer, our long-term customer contact in which clarity is crucial, or the extra measurement of the specifications of our luminaires... Prolumia makes no concessions. WHAT IS ACTUALLY MEASURED? The Integrating Sphere from Labsphere is a complete measuring platform for our LED luminaires. The sphere has a highly reflective coating on the inside so that all the light emitted by the light source is actually measured. This enables us to accurately measure essential technical lighting values such as luminous flux, light color, color rendering and spectral distribution. We can also accurately determine or check the specific luminous flux (lumen/watt) with the aid of a power meter. This enables us to support the technical lighting performance of our luminaires with measurements and in that way ensure the quality of our luminaires. WE USE THE INTEGRATING SPHERE FROM LABSPHERE TO ACCURATELY MEASURE THE TECHNICAL LIGHTING PERFORMANCE OF OUR LUMINAIRES BUT HOW DO WE DO IT EXACTLY? TO KNOWLEDGE
PROLUMIA W H E N L I G H T I N G M A T T E R S WWW.PROLUMIA.COM 17 16 SERIES Prodisc Series Prodisc II Series Prodisc III Series Ecodisc II Series Pro-Stripe Series Pro-Space Series Pro-Ceiling Series Pro-Rio Surface Series Pro-Rio Tracklight Series LED 3-Phase Rail Series Downlight General Series Downlight Accent Series Pro-Fusion Series Pro-Office Series I-Panel Series Eco-Panel BL Series Pro-Sign Series ATTRACTIVE TO THE SMALLEST DETAIL INNOVATIVE LIGHTING SOLUTIONS FOR SHOPS AND OFFICES, MORE THAN JUST LIGHT! IT LEADS PEOPLE THE WAY, CREATES A PLEASANT (WORKING) ENVIRONMENT AND DRAWS ATTENTION TO POINTS WHICH SHOULD BE EMPHASIZED MORE. THINK OF A STORE PRESENTATION, SALES DESK OR CONFERENCE TABLE. WHETHER FOR GENERAL LIGHTING OR CREATING FASCINATING ACCENT LIGHTING, PROLUMIA LED INTERIOR LIGHTING OFFERS APPROPRIATE LIGHTING SOLUTIONS FOR EVERY SPACE. INTERIOR LIGHTING
PROLUMIA W H E N L I G H T I N G M A T T E R S WWW.PROLUMIA.COM 18 19 100mm ø348mm 80mm ø280mm SPECIFICATIONS APPLICATIONS HALLWAYS, STAIRCASES, TOILETS, ETC. PRODISC SERIES Light source: SMD LED Beam angle: 115° Color temperature: 3000K or 4000K (Prodisc Mini) 3000K/4000K switchable (Prodisc) Color rendering index: Ra > 80 Operating temperature: -20°C – +50°C Rated life hours: L80B50 > 100,000 / L90B50 > 50,000 LED driver (included): CE Supply voltage: 220-240V AC 50/60Hz / 220-230V AC 50/60Hz | 220V DC (only standard version) Electrical safety class: Class II Power factor: 0.90 The LED Prodisc luminaire provides high energy savings (> 70%) through intelligent lighting management with presence detectors. Safety is the prime consideration in stairwells and hallways. They must be properly illuminated with enough brightness without reflections to ensure safe passage. The LED Prodisc is highly suitable for this. SURFACE MOUNTED AND SEMI-RECESSED LUMINAIRE POLYCARBONATE HOUSING, OPAL PMMA DIFFUSER FIXTURES WITH ANDWITHOUT SENSOR CAN BE COMBINED AS MASTER/SLAVE (WIRED) INCL. MOUNTING BRACKET FOR SEMI-RECESSED MOUNTING (WITH THE EXCEPTION OF PRODISC MINI) OPTIONALLY AVAILABLE WITH BUILD IN INVISIBLE MICROWAVE/DAYLIGHT SENSORWITH ADJUSTABLE DETECTION RANGE, TIME AND LIGHT LEVEL PRODISC MINI Art. no. Description Price Prodisc Mini, surface mounted, ø280x80mm, IP20 40009350 Standard, 10W, 3000K, 1020Lm € 66 40009356 Standard, 10W, 4000K, 1100Lm € 66 40009360 + MW sensor, 11W, 3000K, 1020Lm € 102.50 40009366 + MW sensor, 11W, 4000K, 1100Lm € 102.50 10W 3000K or 4000K Standard / MW sensor DIFFERENT VERSIONS AVAILABLE: STANDARD / MICROWAVE SENSOR / EMERGENCY MODE / EMERGENCY MODE + MICROWAVE SENSOR PRODISC Art. no. Description Price Prodisc, surface mounted, ø348x100mm, IP44, 3000K/4000K 40009302 Standard, 12W, 1300Lm € 104 40009312 + MW sensor, 13W, 1300Lm € 145 40009322 + Emergency mode, 13W, 1300Lm (Emergency mode: 280Lm) € 138.50 40009332 + Emergency mode + MW sensor, 14W, 1300Lm (Emergency mode: 280Lm) € 179.50 12W Switchable color temperature Standard / MW sensor / Emergency mode / Emergency mode + MW sensor 100 200 300 90° 90° 180° 0° 30° 30° 150° 150° 60° 120° 60° 120° cd / 1000 lm C0 / C180 C90 / C270 Prodisc 50 100 150 200 250 90° 90° 180° 0° 30° 30° 150° 150° 60° 120° 60° 120° cd / 1000 lm C0 / C180 C90 / C270 Prodisc Mini LIGHT DISTRIBUTION LIGHT DISTRIBUTION DIMENSION DRAWING DIMENSION DRAWING HOUSING UTILITY CONVENIENT MASTER/SLAVE FUNCTION MORE INFO ABOUT PRODISC ONLINE: FROM € 66 Recommended retail price excl. VAT FROM € 104 Recommended retail price excl. VAT EASY TO ASSEMBLE SURFACE MOUNTED AND SEMI-RECESSED LUMINAIRE PRODISC
PROLUMIA W H E N L I G H T I N G M A T T E R S WWW.PROLUMIA.COM 20 21 313mm 50mm Metal bracket Recessed Surface mounted 100% 100% 100% 100% 100% 100% 0% / 100%, independent of daylight 0% / 100%, dependent on daylight A B 1 1 2 2 3 3 Off --> after motion detection 100% during delay time --> then off Off when there is enough ambient light --> in the evening/night after motion detection 100% during hold time --> then off 100% upon detection, during hold time. Off when there is sufficient daylight, also after detection. 100% upon detection, during hold time. 100% during hold time, in case of detection and insufficient daylight. Off after expiry of hold time. Off after expiry of hold time. 20% 20% 20% 20% 100% 100% 20% 20% 20% / 100% C 1 2 3 4 Always on at dimmed level --> after detection 100% during hold time (Please note! L and L1 must be swapped on the driver) Daytime: on at dimmed level. In the evening/at night: on at dimmed level. 100% upon detection, during hold time. In the evening/at night: on at dimmed level. PRODISC SERIES PRODISC SERIES MOUNTING OPTIONS PRODISC MICROWAVE MOTION SENSOR PRODISC Specifications: Detection range ceiling mounting: (at 100% sensitivity 3m mounting height and 0.3m/s speed) 8m Detection range wall mounting: (at 100% sensitivity 2m mounting height and 0.3m/s speed) 7m Maximum mounting height: 6m Sensitivity adjustment range: 10% - 25% - 50% - 75% - 100% Hold time: 10 - 30 - 90 sec.; 6 - 20 - 30 min. Daylight level: 5 - 10 - 30 - 50 lux - off Examples of sensor settings: HOUSING UTILITY MORE INFO ABOUT PRODISC ONLINE: MORE INFO ABOUT PRODISC ONLINE:
PROLUMIA W H E N L I G H T I N G M A T T E R S WWW.PROLUMIA.COM 22 23 85mm ø260mm 50 100 150 200 250 90° 90° 180° 0° 30° 30° 150° 150° 60° 120° 60° 120° cd / 1000 lm C0 / C180 C90 / C270 Prodisc II Mini PRODISC II SERIES PRODISC II PRODISC II MINI Art. no. Description Price Prodisc II Mini, surface mounted, ø260x85mm, 3000K/4000K, 900Lm/450Lm 40009441 Standard, 9W € 66 40009451 + MW sensor, 10W € 102.50 9W Switchable color temperature: 3000K/4000K Standard / MW sensor LIGHT DISTRIBUTION DIMENSION DRAWING Energy efficient, bright illumination for safe passage of stairwells and corridors. Optionally available with emergency function and a new microwave sensor: 3-phase dim scenario and/or a daylight on/off switch. The detection range and the daylight sensitivity after burning time are adjustable. In addition, fixtures with and without sensor can be combined as master/slave. POLYCARBONATE HOUSING AND OPAL LENS 3-STEP DIMMING OPTION (100% → 20% → 0%) DAYLIGHT PRIORITY (ON/OFF BASED UPON DAYLIGHT) SWITCHABLE COLOR TEMPERATURE AND LIGHT OUTPUT FIXTURES WITH ANDWITHOUT SENSOR CAN BE COMBINED AS MASTER/SLAVE (WIRED) DIFFERENT VERSIONS AVAILABLE: STANDARD / MICROWAVE SENSOR / EMERGENCY MODE / EMERGENCY MODE + MICROWAVE SENSOR INCREASE SAFETY WITH THIS VERSATILE LUMINAIRE Light source: SMD 2835 LED Beam angle: 120° Color temperature: Switchable 3000K/4000K Light output: Switchable Operating temperature: -20°C – +50°C Rated life hours: L80B50 > 100,000 / L90B50 > 50,000 LED driver (included): CE Supply voltage: 220-240V AC 50/60Hz / 220-230V AC 50/60Hz | 220V DC (only standard version) Electrical safety class: Class II Power factor: > 0.90 APPLICATIONS HALLWAYS, STAIRCASES, TOILETS, ETC. SPECIFICATIONS HOUSING UTILITY FROM € 66 Recommended retail price excl. VAT MORE INFO ABOUT PRODISC II ONLINE: 3-STEP DIMMING DAYLIGHT PRIORITY
PROLUMIA W H E N L I G H T I N G M A T T E R S WWW.PROLUMIA.COM 24 25 107mm ø400mm 100mm ø340mm 100 200 300 90° 90° 180° 0° 30° 30° 150° 150° 60° 120° 60° 120° cd / 1000 lm C0 / C180 C90 / C270 Prodisc II Maxi 50 100 150 200 250 90° 90° 180° 0° 30° 30° 150° 150° 60° 120° 60° 120° cd / 1000 lm C0 / C180 C90 / C270 Prodisc II PRODISC II SERIES PRODISC II MAXI Art. no. Description Price Prodisc II Maxi, surface mounted, ø400x107mm, 3000K/4000K, 3000Lm/2000Lm/1500Lm 40009461 Standard, 24W € 168.50 40009471 + MW sensor, 25W € 211.50 40009481 + Emergency mode with auto test, 25.5W (Emergency mode: 300Lm) € 241.50 40009491 + Emergency mode with auto test + MW sensor, 26W (Emergency mode: 300Lm) € 284.50 24W Switchable color temperature: 3000K/4000K Standard / MW sensor / Emergency mode / Emergency mode + MW sensor PRODISC II SERIES PRODISC II Art. no. Description Price Prodisc II, surface mounted, ø340x100mm, 3000K/4000K, 1500Lm/1000Lm/700Lm 40009401 Standard, 14W € 108 40009411 + MW sensor, 15W € 151 40009421 + Emergency mode with auto test, 15.5W (Emergency mode: 300Lm) € 180.50 40009431 + Emergency mode with auto test + MW sensor, 16W (Emergency mode: 300Lm) € 223.50 14W Switchable color temperature: 3000K/4000K Standard / MW sensor / Emergency mode / Emergency mode + MW sensor LIGHT DISTRIBUTION LIGHT DISTRIBUTION DIMENSION DRAWING DIMENSION DRAWING HOUSING UTILITY MORE INFO ABOUT PRODISC II ONLINE: FROM € 168. 50 Recommended retail price excl. VAT FROM € 108 Recommended retail price excl. VAT MORE INFO ABOUT PRODISC II ONLINE:
PROLUMIA W H E N L I G H T I N G M A T T E R S WWW.PROLUMIA.COM 26 27 0% / 100% / 20% / 0%, independent of daylight 0% / 100% / 20% / 0%, dependent on daylight C D Off --> after motion detection 100% during hold time and 20% during standby time --> then off Off when there is sufficient ambient light --> in the evening/night after motion detection 100% during hold time and 20% during standby time --> then off 100% 100% 1 100% upon detection, during hold time. 1 Off when there is sufficient daylight, also after detection. 100% 100% 2 100% upon detection, during hold time. 100% 100% 2 100% during hold time, in case of detection and insufficient daylight. 100% 20% 3 After expiry of hold time to 20% during standby time. 100% 20% 3 After expiry of hold time to 20% during standby time. 4 Off after expiry of standby time. 4 Off after expiry of standby time. 100% 100% 100% 100% 100% 100% 0% / 100%, independent of daylight 0% / 100%, dependent on daylight A B 1 1 2 2 3 3 Off --> after motion detection 100% during delay time --> then off Off when there is enough ambient light --> in the evening/night after motion detection 100% during hold time --> then off 100% upon detection, during hold time. Off when there is sufficient daylight, also after detection. 100% upon detection, during hold time. 100% during hold time, in case of detection and insufficient daylight. Off after expiry of hold time. Off after expiry of hold time. 0% / 20% / 100% / 20% / 0% 1 F On at dimmed level based on daylight and 100% upon detection Off when there is sufficient daylight, also after detection. 20% 20% 2 5 In the evening/at night: on at dimmed level. Off when there is sufficient daylight, also after detection. 100% 100% 20% 20% 3 4 100% upon detection, during hold time. In the evening/at night: on at dimmed level. 20% 20% 20% 20% 100% 100% 20% 20% 20% / 100% E 1 2 3 4 Always on at dimmed level --> after detection 100% during hold time Daytime: on at dimmed level. In the evening/at night: on at dimmed level. 100% upon detection, during hold time. In the evening/at night: on at dimmed level. PRODISC II SERIES PRODISC II SERIES MICROWAVE MOTION SENSOR PRODISC II Specifications: Detection range ceiling mounting: (at 100% sensitivity 3m mounting height and 0.3m/s speed) 10m Detection range wall mounting: (at 100% sensitivity 2m mounting height and 0.3m/s speed) 8m Maximum mounting height: 6m Sensitivity adjustment range: 25% - 50% - 75% - 100% Hold time: 5 - 30 sec.; 1 - 5 - 15 - 30 min. Hold time orientation lighting: off - 10 - 20 - 30 - 60 min. - ∞ Daylight level: 5 - 10 - 15 lux - off Daylight level with daylight priority: 35 - 50 - 75 - 100 - 150 lux - off Light level with orientation lighting: 20% Examples of sensor settings: HOUSING UTILITY MORE INFO ABOUT PRODISC II ONLINE: MORE INFO ABOUT PRODISC II ONLINE:
PROLUMIA W H E N L I G H T I N G M A T T E R S WWW.PROLUMIA.COM 28 29 SPECIFICATIONS PRODISC III MINI PRODISC III SERIES 9W Switchable light output and color temperature Standard / MW sensor Light source: SMD 2835 LED Beam angle: 120° Switchable color temperature: 3000K/4000K Operating temperature: -25°C – +50°C Rated life hours: L80B50 > 100,000 / L90B50 > 50,000 LED driver (included): CE Supply voltage: 220-240V AC 50/60Hz / 220-230V AC 50/60Hz | 220V DC (only standard version) Electrical safety class: Class II Power factor: > 0.90 APPLICATIONS HALLS, GALLERIES, PORCHES, HALLWAYS, STAIRCASES, STORAGES, TOILETS, ETC. Art. no. Description Price Prodisc III Mini, white, surface mounted, ø267x57mm, 3000K/4000K 40009380 Standard, 9W, 970Lm/485Lm € 60 40009381 + MW sensor, 10.5W, 970Lm/485Lm € 93.50 Prodisc III Mini, black, surface mounted, ø267x57mm, 3000K/4000K 40009385 Standard, 9W, 880Lm/440Lm € 60 40009386 + MW sensor, 10.5W, 880Lm/440Lm € 93.50 PRODISC III Art. no. Description Price Prodisc III, white, surface mounted, ø335x63mm, 3000K/4000K 40009370 Standard, 15W, 1700Lm/1190Lm/850Lm € 87 40009371 + MW sensor, 16.5W, 1700Lm/1190Lm/850Lm € 119.50 40009372 + Emergency mode, 16W, 1700Lm/1190Lm/850Lm € 142 40009373 + Emergency mode + MW sensor, 17.5W, 1700Lm/1190Lm/850Lm € 175.50 Prodisc III, black, surface mounted, ø335x63mm, 3000K/4000K 40009375 Standard, 15W, 1500Lm/1050Lm/750Lm € 87 40009376 + MW sensor, 16.5W, 1500Lm/1050Lm/750Lm € 119.50 40009377 + Emergency mode, 16W, 1500Lm/1050Lm/750Lm € 142 40009378 + Emergency mode + MW sensor, 17.5W, 1500Lm/1050Lm/750Lm € 175.50 15W Switchable light output and color temperature Standard / MW sensor / Emergency mode / Emergency mode + MW sensor 57 mm ø267mm 63 mm ø335mm 50 100 150 200 250 90° 90° 180° 0° 30° 30° 150° 150° 60° 120° 60° 120° cd / 1000 lm C0 / C180 C90 / C270 Prodisc III Mini 50 100 150 200 250 90° 90° 180° 0° 30° 30° 150° 150° 60° 120° 60° 120° cd / 1000 lm C0 / C180 C90 / C270 Prodisc III LIGHT DISTRIBUTION LIGHT DISTRIBUTION DIMENSION DRAWING DIMENSION DRAWING DIFFERENT VERSIONS AVAILABLE: STANDARD / MICROWAVE SENSOR / EMERGENCY MODE / EMERGENCY MODE + MICROWAVE SENSOR The Prodisc fixtures from Prolumia are now a household name in the market. The new Prodisc III series has been developed in-house, and has a contemporary design and high efficiency. The extremely strong housing and shield consist of impact-resistant and flame-retardant polycarbonate. In addition, the luminaires are equipped with new lighting technology and a flicker-free driver, optionally with integrated motion sensor. Also available in an emergency version. This makes the competitively priced Prodisc III series very versatile. EFFICIENCY UP TO 110 LM/W 3-STEP DIMMING OPTION (100% → 10%/25% → 0%) DAYLIGHT PRIORITY (ON/OFF BASED UPON DAYLIGHT) SWITCHABLE COLOR TEMPERATURE AND LIGHT OUTPUT STATE-OF-THE-ART LI-FEPO4 BATTERY TECHNOLOGY FIXTURES WITH ANDWITHOUT SENSOR CAN BE COMBINED AS MASTER/SLAVE (WIRED) GREAT TIME SAVINGS DUE TO SIMPLE INSTALLATION AND ELECTRICAL CONNECTION WITHOUT TOOLS HOUSING UTILITY FROM € 60 Recommended retail price excl. VAT FROM € 87 Recommended retail price excl. VAT 3-STEP DIMMING DAYLIGHT PRIORITY PRODISC III
PROLUMIA W H E N L I G H T I N G M A T T E R S WWW.PROLUMIA.COM 31 30 SAFE Integrated emergency functionality: Li-FePO4 battery, 2x longer life span compared to NiCd Low self-discharge and less chance of spontaneous combustion due to improved chemical and thermal stability No heavy metals, 100% recyclable SAFE Robust housing and shielding made of impact-resistant and flame-extinguishing polycarbonate Double insulated (class II, no grounding necessary) ENERGY-SAVING High efficiency: 110 Lm/W EASE Switchable color temperature: 3000K and 4000K TIME-SAVING Tool-less electrical connection EASY ASSEMBLY Fits most standard junction boxes COMFORT Flicker-free driver Switchable light output: 100% - (70%) - 50% ENERGY-SAVING Integrated microwave motion sensor with photocell: 3-step dimming (high → low → off) On/off depending on daylight Master-Slave function Adjustable dim level (10% or 25%) Sensitivity, hold time and daylight level adjustable PRODISC III SERIES PRODISC III SERIES UNPRECEDENTED POSSIBILITIES AND OPTIONAL FUNCTIONS IN ONE LUMINAIRE HOUSING UTILITY MORE INFO ABOUT PRODISC III ONLINE: MORE INFO ABOUT PRODISC III ONLINE:
PROLUMIA W H E N L I G H T I N G M A T T E R S WWW.PROLUMIA.COM 32 33 0% / 100% / 10% or 25% / 0%, independent of daylight 0% / 100% / 10% or 25% / 0%, dependent on daylight C D Off --> after motion detection 100% during hold time and 10%/25% during standby time --> then off Off when there is sufficient ambient light --> in the evening/night after motion detection 100% during hold time and 10%/25% during standby time --> then off 100% 100% 1 100% upon detection, during hold time. 1 Off when there is sufficient daylight, also after detection. 100% 100% 2 100% upon detection, during hold time. 100% 100% 2 100% during hold time, in case of detection and insufficient daylight. 100% 10%/25% 3 After expiry of hold time to 10%/25% during standby time. 100% 10%/25% 3 After expiry of hold time to 10%/25% during standby time. 4 Off after expiry of standby time. 4 Off after expiry of standby time. 100% 100% 100% 100% 100% 100% 0% / 100%, independent of daylight 0% / 100%, dependent on daylight A B 1 1 2 2 3 3 Off --> after motion detection 100% during delay time --> then off Off when there is enough ambient light --> in the evening/night after motion detection 100% during hold time --> then off 100% upon detection, during hold time. Off when there is sufficient daylight, also after detection. 100% upon detection, during hold time. 100% during hold time, in case of detection and insufficient daylight. Off after expiry of hold time. Off after expiry of hold time. 0% / 10% or 25% / 100% / 10% or 25% / 0% 1 F On at dimmed level based on daylight and 100% upon detection Off when there is sufficient daylight, also after detection. 10%/25% 10%/25% 2 5 In the evening/at night: on at dimmed level. 100% 100% 10%/25% 10%/25% 3 4 100% upon detection, during hold time. 10%/25% 10%/25% 10%/25% 10%/25% 100% 100% 10%/25% 10%/25% 10% or 25% / 100% E 1 2 3 4 Always on at dimmed level --> after detection 100% during hold time Daytime: on at dimmed level. In the evening/at night: on at dimmed level. 100% upon detection, during hold time. In the evening/at night: on at dimmed level. Examples of sensor settings: Off when there is sufficient daylight, also after detection. In the evening/at night: on at dimmed level. MICROWAVE MOTION SENSOR PRODISC III PRODISC III SERIES PRODISC III SERIES Specifications: Detection range ceiling mounting: (at 100% sensitivity 3m mounting height and 0.3m/s speed) 6m Detection range wall mounting: (at 100% sensitivity 2m mounting height and 0.3m/s speed) 7m Maximum mounting height: 6m Sensitivity adjustment range: 50% - 100% Hold time: 5 sec.; 1 - 5 - 10 min. Hold time orientation lighting: off - 10 min. - 30 min. - ∞ Daylight level: 5 - 25 - 50 lux - off Daylight level with daylight priority: 5 - 25 - 50 lux - off Light level with orientation lighting: 10% - 25% HOUSING UTILITY MORE INFO ABOUT PRODISC III ONLINE: MORE INFO ABOUT PRODISC III ONLINE:
PROLUMIA W H E N L I G H T I N G M A T T E R S WWW.PROLUMIA.COM 34 35 SPECIFICATIONS 57mm ø265mm 40 80 120 160 200 90° 90° 180° 0° 30° 30° 150° 150° 60° 120° 60° 120° cd / 1000 lm C0 / C180 C90 / C270 Ecodisc II Mini LIGHT DISTRIBUTION DIMENSION DRAWING ECODISC II MINI Ø265 MM ECODISC II SERIES 12W 1100Lm APPLICATIONS HALLS, GALLERIES, PORCHES, HALLWAYS, STAIRCASES, TOILETS, ETC. Art. no. Description Price Ecodisc II Mini, surface mounted, ø265x57mm, 3000K/4000K/6500K, 1100Lm 40009902 Standard, 12W € 28 40009903 + MW sensor, 13.5W € 52 DIFFERENT VERSIONS AVAILABLE: STANDARD / MICROWAVE SENSOR The Ecodisc II is an ideal choice when an inexpensive but functional surface-mounted luminaire is required. The luminaire is made of powder coated steel and fitted with a homogeneously illuminated PMMA cover. The Ecodisc II is equipped with a switchable color temperature, which makes switching effortless between 3000K, 4000K and 6500K. Optionally, a version with built-in Microwave motion sensor is available. This fixture provides good lighting for halls, galleries, porches, corridors, stairwells and toilets. TIMELESS, MINIMALISTICALLY DESIGNED SURFACE LUMINAIRE BASE METAL / COVER PMMA EFFICIENCY UP TO 90 LM/W COLOR TEMPERATURE SWITCHABLE BETWEEN 3000K, 4000K AND 6500K AVAILABLE WITH INTERGRATED MICROWAVE SENSOR AFFORDABLE AND FUNCTIONAL CEILING AND WALL LUMINAIRE WITH SWITCHABLE COLOR TEMPERATURE AND OPTIONAL MW SENSOR ECODISC II Light source: SMD 2835 LED Beam angle: 120° Switchable color temperature: 3000K/4000K/6500K Operating temperature: -20°C – +40°C Rated life hours: L70B50 > 30,000 LED driver (included): CE Supply voltage: 220-240V AC 50/60Hz Electrical safety class: Class I Power factor: > 0.90 HOUSING UTILITY FROM € 28 Recommended retail price excl. VAT EFFICIENCY UP TO 90 LM/W MORE INFO ABOUT ECODISC II ONLINE: 3000K, 4000K & 6500K IN ONE
PROLUMIA W H E N L I G H T I N G M A T T E R S WWW.PROLUMIA.COM 36 37 66mm ø380mm 66mm ø330mm 50 100 150 200 250 90° 90° 180° 0° 30° 30° 150° 150° 60° 120° 60° 120° cd / 1000 lm C0 / C180 C90 / C270 Ecodisc II Maxi 50 100 150 200 250 90° 90° 180° 0° 30° 30° 150° 150° 60° 120° 60° 120° cd / 1000 lm C0 / C180 C90 / C270 Ecodisc II Midi 100% 100% 100% 100% 100% 100% 0% / 100%, independent of daylight 0% / 100%, dependent on daylight A B 1 1 2 2 3 3 Off --> after motion detection 100% during delay time --> then off Off when there is enough ambient light --> in the evening/night after motion detection 100% during hold time --> then off 100% upon detection, during hold time. Off when there is sufficient daylight, also after detection. 100% upon detection, during hold time. 100% during hold time, in case of detection and insufficient daylight. Off after expiry of hold time. Off after expiry of hold time. ECODISC II MIDI Ø330 MM ECODISC II MAXI Ø380 MM 18W 1650Lm 23W 2150Lm Art. no. Description Price Ecodisc II Maxi, surface mounted, ø380x66mm, 3000K/4000K/6500K, 2150Lm 40009922 Standard, 23W € 44 40009923 + MW sensor, 24.5W € 68.50 Art. no. Description Price Ecodisc II Midi, surface mounted, ø330x66mm, 3000K/4000K/6500K, 1650Lm 40009912 Standard, 18W € 39.50 40009913 + MW sensor, 19.5W € 63.50 LIGHT DISTRIBUTION LIGHT DISTRIBUTION DIMENSION DRAWING DIMENSION DRAWING MICROWAVE MOTION SENSOR ECODISC II ECODISC II SERIES ECODISC II SERIES Specifications: Detection range ceiling mounting: (at 100% sensitivity 3m mounting height and 0.3m/s speed) 10m Detection range wall mounting: (at 100% sensitivity 2m mounting height and 0.3m/s speed) 8m Maximum mounting height: 6m Sensitivity adjustment range: 25% - 50% - 75% - 100% Hold time: 5 - 30 sec.; 1 - 3 - 5 - 10 - 20 - 30 min. Daylight level: 2 - 10 - 25 - 50 lux - off Examples of sensor settings: HOUSING UTILITY FROM € 39. 50 Recommended retail price excl. VAT FROM € 44 Recommended retail price excl. VAT MORE INFO ABOUT ECODISC II ONLINE: MORE INFO ABOUT ECODISC II ONLINE:
PROLUMIA W H E N L I G H T I N G M A T T E R S WWW.PROLUMIA.COM 38 39 SPECIFICATIONS ø270mm 67 mm ø270mm 100 200 300 90° 90° 180° 0° 30° 30° 150° 150° 60° 120° 60° 120° cd / 1000 lm C0 / C180 C90 / C270 Pro-Stripe LIGHT DISTRIBUTION DIMENSION DRAWING Art. no. black Description Price Pro-Stripe, surface mounted, ø270x67mm, 24W/18W/10W, 2300Lm/1850Lm/1050Lm, 3000K/4000K 40009345 Standard, IP54 (indoor and outdoor use) € 128 40009346 + MW sensor, IP54 (indoor and outdoor use) € 167.50 40009347 + Emergency mode, IP20 (only indoor use) € 190.50 40009348 + Emergency mode + MW sensor, IP20 (only indoor use) € 230.50 PRO-STRIPE PRO-STRIPE SERIES Surface mounted Switchable light output and color temperature Optional with MW sensor and/or Emergency mode Light source: SMD 2835 LED Beam angle: 110° Color temperature: Switchable between 3000K and 4000K Light output: Switchable between 2500Lm, 2000Lm and 1150Lm (white) / 2300Lm, 1850Lm and 1050Lm (black) Operating temperature: -20°C – +40°C Rated life hours: L80B50 > 100,000 / L90B50 > 50,000 LED driver (included): CE Supply voltage: 220-240V AC 50/60Hz Electrical safety class: Class II Power factor: > 0.95 APPLICATIONS HOUSES, PORTALS, HALLWAYS, STAIRCASES, TOILETS, BATHROOMS, ETC. DIFFERENT VERSIONS AVAILABLE: WHITE AND BLACK / STANDARD / MICROWAVE SENSOR / EMERGENCY MODE / EMERGENCY MODE + MICROWAVE SENSOR This series of splash-proof surface mounted fixtures, designed in The Netherlands, has a modern design and thus very suitable for decorative purposes. The versions with a microwave motion sensor and with an emergency function are visibly the same. Combined with the switchable light color an uniform application is possible, even when the functional requirements interchange between a project. MODERN DESIGNED SURFACE MOUNTED FIXTURE POLYCARBONATE HOUSING AND OPAL DIFFUSER COLOR TEMPERATURE SWITCHABLE BETWEEN 3000K AND 4000K LIGHT OUTPUT SWITCHABLE BETWEEN 100%, 80% AND 45% SPLASH-PROOF (IP54) (+ EMERGENCY MODE (IP20)) UNIVERSAL MOUNTING ON A CEILING ORWALL MOUNTING BOX VERSATILE INTERIOR LIGHTING WITH A MODERN LOOK PRO-STRIPE Art. no. white Description Price Pro-Stripe, surface mounted, ø270x67mm, 24W/18W/10W, 2500Lm/2000Lm/1150Lm, 3000K/4000K 40009340 Standard, IP54 (indoor and outdoor use) € 128 40009341 + MW sensor, IP54 (indoor and outdoor use) € 167.50 40009342 + Emergency mode, IP20 (only indoor use) € 190.50 40009343 + Emergency mode + MW sensor, IP20 (only indoor use) € 230.50 HOUSING UTILITY MORE INFO ABOUT PRO-STRIPE ONLINE: COLOR TEMPERATURE SWITCHABLE BETWEEN 3000K AND 4000K FROM € 128 Recommended retail price excl. VAT
PROLUMIA W H E N L I G H T I N G M A T T E R S WWW.PROLUMIA.COM 41 40 0% / 100% / 10% or 30% / 0%, independent of daylight 0% / 100% / 10% or 30% / 0%, dependent on daylight C D Off --> after motion detection 100% during hold time and 10%/30% during standby time --> then off Off when there is sufficient ambient light --> in the evening/night after motion detection 100% during hold time and 10%/30% during standby time --> then off 100% 100% 1 100% upon detection, during hold time. 1 Off when there is sufficient daylight, also after detection. 100% 100% 2 100% upon detection, during hold time. 100% 100% 2 100% during hold time, in case of detection and insufficient daylight. 100% 10%/30% 3 After expiry of hold time to 10%/30% during standby time. 100% 10%/30% 3 After expiry of hold time to 10%/30% during standby time. 4 Off after expiry of standby time. 4 Off after expiry of standby time. 100% 100% 100% 100% 100% 100% 0% / 100%, independent of daylight 0% / 100%, dependent on daylight A B 1 1 2 2 3 3 Off --> after motion detection 100% during delay time --> then off Off when there is enough ambient light --> in the evening/night after motion detection 100% during hold time --> then off 100% upon detection, during hold time. Off when there is sufficient daylight, also after detection. 100% upon detection, during hold time. 100% during hold time, in case of detection and insufficient daylight. Off after expiry of hold time. Off after expiry of hold time. 0% / 10% or 30% / 100% / 10% or 30% / 0% 1 F On at dimmed level based on daylight and 100% upon detection Off when there is sufficient daylight, also after detection. 10%/30% 10%/30% 2 5 In the evening/at night: on at dimmed level. 100% 100% 10%/30% 10%/30% 3 4 100% upon detection, during hold time. 10%/30% 10%/30% 10%/30% 10%/30% 100% 100% 10%/30% 10%/30% 10% or 30% / 100% E 1 2 3 4 Always on at dimmed level --> after detection 100% during hold time Daytime: on at dimmed level. In the evening/at night: on at dimmed level. 100% upon detection, during hold time. In the evening/at night: on at dimmed level. Off when there is sufficient daylight, also after detection. In the evening/at night: on at dimmed level. MICROWAVE MOTION SENSOR PRO-STRIPE PRO-STRIPE SERIES PRO-STRIPE SERIES Specifications: Detection range ceiling mounting: (at 100% sensitivity 3m mounting height and 0.3m/s speed) 10m Detection range wall mounting: (at 100% sensitivity 2m mounting height and 0.3m/s speed) 8m Maximum mounting height: 6m Sensitivity adjustment range: 25% - 50% - 75% - 100% Hold time: 5 sec.; 1 - 3 - 5 min. Hold time orientation lighting: off - 30 min. - 60 min. - ∞ Daylight level: 10 - 50 - 100 lux - off Daylight level with daylight priority: 10 - 50 - 100 lux - off Light level with orientation lighting: 10% - 30% Examples of sensor settings: HOUSING UTILITY MORE INFO ABOUT PRO-STRIPE ONLINE: MORE INFO ABOUT PRO-STRIPE ONLINE:
PROLUMIA W H E N L I G H T I N G M A T T E R S WWW.PROLUMIA.COM 42 43 SPECIFICATIONS 100 200 300 90° 90° 180° 0° 30° 30° 150° 150° 60° 120° 60° 120° cd / 1000 lm C0 / C180 C90 / C270 Pro-Space Round LIGHT DISTRIBUTION DIMENSION DRAWINGS PRO-SPACE ROUND PRO-SPACE SERIES Recessed 6 different sizes & 3 color temperatures Optional with Triac dimmable driver Light source: SMD LED Beam angle: 120° Color rendering index: Ra > 80 Operating temperature: -20°C – +50°C Rated life hours: L70B50 > 50,000 LED driver (included): CE Supply voltage: 220-240V AC 50/60Hz Electrical safety class: Class II APPLICATIONS HALLWAYS, STAIRCASES, TOILETS, BATHROOMS, CANOPIES, ETC. DIFFERENT VERSIONS AVAILABLE: ROUND: Ø 75MM (6W) UP TO Ø 215MM (30W) / SQUARE: # 75MM (6W) UP TO # 215MM (30W) / STANDARD DRIVER (IP40) / TRIAC DIMMABLE DRIVER (IP65) The LED Pro-Space is a sleek and timeless recessed fixture, with a very low installation depth. Due to its trimless design it integrates flawlessly in any ceiling, while the IP66 classification enables use in humid places without difficulty. RECESSED FIXTURE FOR GENERAL LIGHTING HIGH-QUALITY ALUMINIUM HOUSING WITH POLYCARBONATE DIFFUSER WATERPROOF (IP66) AND IMPACT RESISTANT (IK08) UNIFORMLY ILLUMINATED BORDERLESS DESIGN VERY LOW INSTALLATION DEPTH STANDARD IP40 DRIVER OR TRIAC DIMMABLE IP65 DRIVER Description Art. no. Standard driver (IP40) Price Art. no. Triac dimmable driver (IP65) Price Pro-Space Round, recessed, IP66, IK08 ø75x20mm, cutout ø55mm, 6W, 2700K, 380Lm 40004203 € 37.50 40004208 € 51 ø75x20mm, cutout ø55mm, 6W, 3000K, 400Lm 40004200 € 37.50 40004205 € 51 ø75x20mm, cutout ø55mm, 6W, 4200K, 420Lm 40004201 € 37.50 40004206 € 51 ø100x20mm, cutout ø80mm, 8W, 2700K, 540Lm 40004213 € 41 40004218 € 54 ø100x20mm, cutout ø80mm, 8W, 3000K, 570Lm 40004210 € 41 40004215 € 54 ø100x20mm, cutout ø80mm, 8W, 4200K, 590Lm 40004211 € 41 40004216 € 54 ø125x20mm, cutout ø105mm, 11W, 2700K, 760Lm 40004223 € 50 40004228 € 66 ø125x20mm, cutout ø105mm, 11W, 3000K, 800Lm 40004220 € 50 40004225 € 66 ø125x20mm, cutout ø105mm, 11W, 4200K, 840Lm 40004221 € 50 40004226 € 66 ø155x20mm, cutout ø135mm, 15W, 2700K, 1050Lm 40004233 € 63 40004238 € 77 ø155x20mm, cutout ø135mm, 15W, 3000K, 1100Lm 40004230 € 63 40004235 € 77 ø155x20mm, cutout ø135mm, 15W, 4200K, 1160Lm 40004231 € 63 40004236 € 77 ø185x20mm, cutout ø165mm, 22W, 2700K, 1640Lm 40004243 € 75 40004248 € 90.50 ø185x20mm, cutout ø165mm, 22W, 3000K, 1730Lm 40004240 € 75 40004245 € 90.50 ø185x20mm, cutout ø165mm, 22W, 4200K, 1810Lm 40004241 € 75 40004246 € 90.50 ø215x20mm, cutout ø195mm, 30W, 2700K, 2110Lm 40004253 € 88 40004258 € 105 ø215x20mm, cutout ø195mm, 30W, 3000K, 2220Lm 40004250 € 88 40004255 € 105 ø215x20mm, cutout ø195mm, 30W, 4200K, 2330Lm 40004251 € 88 40004256 € 105 Description Art. no. Price Mounting rings ø154.5x37mm, White, for Pro-Space Round ø155mm 40004180 € 18 ø184.5x37mm, White, for Pro-Space Round ø185mm 40004181 € 20 ø214.5x37mm, White, for Pro-Space Round ø215mm 40004182 € 23 ø154.5x37mm, Black, for Pro-Space Round ø155mm 40004190 € 18 ø184.5x37mm, Black, for Pro-Space Round ø185mm 40004191 € 20 ø214.5x37mm, Black, for Pro-Space Round ø215mm 40004192 € 23 ACCESSORIES (EXCLUSIVE) THE SLEEK AND TRIMLESS DESIGN COMPLETES EVERY INTERIOR PRO-SPACE 20mm ø75mm ø55mm 4000420x ø80mm 20mm ø100mm 4000421x ø105mm 20mm ø125mm 4000422x ø135mm 20mm ø155mm 4000423x ø165mm 20mm ø185mm 4000424x ø195mm 20mm ø215mm 4000425x HOUSING UTILITY FROM € 37. 50 Recommended retail price excl. VAT UNIFORMLY ILLUMINATED BORDERLESS DESIGN
PROLUMIA W H E N L I G H T I N G M A T T E R S WWW.PROLUMIA.COM 44 45 100 200 300 90° 90° 180° 0° 30° 30° 150° 150° 60° 120° 60° 120° cd / 1000 lm C0 / C180 C90 / C270 Pro-Space Square LIGHT DISTRIBUTION DIMENSION DRAWINGS PRO-SPACE SQUARE Recessed 6 different sizes & 3 color temperatures Optional with Triac dimmable driver Description Art. no. Standard driver (IP40) Price Art. no. Triac dimmable driver (IP65) Price Pro-Space Square, recessed, IP66, IK08 #75x20mm, cutout ø55mm, 6W, 2700K, 390Lm 40004263 € 37.50 40004268 € 51 #75x20mm, cutout ø55mm, 6W, 3000K, 410Lm 40004260 € 37.50 40004265 € 51 #75x20mm, cutout ø55mm, 6W, 4200K, 430Lm 40004261 € 37.50 40004266 € 51 #100x20mm, cutout ø80mm, 8W, 2700K, 560Lm 40004273 € 41 40004278 € 54 #100x20mm, cutout ø80mm, 8W, 3000K, 590Lm 40004270 € 41 40004275 € 54 #100x20mm, cutout ø80mm, 8W, 4200K, 620Lm 40004271 € 41 40004276 € 54 #125x20mm, cutout ø105mm, 11W, 2700K, 790Lm 40004283 € 50 40004288 € 66 #125x20mm, cutout ø105mm, 11W, 3000K, 830Lm 40004280 € 50 40004285 € 66 #125x20mm, cutout ø105mm, 11W, 4200K, 870Lm 40004281 € 50 40004286 € 66 #155x20mm, cutout ø135mm, 15W, 2700K, 1100Lm 40004293 € 63 40004298 € 77 #155x20mm, cutout ø135mm, 15W, 3000K, 1160Lm 40004290 € 63 40004295 € 77 #155x20mm, cutout ø135mm, 15W, 4200K, 1210Lm 40004291 € 63 40004296 € 77 #185x20mm, cutout ø165mm, 22W, 2700K, 1730Lm 40004303 € 75 40004308 € 90.50 #185x20mm, cutout ø165mm, 22W, 3000K, 1820Lm 40004300 € 75 40004305 € 90.50 #185x20mm, cutout ø165mm, 22W, 4200K, 1910Lm 40004301 € 75 40004306 € 90.50 #215x20mm, cutout ø195mm, 30W, 2700K, 2260Lm 40004313 € 88 40004318 € 105 #215x20mm, cutout ø195mm, 30W, 3000K, 2380Lm 40004310 € 88 40004315 € 105 #215x20mm, cutout ø195mm, 30W, 4200K, 2490Lm 40004311 € 88 40004316 € 105 Description Art. no. Price Mounting rings #154.5x37mm, White, for Pro-Space Square #155mm 40004183 € 18 #184.5x37mm, White, for Pro-Space Square #185mm 40004184 € 20 #214.5x37mm, White, for Pro-Space Square #215mm 40004185 € 23 #154.5x37mm, Black, for Pro-Space Square #155mm 40004193 € 18 #184.5x37mm, Black, for Pro-Space Square #185mm 40004194 € 20 #214.5x37mm, Black, for Pro-Space Square #215mm 40004195 € 23 ACCESSORIES (EXCLUSIVE) PRO-SPACE SERIES PRO-SPACE SERIES 20mm #75mm ø55mm 4000426x ø80mm 20mm #100mm 4000427x ø105mm 20mm #125mm 4000428x ø135mm 20mm #155mm 4000429x ø165mm 20mm #185mm 4000430x ø195mm 20mm #215mm 4000431x HOUSING UTILITY FROM € 37. 50 Recommended retail price excl. VAT MORE INFO ABOUT PRO-SPACE ONLINE:
PROLUMIA W H E N L I G H T I N G M A T T E R S WWW.PROLUMIA.COM 46 47 SPECIFICATIONS 100 200 300 90° 90° 180° 0° 30° 30° 150° 150° 60° 120° 60° 120° cd / 1000 lm C0 / C180 C90 / C270 LIGHT DISTRIBUTION DIMENSION DRAWINGS 48mm ø420mm 39mm ø300mm 39mm ø240mm 39mm ø180mm 39mm ø117mm 4000110x / 4000120x 4000111x / 4000121x 4000112x / 4000122x 4000113x / 4000123x 4000114x / 4000124x PRO-CEILING ROUND Surface mounted White / Black Optional with sensor or dimmable driver Light source: SMD LEDs Beam angle: 110° Color temperature: 2700K, 3000K and 4200K Operating temperature: -10 °C – +40 °C Rated life hours: L80B50 > 100,000 / L90B50 > 50,000 LED driver (included): CE, TUV Supply voltage: 220-240V AC 50/60Hz Power factor: > 0.90 APPLICATIONS HALLWAYS, STAIRCASES, TOILETS, ETC. DIFFERENT VERSIONS AVAILABLE: STANDARD / MICROWAVE SENSOR / EMERGENCY MODE TRIAC DIMMABLE (TRAILING EDGE) / 1-10V DIMMABLE The Prolumia LED Pro-Ceiling series are unique in their design. It combines the warmth from a decorative light with the refinement of a modern, nowadays armature. Available in a round or square shape for ceiling or wall mounting The Prolumia LED Pro-Ceiling series has a lifespan of over 50,000 hours, comes complete with integrated power supply and is installed quickly and easily! RECESSED AND SURFACE MOUNTED LUMINAIRES, AVAILABLE IN ROUND, SQUARE AND RECTANGULAR VERSIONS HOUSING MADE OF DIE-CAST ALUMINIUM, POWDERCOATED INWHITE AND BLACK EQUIPPEDWITH A MILKYWHITE ACRYLIC LENS EXCELLENT HEAT SINK CAPABILITY TO MINIMIZE LUMINOUS DEGRADATION OPTIONALLY AVAILABLE WITH DIMMABLE DRIVER EXPERIENCE THE WARMTH OF DECORATIVE LIGHT, COMBINED WITH THE SOPHISTICATION OF A MODERN, CONTEMPORARY LUMINAIRE PRO-CEILING Pro-Ceiling Round PRO-CEILING SERIES Art. no. White Description Price Art. no. Black Description Price Pro-Ceiling, surface mounted, ø117x39mm, 8W Pro-Ceiling, surface mounted, ø117x39mm, 8W 40001103 2700K, 580Lm € 41 40001203 2700K, 510Lm € 41 40001108 2700K, 580Lm, Triac dimmable € 53.50 40001208 2700K, 510Lm, Triac dimmable € 53.50 40001100 3000K, 630Lm € 41 40001200 3000K, 550Lm € 41 40001105 3000K, 630Lm, Triac dimmable € 53.50 40001205 3000K, 550Lm, Triac dimmable € 53.50 40001101 4200K, 670Lm € 41 40001201 4200K, 590Lm € 41 40001106 4200K, 670Lm, Triac dimmable € 53.50 40001206 4200K, 590Lm, Triac dimmable € 53.50 Pro-Ceiling, surface mounted, ø180x39mm, 11W Pro-Ceiling, surface mounted, ø180x39mm, 11W 40001113 2700K, 900Lm € 49.50 40001213 2700K, 790Lm € 49.50 40001118 2700K, 900Lm, Triac dimmable € 64 40001218 2700K, 790Lm, Triac dimmable € 64 40001113S 2700K, 780Lm, with MW sensor (10W) € 87 40001213S 2700K, 680Lm, with MW sensor (10W) € 87 40001110 3000K, 970Lm € 49.50 40001210 3000K, 850Lm € 49.50 40001115 3000K, 970Lm, Triac dimmable € 64 40001215 3000K, 850Lm, Triac dimmable € 64 40001110S 3000K, 840Lm, with MW sensor (10W) € 87 40001210S 3000K, 730Lm, with MW sensor (10W) € 87 40001111 4200K, 1040Lm € 49.50 40001211 4200K, 910Lm € 49.50 40001116 4200K, 1040Lm, Triac dimmable € 64 40001216 4200K, 910Lm, Triac dimmable € 64 40001111S 4200K, 910Lm, with MW sensor (10W) € 87 - - - Pro-Ceiling, surface mounted, ø240x39mm, 15W Pro-Ceiling, surface mounted, ø240x39mm, 15W 40001123 2700K, 1110Lm € 75.50 40001223 2700K, 970Lm € 75.50 40001128 2700K, 1110Lm, Triac dimmable € 90.50 40001228 2700K, 970Lm, Triac dimmable € 90.50 40001123S 2700K, 1570Lm, with MW sensor (20W) € 126 40001223S 2700K, 1370Lm, with MW sensor (20W) € 126 40001120 3000K, 1190Lm € 75.50 40001220 3000K, 1040Lm € 75.50 40001125 3000K, 1190Lm, Triac dimmable € 90.50 40001225 3000K, 1040Lm, Triac dimmable € 90.50 40001120S 3000K, 1690Lm, with MW sensor (20W) € 126 40001220S 3000K, 1480Lm, with MW sensor (20W) € 126 40001121 4200K, 1280Lm € 75.50 40001221 4200K, 1120Lm € 75.50 40001126 4200K, 1280Lm, Triac dimmable € 90.50 40001226 4200K, 1120Lm, Triac dimmable € 90.50 40001121S 4200K, 1820Lm, with MW sensor (20W) € 127 - - - Pro-Ceiling, surface mounted, ø300x39mm, 30W Pro-Ceiling, surface mounted, ø300x39mm, 30W 40001133 2700K, 2370Lm € 98.50 40001233 2700K, 2070Lm € 98.50 40001138 2700K, 2370Lm, Triac dimmable € 114.50 40001238 2700K, 2070Lm, Triac dimmable € 114.50 40001130 3000K, 2550Lm € 98.50 40001230 3000K, 2230Lm € 98.50 40001135 3000K, 2550Lm, Triac dimmable € 114.50 40001235 3000K, 2230Lm, Triac dimmable € 114.50 40001131 4200K, 2740Lm € 98.50 40001231 4200K, 2390Lm € 98.50 40001136 4200K, 2740Lm, Triac dimmable € 114.50 40001236 4200K, 2390Lm, Triac dimmable € 114.50 Pro-Ceiling, surface mounted, ø420x48mm, 40W Pro-Ceiling, surface mounted, ø420x48mm, 40W 40001143 2700K, 3350Lm € 181.50 40001243 2700K, 2930Lm € 181.50 40001148 2700K, 3350Lm, 1-10V dimmable € 198.50 40001248 2700K, 2930Lm, 1-10V dimmable € 198.50 40001140 3000K, 3610Lm € 181.50 40001240 3000K, 3150Lm € 181.50 40001145 3000K, 3610Lm, 1-10V dimmable € 198.50 40001245 3000K, 3150Lm, 1-10V dimmable € 198.50 40001141 4200K, 3870Lm € 181.50 40001241 4200K, 3380Lm € 181.50 40001146 4200K, 3870Lm, 1-10V dimmable € 198.50 40001246 4200K, 3380Lm, 1-10V dimmable € 198.50 Customer: Apotheek AZ-Delta, Installer: Electro Mandel NV, Photographer: AF-Fotografie HOUSING UTILITY OPTIONALLY AVAILABLE WITH SENSOR OR DIMMABLE DRIVER FROM € 41 Recommended retail price excl. VAT
