1 A R C H I T E C T U R A L L I G H T I N G
3 0 3 . 2 4 V F L E X I B L E C U R V E D S Y S T E M | p . 0 3 6 - 0 4 3 1 5 . G Y P S U M | p . 2 4 8 - 2 5 9 0 2 . 4 8 V U L T R A S L I M M A G N E T I C S Y S T E M | p . 0 2 2 - 0 3 5 0 1 . 4 8 V S P A C E F R A M E M A G N E T I C S Y S T E M | p . 0 1 0 - 0 2 1 0 4 . 4 8 V L I N E A R M A G N E T I C S Y S T E M | p . 0 4 4 - 0 7 7 0 6 . 4 8 V C I R C L E S - C U R V E D M A G N E T I C S Y S T E M | p . 0 9 2 - 1 0 5 0 5 . 4 8 V R O U N D E D R E C T A N G L E M A G N E T I C S Y S T E M | p . 0 7 8 - 0 9 1 0 8 . 2 4 V P L U G & P L A Y | p . 1 1 6 - 1 2 1 0 9 . L I N E A R & C I R C L E S | p . 1 2 2 - 1 4 3 1 0 . 3 - P H A S E T R A C K S & L I G H T S | p . 1 4 4 - 1 6 5 1 1 . D O W N L I G H T R E C E S S E D & T R I M L E S S L E D S P O T S | p . 1 6 6 - 2 0 1 1 2 . W A T E R P R O O F D O W N L I G H T S P O T S | p . 2 0 2 - 2 0 9 1 3 . D O W N L I G H T R E C E S S E D S P O T S G U 1 0 | p . 2 1 0 - 2 2 3 1 4 . C E I L I N G S P O T S | p . 2 2 4 - 2 4 7 I N D E X 0 7 . 2 4 V M I N I S U R F A C E M A G N E T I C S Y S T E M | p . 1 0 6 - 1 1 5 1 6 . A L U M I N I U M P R O F I L E S - L E D S T R I P S - D R I V E R S | p . 2 6 0 - 2 7 9
5 4 A R C H I T E C T U R A L L I G H T I N G 23142 p.17 NEW 23153 p.16 NEW 23296 p.17 NEW 23145 p.16 NEW 23139 p.17 NEW 23154 p.21 NEW 23152 p.14 NEW 23121 p.26 NEW 23110 p.30 23118 p.27 23124 p.28 NEW NEW NEW 23113 p.30 23112 p.30 23115 p.32 23114 p.32 NEW NEW NEW NEW 23126 p.34 23117 p.33 23116 p.33 NEW NEW NEW 23183 p.40 23178 p.38 NEW 23182 p.40 NEW NEW 23186 p.42 NEW 23185 p.40 NEW 23187 p.42 NEW 2083 p.48 2087 p.52 2085 p.51 2084 p.50 20291 p.54 2082 p.49 2091-27B p.54 NEW 2092-D p.56 2089-4W p.66 2091-3W p.66 20178 p.62 20180 p.62 20406 p.60 NEW 2081-D p.64 NEW 20291-W p.68 NEW 20414 p.70 NEW 22273B-1 p.80 NEW 22275 p.80 NEW 22274B-1 p.82 NEW 22276 p.82 NEW 22101 p.84 22099 p.84 22100 p.84 22107 p.84 22273B-2 p.94 NEW 22090 p.94 NEW 22274B-2 p.96 NEW 22091 p.96 NEW 22096 p.99 22120 p.99 NEW 22121 p.99 NEW 22071 p.104 22070 p.104 NEW NEW 22072 p.104 NEW 22251 p.111 22252 p.111 22253 p.111 19169 p.118 19172 p.118 19151 p.118 22262 p.114 22256 p.112 19152 p.118 19166 p.118 5158D p.126 19167 p.121 20140 p.120 20139 p.120 19155 p.120 5358D p.130 3158D p.134 19403-R p.146 19406 p.146 19400 p.146 3358D p.136 81063B p.142 19430 p.147 NEW 23150 p.15 23149 p.15 NEW NEW 23148 p.15 NEW
7 6 A R C H I T E C T U R A L L I G H T I N G S195 p.196 S061 p.219 Z11105TR-B p.216 RFL126-BL p.213 S125 p.212 E332 p.204 Z10103BTR-B p.195 S060 p.219 Z10105-AD p.216 S128 p.213 S168 p.208 S102 p.201 Z10103BTR-W p.195 S150 p.218 Z10105-D9 p.216 S126 p.213 S165 p.208 S087 p.201 S193 p.198 S012 p.220 S149 p.217 S130 p.213 RFL125-BL p.212 180016 p.205 1927 p.195 S148 p.217 NEW S089 p.214 RFL125-G p.212 S111 p.206 S190 p.199 NEW 180013 p.195 S163 p.218 S091 p.214 S129 p.212 S046 p.206 S086 p.200 NEW S192 p.197 S020 p.219 Z11105TR-W p.216 RFL126-G p.213 S127 p.212 S162 p.205 S143 p.194 S204 p.180 S176 p.184 S171 p.182 S169 p.182 S205 p.180 NEW S208 p.180 NEW S145 p.194 S173 p.186 19413 p.147 18306 p.152 S203 p.150 S197 p.150 19414 p.147 S065 p.148 S114 p.154 NEW NEW S118 p.154 S054-40 p.158 S062-40 p.156 S059 p.156 S122 p.154 S123 p.154 S056-40 p.158 180015 p.160 S138 p.172 NEW NEW S136 p.170 S037 p.164 Z65105NT-G p.162 1928-B p.160 Z65644T-W p.162 S140 p.171 NEW S187 p.176 S185 p.176 S183 p.174 S142 p.173 NEW S181 p.174 NEW NEW NEW NEW S178 p.186 S070 p.193 S078 p.192 S094 p.192 S075 p.188 S097 p.190 NEW NEW NEW NEW NEW NEW NEW NEW NEW NEW NEW NEW NEW NEW NEW NEW NEW
9 8 20194 p.262 28003210 p.278 4052899605503 p.274 LS05 p.270 20325 p.267 20198 p.264 20193 p.262 4052899605787 p.278 LS16 p.273 LS12 p.270 20328 p.267 20195 p.264 S048 p.258 89800257 p.277 LS15 p.273 LS32 p.269 20327 p.266 20190 p.264 20205 p.263 LSW700P p.279 4052899465916 p.275 LS07 p.271 LS22 p.268 20201 p.265 S029 p.256 4052899557949 p.276 LS04 p.272 LS28 p.268 NEW 20206 p.265 20203 p.263 S047 p.258 Z89200VND p.276 LSO1 p.272 LS33 p.269 NEW 20326 p.266 20204 p.263 20197 p.262 D-DALI20 p.279 4062172329767 p.275 LS06 p.271 20329 p.267 20199 p.265 S214 p.226 S030 p.256 20272 p.250 S152 p.242 S161 p.236 S153 p.232 S147 p.222 180028 p.255 S063 p.246 S039 p.242 S160 p.236 S001 p.230 S014 p.221 180025 p.255 S158 p.244 S069 p.241 S159 p.236 S179 p.230 S217 p.228 S027 p.256 20274 p.252 22133 p.239 S155 p.232 S009 p.220 180026 p.254 S156 p.244 NEW S131 p.240 Z12107K-W p.234 S218 p.228 NEW S008 p.221 180027 p.254 S157 p.244 NEW S134 p.240 Z12107K-B p.234 S180 p.230 S215 p.226 S025 p.256 20273 p.252 S151 p.242 S112 p.238 S154 p.232 A R C H I T E C T U R A L L I G H T I N G NEW NEW NEW NEW NEW NEW NEW NEW NEW NEW NEW NEW NEW NEW S040 p.242 NEW NEW NEW NEW NEW NEW NEW NEW NEW NEW NEW NEW
11 10 4 8 V S P A C E F R A M E M A G N E T I C S Y S T E M | p . 0 1 0 - 0 2 1
13 12 A R C H I T E C T U R A L L I G H T I N G | 4 8 V S P A C E F R A M E M A G N E T I C S Y S T E M D O I T Y O U R S E L F. . . M A G N E T I C T R A C K S P O T T U B E S P O T T U B E W I T H U P - L I G H T D O W N L I G H T T U B E
15 14 1 2 3 4 Feeder Tube needs to be used in conjunction with Power Supply 48V. End Cap and Inner Connector is needed at combined tail end. Each group of circuits should not exceed 200W. Insulator block circuit should be used in circuit grouping. Power Supply Connection *Dimensions Indicated In Millimeters End Cap Inner Connector 1 2 3 Inner Connector 4 T Connector 5 Cross Connector 6 L Connector Dimensions Ø: 25mm H:562mm Material Metal Color Black Matt / Code 23155 Feeder Tube Dimensions Ø: 25mm H: 593mm Material Metal Color Black Matt / Code 23152 Pendant Tube Dimensions Ø: 30mm L: 70mm Material Plastic Color Black Matt / Code 23156 Inner Connector Dimensions Ø: 30mm L: 70mm W: 50mm Material Plastic Color Black Matt / Code 23150 T Connector 30 30 Ø30 70 Dimensions Ø: 30mm L: 23mm Material Plastic Color Black Matt / Code 23151 End Cap Dimensions Ø: 30mm L: 50mm W: 50mm Material Plastic Color Black Matt / Code 23149 L Connector Ø30 30 Ø30 23 50 30 30 50 50 30 30 70 Dimensions Ø: 30mm L: 70mm W: 70mm Material Plastic Color Black Matt / Code 23148 Cross Connector 70 30 70 A R C H I T E C T U R A L L I G H T I N G | 4 8 V S P A C E F R A M E M A G N E T I C S Y S T E M
17 16 Input 48V Dimensions Ø: 30mm L: 635mm | 1235mm | 1835mm Material Aluminium Color Black Matt 635 | 1235 | 1835 30 A R C H I T E C T U R A L L I G H T I N G | 4 8 V S P A C E F R A M E M A G N E T I C S Y S T E M 23147 635mm Track Code Size 23145 1235mm 23146 1835mm 23295 635mm Track Code Size 23296 1235mm 23297 1835mm Power 12W | 24W | 36W Input 48V Color Temperature 3000K Lumen 966Lm | 1812Lm | 2708Lm Cri 90 Dimensions Ø: 30mm L: 635mm | 1235mm | 1835mm Beam Angle 115o DALI Dimmable Material Aluminium - Acrylic Color Black Matt 635 | 1235 | 1835 30 23144 635mm Track Code Size 23142 1235mm 23143 1835mm Power 25W | 50W | 75W Input 48V Color Temperature 3000K Lumen 1966Lm | 2812Lm | 3708Lm Cri 90 Dimensions Ø: 30mm L: 635mm | 1235mm | 1835mm Beam Angle 20o DALI Dimmable Material Aluminium - Acrylic Special Feature Up-Down Light Color Black Matt 635 | 1235 | 1835 30 23141 635mm Track Code Size 23139 1235mm 23140 1835mm Power 12W | 24W | 36W Input 48V Color Temperature 3000K Lumen 985Lm | 1831Lm | 2726Lm Cri 90 Dimensions Ø: 30mm L: 635mm | 1235mm | 1835mm Beam Angle 20o DALI Dimmable Material Aluminium - Acrylic Color Black Matt 635 | 1235 | 1835 30 Power 9.6W Input 48V Color Temperature 3000K Lumen 780Lm Cri 90 Dimensions Ø: 45mm L: 151mm Beam Angle 28o DALI Dimmable Material Aluminium Color Black Matt / Code 23153 45 151 *Dimensions Indicated In Millimeters *Dimensions Indicated In Millimeters
19 18 19 A R C H I T E C T U R A L L I G H T I N G | 4 8 V S P A C E F R A M E M A G N E T I C S Y S T E M Each group of circuits should not exceed 200W. Circuit grouping, need to block the circuit. WARNING
21 20 A R C H I T E C T U R A L L I G H T I N G | 4 8 V S P A C E F R A M E M A G N E T I C S Y S T E M I n s t a l l a t i o n G u i d e ( O n / O f f A p p l i c a t i o n ) 21 Power 200W Input 220-240V Output 48V Dimensions L: 355mm W: 124mm H: 39.5mm Material Metal Special Feature Driver On the Box Color Black Matt / Code 23154 Power Supply 48V On/Off Power 200W Input 220-240V Output 48V Dimensions L: 355mm W: 124mm H: 39.5mm Material Metal Special Feature DALI Driver is out of the box (Remote) Color Black Matt / Code 23157 Power Supply 48V DALI Remote Dimensions Ø: 25mm H:562mm Material Metal Color Black Matt / Code 23155 Feeder Tube Dimensions Ø: 25mm H: 593mm Material Metal Color Black Matt / Code 23152 Pendant Tube
23 22 23 4 8 V U L T R A S L I M M A G N E T I C S Y S T E M | p . 0 2 2 - 0 3 5
25 24 25 A R C H I T E C T U R A L L I G H T I N G | 4 8 V U L T R A S L I M M A G N E T I C S Y S T E M
27 26 Trimless Slim Magnetic Track : 1m / 2m / 3m Accessories for Trimless Slim Magnetic Track End Cap Material Plastic Color Black / Code 23262 Straight Mechanic Connector Material Aluminium Color Black / Code 23263 23121 Sandy Black 1m Track Code Color Size 23122 Sandy Black 2m 23133 Sandy Black Vertical Corner Code Color Plane 23130 Sandy Black Horizontal 23123 Sandy Black 3m Notice : For Vertical corner required also to order 23128 and for Horizontal corner required also to order 23129 CORNER 9Oo (23130) Horizontal Plane CORNER 9Oo (23133) Vertical Plane 5.5 4.8 6.9 1.4 4.8 4.8 4.8 1.4 A R C H I T E C T U R A L L I G H T I N G | 4 8 V U L T R A S L I M M A G N E T I C S Y S T E M 4.8 1.35 1.5 1.9 Surface Slim Magnetic Track : 1m / 2m / 3m Accessories for Surface Slim Magnetic Track End Cap Material Plastic Color Black / Code 23262 Straight Mechanic Connector Material Aluminium Color Black / Code 23263 23118 Sandy Black 1m Track Code Color Size 23119 Sandy Black 2m 23132 Sandy Black Vertical Corner Code Color Plane 23131 Sandy Black Horizontal 23120 Sandy Black 3m Notice : For Vertical corner required also to order 23128 and for Horizontal corner required also to order 23129 CORNER 9Oo (23131) Horizontal Plane CORNER 9Oo (23132) Vertical Plane 1.9 1.35 1.5 4.8 4.8 1.35 1.9 4.8 4.8 1.9 1.35 PC Cover 3m Plastic Color Black / Code 23125 PC Cover 3m Plastic Color Black / Code 23125 6.9 5.5
29 28 Pendant Round Magnetic Track : 2m Accessories for Round Magnetic Track End Cap Material Plastic Color Black / Code 23264 Straight Mechanic Connector Material Aluminium Color Black / Code 23263 A R C H I T E C T U R A L L I G H T I N G | 4 8 V U L T R A S L I M M A G N E T I C S Y S T E M 2.8 2.4 1.5 PC Cover 3m Plastic Color Black / Code 23125 Input 48V Dimensions L: 200cm Ø: 2.8cm Material Aluminium Color Black Matt / Code 23124 Pendant Kit with Wire 150cm Metal Color Chrome / Code 23265 29
31 30 Power 6W Input 48V Color Temperature 3000K Lumen 408Lm Cri 90 Dimensions L: 30cm W: 1.5cm H: 1.1cm Beam Angle 110o DALI Dimmable Material Aluminium - PC Diffuser Color Sandy Black / Code 23110 Power 12W Input 48V Color Temperature 3000K Lumen 832Lm Cri 90 Dimensions L: 60cm W: 1.5cm H: 1.1cm Beam Angle 110o DALI Dimmable Material Aluminium - PC Diffuser Color Sandy Black / Code 23111 Power 6W Input 48V Color Temperature 3000K Lumen 475Lm Cri 90 Dimensions L: 30cm W: 1.5cm H: 1.1cm Beam Angle 36o DALI Dimmable Material Aluminium Color Sandy Black / Code 23112 Power 6W Input 48V Color Temperature 3000K Lumen 415Lm Cri 90 Dimensions L: 30cm W: 1.5cm H: 1.1cm Beam Angle 36o DALI Dimmable Material Aluminium Color Sandy Black / Code 23113 1.1 1.5 60 1.1 1.5 1.5 30 1.1 1.5 30 1.1 30 A R C H I T E C T U R A L L I G H T I N G | 4 8 V U L T R A S L I M M A G N E T I C S Y S T E M 31
33 32 Power 5W Input 48V Color Temperature 3000K Lumen 305Lm Cri 90 Dimensions L: 15cm W: 4-5.8cm H: 4.5-7.5cm Spot Dimensions Ø: 3.2cm H: 5.8cm Beam Angle 24o DALI Dimmable Material Aluminium Special Feature Movable Spot Color Sandy Black / Code 23114 A R C H I T E C T U R A L L I G H T I N G | 4 8 V U L T R A S L I M M A G N E T I C S Y S T E M Power 3W Input 48V Color Temperature 3000K Lumen 186Lm Cri 90 Dimensions Ø: 8cm Beam Angle 340o DALI Dimmable Material Aluminium - Glass Color Sandy Black / Code 23117 15 8 10 Power 8W Input 48V Color Temperature 3000K Lumen 554Lm Cri 90 Dimensions L: 11.2cm W: 1.5-4.5cm H: 5.5-8.7cm Beam Angle 24o DALI Dimmable Material Aluminium Special Feature Adjustable Grille Color Sandy Black / Code 23115 11.2 1.5 8.7 Power 8W Input 48V Color Temperature 3000K Lumen 553Lm Cri 90 Dimensions Ø: 9cm H: 9.5cm Beam Angle 36o DALI Dimmable Material Aluminium Special Feature 120cm Cable Available Color Sandy Black / Code 23116 22 9 9.5 120 15 1.5 3.2 5.8 3
35 34 Feeder for 48V Slim Tracks Inner Connector for 48V Slim Tracks Flex Connector for 48V Slim Tracks Corner Connector for 48V Slim Tracks Dimensions L: 11cm W: 1.5cm H: 1.1cm Material Aluminium Special Feature 150cm Available Color Sandy Black / Code 23126 Dimensions L: 11cm W: 1.5cm H: 1.1cm Material Aluminium Color Sandy Black / Code 23127 Dimensions L: 16cm W: 1.5cm H: 1.1cm Material Aluminium Color Sandy Black / Code 23128 Dimensions L: 9.4cm W: 9.4cm H: 1.1cm Material Aluminium Color Sandy Black / Code 23129 11 1.5 1.1 11 1.5 1.1 16 1.5 1.1 9.4 9.4 1.5 A R C H I T E C T U R A L L I G H T I N G | 4 8 V U L T R A S L I M M A G N E T I C S Y S T E M Accessories for 48V Slim - Round Tracks Remote Driver 100W 48V 5Years Guarantee ON-OFF / Code 20296 Remote Driver 150W 48V 5Years Guarantee ON-OFF / Code 20297 Remote Driver 60W 48V 5Years Guarantee ON-OFF / Code 20295 32 162.5 42.5 37 190 52 88 191 35.5 Drivers 48V for Slim - Round Tracks 31 4.5 6 Remote Driver 200W 48V 5Years Guarantee DALI / Code 23134 Driver for Slim - Round Magnetic Tracks Power 150W Input 220-240 , 50-60Hz Output 48V Special Feature Integrates Into Track Color Black Guarantee 2Years ON-OFF / Code 23159 1.5 30.4 3.2 8 3.5 Ceiling Base Dimensions Ø: 8cm H: 3.5cm Material Metal Color Sandy Black / Code 23280
37 36 37 2 4 V F L E X I B L E C U R V E D S Y S T E M | p . 0 3 6 - 0 4 3
39 38 Input 24V Dimensions L: 200cm W: 0.8cm H: 1.6cm Material Aluminium Color Sandy Black / Code 23178 Input 24V Dimensions L: 300cm W: 0.8cm H: 1.6cm Material Aluminium Color Sandy Black / Code 23177 Ceiling Base for 24V Flexible Track Dimensions Ø: 3.5cm H: 9cm Material Aluminium Color Sandy Black / Code 23179 Track Connector for 24V Flexible Track Dimensions L: 5cm W: 2cm H: 3.3cm Material Aluminium Color Sandy Black / Code 23180 A R C H I T E C T U R A L L I G H T I N G | 2 4 V F L E X I B L E C U R V E D S Y S T E M Flexible Track : 2m | 3m 9 39 0.8 1.6 3.5 3.3 5
41 40 Power 10W Input 24V Color Temperature 3000K Lumen 832Lm Cri 90 Dimensions L: 30cm W: 3.4cm H: 5cm Beam Angle 120o DALI Dimmable Material Aluminium - PC Diffuser Special Feature This light can also used as connector between 2 tracks Color Sandy Black / Code 23182 Power 10W Input 24V Color Temperature 3000K Lumen 795Lm Cri 90 Dimensions L: 13.5cm W: 3.4cm H: 5cm Beam Angle 40o DALI Dimmable Material Aluminium - Acrylic Color Sandy Black / Code 23183 A R C H I T E C T U R A L L I G H T I N G | 2 4 V F L E X I B L E C U R V E D S Y S T E M 30 5 13.5 5 Power 5W Input 24V Color Temperature 3000K Lumen 378Lm Cri 80 Dimensions Ø: 3.8cm H: 10cm Beam Angle 36o DALI Dimmable Material Aluminium Color Sandy Black / Code 23184 Power 5W Input 24V Color Temperature 3000K Lumen 378Lm Cri 80 Dimensions Ø: 3.8cm H: 10cm Beam Angle 36o DALI Dimmable Material Aluminium Color Gold Matt / Code 23185 10 3.8 10 3.8 41
43 42 Power 5W Input 24V Color Temperature 3000K Lumen 281Lm Cri 80 Dimensions Ø: 6cm DALI Dimmable Material Aluminium Color Sandy Black / Code 23187 Color Gold Matt / Code 23188 Box with DALI Driver for 24V Flexible Track Power 150W Input 220-240 , 50-60Hz Output 24V Dimensions L: 40cm W: 3.5cm H: 5cm DALI Dimmable Material Metal Special Feature 100cm Cable Available Included Ceiling Base D: 8cm for Wire Connection Color Sandy Black / Code 23181 A R C H I T E C T U R A L L I G H T I N G | 2 4 V F L E X I B L E C U R V E D S Y S T E M Power 6W Input 24V Color Temperature 3000K Lumen 470Lm Cri 90 Dimensions Ø: 3cm H: 30cm Beam Angle 40o DALI Dimmable Material Aluminium Special Feature 120cm Cable Adjustable Color Sandy Black / Code 23186 3 30 6 355o Movable 45o Movable 40 5 Feeder for Remote Driver Application Input 24V Dimensions Ø: 3.5cm H: 4.7cm Material Metal Special Feature 100cm Cable Available Included Ceiling Base D: 8cm for Wire Connection Color Sandy Black / Code 23189 Power 120W Input 220-240V, 50/60Hz Output 24V Dimensions W: 4.1cm H: 3.1cm L: 26cm Non Dimmable On-Off ELEMENT 120/220-240/24 G2 Material Plastic Special Feature IP 20 Color White / Code 4052899605541 Power 250W Input 220-240V, 50/60Hz Output 24V Dimensions W: 3.5cm H: 5cm L: 37.5cm Non Dimmable On-Off ELEMENT 250/220-240/24 G2 Material Plastic Special Feature IP 20 Color White / Code 4062172333467 4.7 3.5 Power 180W Input 220-240V, 50/60Hz Output 24V Dimensions W: 4cm H: 3.1cm L: 30cm Non Dimmable On-Off ELEMENT 180/220-240/24 G2 Material Plastic Special Feature IP 20 Color White / Code 4052899605565 Power 60W Input 220-240V, 50/60Hz Output 24V Dimensions W: 4.1cm H: 3.1cm L: 20.1cm Non Dimmable On-Off ELEMENT 60/220-240/24 G2 Material Plastic Special Feature IP 20 Color White / Code 4052899605527
45 44 45 4 8 V L I N E A R M A G N E T I C S Y S T E M | p . 0 4 4 - 0 7 7
47 46 47 A R C H I T E C T U R A L L I G H T I N G | 4 8 V L I N E A R M A G N E T I C S Y S T E M
49 48 SURFACE Track : 1m / 2m / 3m CORNER 9Oo (c1) Vertical Plane CORNER 9Oo (c2) Horizontal Plane PC Cover 3m Material Plastic Color Black Matt / Code 20107 Color White Matt / Code 20107-W End Cap Material Plastic Color Black / Code 2098-B Color White / Code 2098-W Surface Mounted Kit (2pcs) Material Stainless Steel Code 2082SP Accessories for Track 2082 Straight Mechanic Connector Material Aluminium Code 2097-B Suspension Kit (2pcs) / Adjustable Wire 2m Material Aluminium Code 20102-B 23 26 52 50 50 TRIMLESS Track : 1m / 2m / 3m CORNER 9Oo (c1) Vertical Plane CORNER 9Oo (c2) Horizontal Plane Accessories for Track 2083 End Cap Material Plastic Color Black / Code 2099-B Color White / Code 2099-W PC Cover 3m Material Plastic Color Black Matt / Code 20107 Color White Matt / Code 20107-W 23 74 13 54 50 50 2083B-1 Sandy Black 1m 2083W-1 Sandy White 1m Track Code Color Size 2083W-2 Sandy White 2m 2083B-2 Sandy Black 2m 2083B-C1 Sandy Black Vertical 2083W-C1 Sandy White Vertical Corner Code Color Plane 2083W-C2 Sandy White Horizontal 2083B-C2 Sandy Black Horizontal 2083W-3 Sandy White 3m 2083B-3 Sandy Black 3m Notice : For corners type C1 required also to order 20105 and for type C2 20104 2082B-1 Sandy Black 1m 2082W-1 Sandy White 1m Track Code Color Size 2082W-2 Sandy White 2m 2082B-2 Sandy Black 2m 2082B-C1 Sandy Black Vertical 2082W-C1 Sandy White Vertical Corner Code Color Plane 2082W-C2 Sandy White Horizontal 2082B-C2 Sandy Black Horizontal 2082W-3 Sandy White 3m 2082B-3 Sandy Black 3m Notice : For corners type C1 required also to order 20105 and for type C2 20104 A R C H I T E C T U R A L L I G H T I N G | 4 8 V L I N E A R M A G N E T I C S Y S T E M *Dimensions Indicated In Millimeters *Dimensions Indicated In Millimeters
51 50 SURFACE SHORT Track : 1m / 2m / 3m CORNER 9Oo (c1) Vertical Plane CORNER 9Oo (c2) Horizontal Plane End Cap Material Plastic Color Black / Code 20101-B Color White / Code 20101-W Accessories for Track 2085 Straight Mechanic Connector Material Aluminium Code 2097 Suspension Kit (2pcs) / Adjustable Wire 2m Material Aluminium Code 20102 26 29 50 50 RECESSED Track : 1m / 2m / 3m CORNER 9Oo (c1) Vertical Plane CORNER 9Oo (c2) Horizontal Plane Recessed Accessorie Kit (2pcs) Material Stainless Steel Code 20106 Accessories for Track 2084 End Cap Material Metal Color Black / Code 20108-1B Color White / Code 20108-1W End Cap Material Metal Color Black / Code 20108-B Color White / Code 20108-W 50 50 23 26 56 39 2084B-1 Sandy Black 1m 2084W-1 Sandy White 1m Track Code Color Size 2084W-2 Sandy White 2m 2084B-2 Sandy Black 2m 2084B-C1 Sandy Black Vertical 2084W-C1 Sandy White Vertical Corner Code Color Plane 2084W-C2 Sandy White Horizontal 2084B-C2 Sandy Black Horizontal 2084W-3 Sandy White 3m 2084B-3 Sandy Black 3m Notice : For corners type C1 required also to order 20105 and for type C2 20104 2085B-1 Sandy Black 1m 2085W-1 Sandy White 1m Track Code Color Size 2085W-2 Sandy White 2m 2085B-2 Sandy Black 2m 2085B-C1 Sandy Black Vertical 2085W-C1 Sandy White Vertical Corner Code Color Plane 2085W-C2 Sandy White Horizontal 2085B-C2 Sandy Black Horizontal 2085W-3 Sandy White 3m 2085B-3 Sandy Black 3m Notice : For corners type C1 required also to order 20105 and for type C2 20104 *Dimensions Indicated In Millimeters A R C H I T E C T U R A L L I G H T I N G | 4 8 V L I N E A R M A G N E T I C S Y S T E M *Dimensions Indicated In Millimeters
53 52 Power 12W Input 48V Color Temperature 3000K Lumen 779Lm Cri 80 Dimensions L: 328mm W: 23mm H: 45mm Beam Angle 120o DALI Dimmable Material Aluminium - PC Diffuser Color Sandy Black / Code 2087 Power 12W Input 48V Color Temperature 3000K Lumen 779Lm Cri 80 Dimensions L: 328mm W: 23mm H: 45mm Beam Angle 120o Non Dimmable Material Aluminium - PC Diffuser Color Sandy Black / Code 2086 328 23 45 Power 20W Input 48V Color Temperature 2700K | 3000K | 4000K Lumen 1655Lm | 1669Lm | 1897Lm Cri 80 Dimensions L: 652mm W: 23mm H: 45mm Beam Angle 120o DALI Dimmable Material Aluminium - PC Diffuser Color 3000K Sandy Black / Code 2089 Color 4000K Sandy Black / Code 2089-4B Color 2700K Sandy Black / Code 2089-27B Power 20W Input 48V Color Temperature 3000K Lumen 1669Lm Cri 80 Dimensions L: 652mm W: 23mm H: 45mm Beam Angle 120o Non Dimmable Material Aluminium - PC Diffuser Color Sandy Black / Code 2088 23 45 652 *Dimensions Indicated In Millimeters 53 A R C H I T E C T U R A L L I G H T I N G | 4 8 V L I N E A R M A G N E T I C S Y S T E M
55 54 *Dimensions Indicated In Millimeters Power 12W Input 48V Color Temperature 3000K Lumen 1021Lm Cri 80 Dimensions L: 220mm W: 23mm H: 53mm Beam Angle 30o Non Dimmable Material Aluminium - Acrylic Color Sandy Black / Code 20290 Power 12W Input 48V Color Temperature 3000K Lumen 1021Lm Cri 80 Dimensions L: 220mm W: 23mm H: 53mm Beam Angle 30o DALI Dimmable Material Aluminium - Acrylic Color Sandy Black / Code 20291 23 220 53 Power 8W Input 48V Color Temperature 3000K Lumen 693Lm Cri 80 Dimensions L: 220mm W: 23mm H: 45mm Beam Angle 30o Non Dimmable Material Aluminium - Acrylic Color Sandy Black / Code 2090 Power 8W Input 48V Color Temperature 2700K | 3000K | 4000K Lumen 675Lm | 693Lm | 713Lm Cri 80 Dimensions L: 220mm W: 23mm H: 45mm Beam Angle 30o DALI Dimmable Material Aluminium - Acrylic Color 3000K Sandy Black / Code 2091 Color 4000K Sandy Black / Code 2091-4B Color 2700K Sandy Black / Code 2091-27B 220 23 45 5 A R C H I T E C T U R A L L I G H T I N G | 4 8 V L I N E A R M A G N E T I C S Y S T E M
57 56 57 150 23 95 Power 10W Input 48V Color Temperature 3000K Lumen 945Lm Cri 80 Dimensions L: 150mm W: 23mm H: 95mm Beam Angle Asymmetric 50o Non Dimmable Material Aluminium - Acrylic Color Sandy Black / Code 2092 Power 10W Input 48V Color Temperature 3000K Lumen 945Lm Cri 80 Dimensions L: 150mm W: 23mm H: 95mm Beam Angle Asymmetric 50o DALI Dimmable Material Aluminium - Acrylic Color Sandy Black / Code 2092-D *Dimensions Indicated In Millimeters A R C H I T E C T U R A L L I G H T I N G | 4 8 V L I N E A R M A G N E T I C S Y S T E M
59 58 Power 5W Input 48V Color Temperature 3000K Lumen 414Lm Cri 80 Dimensions Ø: 26mm H: 125mm Beam Angle 24o DALI Dimmable Material Aluminium Color Sandy Black / Code 2094 Power 5W Input 48V Color Temperature 3000K Lumen 414Lm Cri 80 Dimensions Ø: 26mm H: 125mm Beam Angle 24o Non Dimmable Material Aluminium Color Sandy Black / Code 2093 26 125 59 *Dimensions Indicated In Millimeters A R C H I T E C T U R A L L I G H T I N G | 4 8 V L I N E A R M A G N E T I C S Y S T E M
61 60 Power 15W Input 48V Color Temperature 3000K | 4000K Lumen 1284Lm | 1312Lm Cri 80 Dimensions Ø: 65mm H: 130mm Beam Angle 24o DALI Dimmable Material Aluminium Color 3000K Sandy Black / Code 20413 Color 4000K Sandy Black / Code 20415 Power 15W Input 48V Color Temperature 3000K | 4000K Lumen 1284Lm | 1312Lm Cri 80 Dimensions Ø: 65mm H: 130mm Beam Angle 24o Non Dimmable Material Aluminium Color 3000K Sandy Black / Code 20410 Color 4000K Sandy Black / Code 20411 Power 7W Input 48V Color Temperature 2700K | 3000K Lumen 565Lm | 580Lm Cri 80 Dimensions Ø: 37mm H: 87mm Beam Angle 32o DALI Dimmable Material Aluminium Color 3000K Sandy Black / Code 20400-BD Color 2700K Sandy Black / Code 20407-BD Power 7W Input 48V Color Temperature 3000K | 4000K Lumen 580Lm | 605Lm Cri 80 Dimensions Ø: 37mm H: 87mm Beam Angle 32o Non Dimmable Material Aluminium Color 3000K Sandy Black / Code 20402-B Color 4000K Sandy Black / Code 20406 37 87 130 65 *Dimensions Indicated In Millimeters 61 A R C H I T E C T U R A L L I G H T I N G | 4 8 V L I N E A R M A G N E T I C S Y S T E M
63 62 Power 12W Input 48V Color Temperature 3000K Lumen 763Lm Cri 80 Dimensions Ø: 120mm H: 110mm Beam Angle 38o Non Dimmable Material Aluminium Color Sandy Black / Code 20177 Color Sandy White / Code 20178 110 120 30 Power 5W Input 48V Color Temperature 3000K Lumen 363Lm Cri 80 Dimensions Ø: 27mm H: 145mm Beam Angle 24o Non Dimmable Material Aluminium Color Sandy Black / Code 20179 Color Gold / Code 20180 27 145 Power 15W Input 48V Color Temperature 3000K Lumen 1225Lm Cri 80 Dimensions Ø: 45mm H: 200mm Beam Angle 24o DALI Dimmable Material Aluminium Color Sandy Black / Code 2095-D Power 15W Input 48V Color Temperature 3000K Lumen 1225Lm Cri 80 Dimensions Ø: 45mm H: 200mm Beam Angle 24o Non Dimmable Material Aluminium Color Sandy Black / Code 2095 200 45 63 *Dimensions Indicated In Millimeters *Dimensions Indicated In Millimeters A R C H I T E C T U R A L L I G H T I N G | 4 8 V L I N E A R M A G N E T I C S Y S T E M
65 64 65 Power 7W Input 48V Color Temperature 3000K Lumen 431Lm Cri 80 Dimensions Ø: 30mm H: 500mm Beam Angle 24o DALI Dimmable Material Aluminium Special Feature 100cm Cable Adjustable Color Sandy Black / Code 2081-D Color Sandy White / Code 2081-WD Power 7W Input 48V Color Temperature 3000K Lumen 431Lm Cri 80 Dimensions Ø: 30mm H: 500mm Beam Angle 24o Non Dimmable Material Aluminium Special Feature 100cm Cable Adjustable Color Sandy Black / Code 2081 Color Sandy White / Code 2081-W 30 500 *Dimensions Indicated In Millimeters A R C H I T E C T U R A L L I G H T I N G | 4 8 V L I N E A R M A G N E T I C S Y S T E M
67 66 Power 20W Input 48V Color Temperature 3000K | 4000K Lumen 1669Lm | 1897Lm Cri 80 Dimensions L: 652mm W: 23mm H: 45mm Beam Angle 120o DALI Dimmable Material Aluminium - PC Diffuser Color 3000K Sandy White / Code 2089-3W Color 4000K Sandy White / Code 2089-4W 23 45 652 Power 8W Input 48V Color Temperature 3000K Lumen 693Lm Cri 80 Dimensions L: 220mm W: 23mm H: 45mm Beam Angle 30o DALI Dimmable Material Aluminium - Acrylic Color Sandy White / Code 2091-3W 220 23 45 *Dimensions Indicated In Millimeters A R C H I T E C T U R A L L I G H T I N G | 4 8 V L I N E A R M A G N E T I C S Y S T E M 67
69 68 Power 12W Input 48V Color Temperature 3000K Lumen 1021Lm Cri 80 Dimensions L: 220mm W: 23mm H: 53mm Beam Angle 30o DALI Dimmable Material Aluminium - Acrylic Color Sandy White / Code 20291-W 23 220 53 69 *Dimensions Indicated In Millimeters A R C H I T E C T U R A L L I G H T I N G | 4 8 V L I N E A R M A G N E T I C S Y S T E M
71 70 37 87 Power 7W Input 48V Color Temperature 3000K | 4000K Lumen 580Lm | 605Lm Cri 80 Dimensions Ø: 37mm H: 87mm Beam Angle 32o DALI Dimmable Material Aluminium Color 3000K Sandy White / Code 20401-WD Color 4000K Sandy White / Code 20404 Power 7W Input 48V Color Temperature 3000K | 4000K Lumen 580Lm | 605Lm Cri 80 Dimensions Ø: 37mm H: 87mm Beam Angle 32o Non Dimmable Material Aluminium Color 3000K Sandy White / Code 20403-W Color 4000K Sandy White / Code 20405 Power 15W Input 48V Color Temperature 3000K | 4000K Lumen 1284Lm | 1312Lm Cri 80 Dimensions Ø: 65mm H: 130mm Beam Angle 24o DALI Dimmable Material Aluminium Color 3000K Sandy White / Code 20412 Color 4000K Sandy White / Code 20414 130 65 *Dimensions Indicated In Millimeters 71 A R C H I T E C T U R A L L I G H T I N G | 4 8 V L I N E A R M A G N E T I C S Y S T E M
73 72 Accessories for All Tracks Color : Black (RAL 9OO5) Wireless Control for 48V Magnetic Tracks Bluetooth DALI Code 20293 Flex Connector with Cable for 48V Magnetic Tracks Code 20105 / Color Black Code 20105-W / Color White Corner Connector for 48V Magnetic Tracks Code 20104 / Color Black Code 20104-W / Color White Power by : Available App on : Feeder for 48V Magnetic Tracks 30cm Cable Available Code 2096 / Color Black Code 2096-W / Color White 112 112 Inner Connector for 48V Magnetic Tracks Code 20103 / Color Black Code 20103-W / Color White 105 143 40 105 105 Remote Driver 100W 48V 5Years Guarantee ON-OFF / Code 20296 DALI KIT / Code 20298 PUSH BUTTON KIT / Code 20301 BLUETOOTH KIT / Code 20304 Remote Driver 150W 48V 5Years Guarantee ON-OFF / Code 20297 DALI KIT / Code 20299 PUSH BUTTON KIT / Code 20302 BLUETOOTH KIT / Code 20305 Remote Driver 60W 48V 5Years Guarantee ON-OFF / Code 20295 DALI KIT / Code 20322 PUSH BUTTON KIT / Code 20300 BLUETOOTH KIT / Code 20303 32 162.5 42.5 37 190 52 88 191 35.5 Remote Drivers DALI Driver for Surface Magnetic Track Power 100W Input 220-240 , 50-60Hz Output 48V Special Feature Fully Integrates Into Track 2085 | 2082 Color Black Guarantee 5Years DALI / Code 22269 292.5 297.5 16 19 DALI Driver for Surface Magnetic Track Power 250W Input 220-240 , 50-60Hz Output 48V Special Feature Fully Integrates Into Track 2082 Color Black Guarantee 5Years DALI / Code 22294 292.5 297.5 16 42 *Dimensions Indicated In Millimeters Feeder for 48V Magnetic Tracks 200cm Cable Available Code 2096-2M / Color Black Code 2096-W2M / Color White 112 *Dimensions Indicated In Millimeters A R C H I T E C T U R A L L I G H T I N G | 4 8 V L I N E A R M A G N E T I C S Y S T E M M A G N E T I C T R A C K 2 0 8 5 M A G N E T I C T R A C K 2 0 8 2 Integrated Drivers Ceiling Box for Cable Connection for 2082 Tracks Dimensions L: 80mm W: 26mm H: 52mm Color Sandy Black / Code 22290 Color Sandy White / Code 22291 80 52 26 Ceiling Box for Cable Connection for 2085 Tracks Dimensions L: 80mm W: 26mm H: 29mm Color Sandy Black / Code 22292 Color Sandy White / Code 22293 80 29 26
75 74 Surface Mount Base with Driver for Surface Magnetic Track Power 100W Input 220-240 , 50-60Hz Output 48V Special Feature Included 48V Feeder Color Sandy White Guarantee 5Years ON-OFF / Code 20306-W DALI KIT / Code 20308-W PUSH BUTTON KIT / Code 20310-W BLUETOOTH KIT / Code 20312-W Surface Mount Base with Driver for Surface Magnetic Track Power 200W Input 220-240 , 50-60Hz Output 48V Special Feature Included 48V Feeder Color Sandy White Guarantee 5Years ON-OFF / Code 20307-W DALI KIT / Code 20309-W PUSH BUTTON KIT / Code 20311-W BLUETOOTH KIT / Code 20313-W 26 562 52 Driver Box for Ceiling Application Surface Mount Base with Driver for Surface Magnetic Track Power 100W Input 220-240 , 50-60Hz Output 48V Special Feature Included 48V Feeder Color Sandy Black Guarantee 5Years ON-OFF / Code 20306-B DALI KIT / Code 20308-B PUSH BUTTON KIT / Code 20310-B BLUETOOTH KIT / Code 20312-B Surface Mount Base with Driver for Surface Magnetic Track Power 200W Input 220-240 , 50-60Hz Output 48V Special Feature Included 48V Feeder Color Sandy Black Guarantee 5Years ON-OFF / Code 20307-B DALI KIT / Code 20309-B PUSH BUTTON KIT / Code 20311-B BLUETOOTH KIT / Code 20313-B 26 562 52 Driver Box for Pendant Application Pendant Base with Driver for Surface Magnetic Track Power 100W Input 220-240 , 50-60Hz Output 48V Special Feature 200cm Cable Available - 48V Feeder Color Sandy Black Guarantee 5Years ON-OFF / Code 20314-B DALI KIT / Code 20316-B PUSH BUTTON KIT / Code 20318-B BLUETOOTH KIT / Code 20320-B Pendant Base with Driver for Surface Magnetic Track Power 200W Input 220-240 , 50-60Hz Output 48V Special Feature 200cm Cable Available - 48V Feeder Color Sandy Black Guarantee 5Years ON-OFF / Code 20315-B DALI KIT / Code 20317-B PUSH BUTTON KIT / Code 20319-B BLUETOOTH KIT / Code 20321-B 26 562 52 Pendant Base with Driver for Surface Magnetic Track Power 100W Input 220-240 , 50-60Hz Output 48V Special Feature 200cm Cable Available - 48V Feeder Color Sandy White Guarantee 5Years ON-OFF / Code 20314-W DALI KIT / Code 20316-W PUSH BUTTON KIT / Code 20318-W BLUETOOTH KIT / Code 20320-W Pendant Base with Driver for Surface Magnetic Track Power 200W Input 220-240 , 50-60Hz Output 48V Special Feature 200cm Cable Available - 48V Feeder Color Sandy White Guarantee 5Years ON-OFF / Code 20315-W DALI KIT / Code 20317-W PUSH BUTTON KIT / Code 20319-W BLUETOOTH KIT / Code 20321-W 26 562 52 *Dimensions Indicated In Millimeters *Dimensions Indicated In Millimeters A R C H I T E C T U R A L L I G H T I N G | 4 8 V L I N E A R M A G N E T I C S Y S T E M
77 76 7 CASAMBI READY wireless control for DALI luminaires The Zambelis 48V tracks are compatible with CASAMBI control system, which permits bidirectional communication between control device and luminaires, making it possible for the user to create scenes, regulate the system from smart devices, etc. With the CASAMBI control system and its Control wireless variants, the user has total control over the installation, with all the features available in low voltage alternatives. The 48V system does not mean relinquishing the leading edge in control for architectural lighting. Power by : Available App on : AC input 48Vdc POWER SUPPLY LIVE-END CONNECTOR DALI SYSTEM A R C H I T E C T U R A L L I G H T I N G | 4 8 V L I N E A R M A G N E T I C S Y S T E M D E S I G N Y O U R O W N L I G H T I N G . . .
79 78 79 4 8 V R O U N D E D R E C T A N G L E M A G N E T I C S Y S T E M | p . 0 7 8 - 0 9 1
81 80 SURFACE | PENDANT Track : 1m / 2m / 3m 22273B-1 Sandy Black 1m 22273B-2 Sandy Black 2m Track Code Color Size 22273B-3 Sandy Black 3m 23 28 56 SURFACE | PENDANT Curved Track Dimensions Ø: 900mm L: 706mm Material Aluminium Color Sandy Black Code 22277 SURFACE | PENDANT Curved Track Dimensions Ø: 600mm L: 471mm Material Aluminium Color Sandy Black Code 22275 90® D:900 R:450 100 100 90® D:600 R:300 100 100 23 28 56 23 28 56 A R C H I T E C T U R A L L I G H T I N G | 4 8 V R O U N D E D R E C T A N G L E M A G N E T I C S Y S T E M 81 *Dimensions Indicated In Millimeters
83 82 TRIMLESS Track : 1m / 2m / 3m 22274B-1 Sandy Black 1m 22274B-2 Sandy Black 2m Track Code Color Size 22274B-3 Sandy Black 3m 23 55 13 55 TRIMLESS Curved Track Dimensions Ø: 900mm L: 906mm Material Aluminium Color Sandy Black Code 22278 TRIMLESS Curved Track Dimensions Ø: 600mm L: 670mm Material Aluminium Color Sandy Black Code 22276 90® D:900 R:450 100 100 90® D:600 R:300 100 100 23 55 13 55 23 55 13 55 A R C H I T E C T U R A L L I G H T I N G | 4 8 V R O U N D E D R E C T A N G L E M A G N E T I C S Y S T E M 83 *Dimensions Indicated In Millimeters
85 84 Power 8W Input 48V Color Temperature 3000K Lumen 780Lm Cri 80 Dimensions Curved: 900mm Ø: 45mm L: 110mm Beam Angle 36o DALI Dimmable Material Aluminium - Acrylic Color Sandy Black / Code 22101 Lights for D: 900mm Curved Tracks Power 8W Input 48V Color Temperature 3000K Lumen 780Lm Cri 80 Dimensions Curved: 900mm L: 195mm W: 23mm H: 45mm Beam Angle 36o DALI Dimmable Material Aluminium - Acrylic Color Sandy Black / Code 22099 195 23 45 110 45 Power 8W Input 48V Color Temperature 3000K Lumen 780Lm Cri 80 Dimensions Curved: 900mm L: 195mm W: 23mm H: 45mm Beam Angle 120o DALI Dimmable Material Aluminium - Acrylic Color Sandy Black / Code 22100 195 23 45 Power 2W Input 48V Color Temperature 3000K Lumen 170Lm Cri 80 Dimensions Curved: 900mm L: 30mm W: 23mm H: 45mm Beam Angle 25o Non Dimmable Material Acrylic Color Sandy Black / Code 22107 30 23 45 Power 8W Input 48V Color Temperature 3000K Lumen 780Lm Cri 80 Dimensions Curved: 600mm L: 195mm W: 23mm H: 45mm Beam Angle 36o DALI Dimmable Material Aluminium - Acrylic Color Sandy Black / Code 22092 195 23 45 Power 8W Input 48V Color Temperature 3000K Lumen 780Lm Cri 80 Dimensions Curved: 600mm Ø: 45mm L: 110mm Beam Angle 36o DALI Dimmable Material Aluminium - Acrylic Color Sandy Black / Code 22094 Power 8W Input 48V Color Temperature 3000K Lumen 780Lm Cri 80 Dimensions Curved: 600mm L: 195mm W: 23mm H: 45mm Beam Angle 120o DALI Dimmable Material Aluminium - Acrylic Color Sandy Black / Code 22093 195 23 45 110 45 Lights for D: 600mm Curved Tracks 85 *Dimensions Indicated In Millimeters
87 86 Power 12W Input 48V Color Temperature 3000K Lumen 779Lm Cri 80 Dimensions L: 328mm W: 23mm H: 45mm Beam Angle 120o DALI Dimmable Material Aluminium - PC Diffuser Color Sandy Black / Code 2087 Power 12W Input 48V Color Temperature 3000K Lumen 779Lm Cri 80 Dimensions L: 328mm W: 23mm H: 45mm Beam Angle 120o Non Dimmable Material Aluminium - PC Diffuser Color Sandy Black / Code 2086 328 23 45 Power 20W Input 48V Color Temperature 2700K | 3000K | 4000K Lumen 1650Lm | 1669Lm | 1897Lm Cri 80 Dimensions L: 652mm W: 23mm H: 45mm Beam Angle 120o DALI Dimmable Material Aluminium - PC Diffuser Color 3000K Sandy Black / Code 2089 Color 4000K Sandy Black / Code 2089-4B Color 2700K Sandy Black / Code 2089-27B Power 20W Input 48V Color Temperature 3000K Lumen 1669Lm Cri 80 Dimensions L: 652mm W: 23mm H: 45mm Beam Angle 120o Not Dimmable Material Aluminium - PC Diffuser Color Sandy Black / Code 2088 23 45 652 Power 12W Input 48V Color Temperature 3000K Lumen 1021Lm Cri 80 Dimensions L: 220mm W: 23mm H: 53mm Beam Angle 30o Non Dimmable Material Aluminium - Acrylic Color Sandy Black / Code 20290 Power 12W Input 48V Color Temperature 3000K Lumen 1021Lm Cri 80 Dimensions L: 220mm W: 23mm H: 53mm Beam Angle 30o DALI Dimmable Material Aluminium - Acrylic Color Sandy Black / Code 20291 23 220 53 Power 8W Input 48V Color Temperature 3000K Lumen 693Lm Cri 80 Dimensions L: 220mm W: 23mm H: 45mm Beam Angle 30o Non Dimmable Material Aluminium - Acrylic Color Sandy Black / Code 2090 Power 8W Input 48V Color Temperature 2700K | 3000K | 4000K Lumen 675Lm | 693Lm | 713Lm Cri 80 Dimensions L: 220mm W: 23mm H: 45mm Beam Angle 30o DALI Dimmable Material Aluminium - Acrylic Color 3000K Sandy Black / Code 2091 Color 4000K Sandy Black / Code 2091-4B Color 2700K Sandy Black / Code 2091-27B 220 23 45 A R C H I T E C T U R A L L I G H T I N G | 4 8 V R O U N D E D R E C T A N G L E M A G N E T I C S Y S T E M *Dimensions Indicated In Millimeters *Dimensions Indicated In Millimeters
89 88 Power 7W Input 48V Color Temperature 2700K | 3000K Lumen 565Lm | 580Lm Cri 80 Dimensions Ø: 37mm H: 87mm Beam Angle 32o DALI Dimmable Material Aluminium Color 3000K Sandy Black / Code 20400-BD Color 2700K Sandy Black / Code 20407-BD Power 7W Input 48V Color Temperature 3000K | 4000K Lumen 580Lm | 605Lm Cri 80 Dimensions Ø: 37mm H: 87mm Beam Angle 32o Non Dimmable Material Aluminium Color 3000K Sandy Black / Code 20402-B Color 4000K Sandy Black / Code 20406 37 87 Power 15W Input 48V Color Temperature 3000K | 4000K Lumen 1284Lm | 1312Lm Cri 80 Dimensions Ø: 65mm H: 130mm Beam Angle 24o DALI Dimmable Material Aluminium Color 3000K Sandy Black / Code 20413 Color 4000K Sandy Black / Code 20415 Power 15W Input 48V Color Temperature 3000K | 4000K Lumen 1284Lm | 1312Lm Cri 80 Dimensions Ø: 65mm H: 130mm Beam Angle 24o Non Dimmable Material Aluminium Color 3000K Sandy Black / Code 20410 Color 4000K Sandy Black / Code 20411 130 65 Power 5W Input 48V Color Temperature 3000K Lumen 414Lm Cri 80 Dimensions Ø: 26mm H: 125mm Beam Angle 24o DALI Dimmable Material Aluminium Color Sandy Black / Code 2094 Power 5W Input 48V Color Temperature 3000K Lumen 414Lm Cri 80 Dimensions Ø: 26mm H: 125mm Beam Angle 24o Non Dimmable Material Aluminium Color Sandy Black / Code 2093 26 125 Power 15W Input 48V Color Temperature 3000K Lumen 1225Lm Cri 80 Dimensions Ø: 45mm H: 200mm Beam Angle 24o DALI Dimmable Material Aluminium Color Sandy Black / Code 2095-D Power 15W Input 48V Color Temperature 3000K Lumen 1225Lm Cri 80 Dimensions Ø: 45mm H: 200mm Beam Angle 24o Non Dimmable Material Aluminium Color Sandy Black / Code 2095 200 45 A R C H I T E C T U R A L L I G H T I N G | 4 8 V R O U N D E D R E C T A N G L E M A G N E T I C S Y S T E M *Dimensions Indicated In Millimeters *Dimensions Indicated In Millimeters
91 90 Accessories for All Tracks Feeder for 48V Magnetic Tracks Code 2096 / Color Black 112 Inner Connector for 48V Magnetic Tracks Code 20103 / Color Black 105 Wireless Control for 48V Magnetic Tracks Bluetooth DALI Code 20293 Power by : Available App on : 143 40 Remote Driver 60W 48V 5Years Guarantee ON-OFF / Code 20295 DALI KIT / Code 20322 PUSH BUTTON KIT / Code 20300 BLUETOOTH KIT / Code 20303 32 162.5 42.5 Remote Driver 100W 48V 5Years Guarantee ON-OFF / Code 20296 DALI KIT / Code 20298 PUSH BUTTON KIT / Code 20301 BLUETOOTH KIT / Code 20304 37 190 52 Remote Driver 150W 48V 5Years Guarantee ON-OFF / Code 20297 DALI KIT / Code 20299 PUSH BUTTON KIT / Code 20302 BLUETOOTH KIT / Code 20305 88 191 35.5 Remote Drivers Feeder for 48V Magnetic Tracks 200cm Cable Available Code 2096-2M / Color Black 112 Flex Connector with Cable for 48V Magnetic Tracks Code 20105 / Color Black 112 Suspension Kit (2pcs) / Adjustable Wire 2m Material Metal Code 22121 End Cap Material Metal Color Black / Code 22097-E Curved Mechanic Connector Material Metal Color Black / Code 22097-C Driver Box for Ceiling Application Surface Mount Base with Driver for Surface Magnetic Track Power 100W Input 220-240 , 50-60Hz Output 48V Special Feature Included 48V Feeder Color Sandy Black Guarantee 5Years ON-OFF / Code 20306-B DALI KIT / Code 20308-B PUSH BUTTON KIT / Code 20310-B BLUETOOTH KIT / Code 20312-B Surface Mount Base with Driver for Surface Magnetic Track Power 200W Input 220-240 , 50-60Hz Output 48V Special Feature Included 48V Feeder Color Sandy Black Guarantee 5Years ON-OFF / Code 20307-B DALI KIT / Code 20309-B PUSH BUTTON KIT / Code 20311-B BLUETOOTH KIT / Code 20313-B 26 562 52 Driver Box for Pendant Application Pendant Base with Driver for Surface Magnetic Track Power 100W Input 220-240 , 50-60Hz Output 48V Special Feature 200cm Cable Available - 48V Feeder Color Sandy Black Guarantee 5Years ON-OFF / Code 20314-B DALI KIT / Code 20316-B PUSH BUTTON KIT / Code 20318-B BLUETOOTH KIT / Code 20320-B Pendant Base with Driver for Surface Magnetic Track Power 200W Input 220-240 , 50-60Hz Output 48V Special Feature 200cm Cable Available - 48V Feeder Color Sandy Black Guarantee 5Years ON-OFF / Code 20315-B DALI KIT / Code 20317-B PUSH BUTTON KIT / Code 20319-B BLUETOOTH KIT / Code 20321-B 26 562 52 A R C H I T E C T U R A L L I G H T I N G | 4 8 V R O U N D E D R E C T A N G L E M A G N E T I C S Y S T E M *Dimensions Indicated In Millimeters *Dimensions Indicated In Millimeters
93 92 93 4 8 V C I R C L E S - C U R V E D M A G N E T I C S Y S T E M | p . 0 9 2 - 1 0 5
95 94 SURFACE | PENDANT Track : 1m / 2m / 3m A R C H I T E C T U R A L L I G H T I N G | 4 8 V C I R C L E S - C U R V E D M A G N E T I C S Y S T E M SURFACE | PENDANT Curved Track Dimensions Ø: 1200mm L: 1252.5mm Material Aluminium Color Sandy Black Code 22102 SURFACE | PENDANT Curved Track Dimensions Ø: 600mm L: 628mm Material Aluminium Color Sandy Black Code 22090 SURFACE | PENDANT Curved Track Dimensions Ø: 900mm L: 942.5mm Material Aluminium Color Sandy Black Code 22097 22273B-1 Sandy Black 1m 22273B-2 Sandy Black 2m Track Code Color Size 22273B-3 Sandy Black 3m 23 28 56 120® D:1200 R:600 120® D:900 R:450 120® D:600 R:300 23 28 56 23 28 56 23 28 56 95 *Dimensions Indicated In Millimeters
97 96 TRIMLESS Track : 1m / 2m / 3m 22274B-1 Sandy Black 1m 22274B-2 Sandy Black 2m Track Code Color Size 22274B-3 Sandy Black 3m 23 55 13 55 TRIMLESS Curved Track Dimensions Ø: 1200mm L: 1252.5mm Material Aluminium Color Sandy Black Code 22103 TRIMLESS Curved Track Dimensions Ø: 600mm L: 628mm Material Aluminium Color Sandy Black Code 22091 TRIMLESS Curved Track Dimensions Ø: 900mm L: 942.5mm Material Aluminium Color Sandy Black Code 22098 120® D:1200 R:600 120® D:900 R:450 120® D:600 R:300 23 55 13 55 23 55 13 55 23 55 13 55 A R C H I T E C T U R A L L I G H T I N G | 4 8 V C I R C L E S - C U R V E D M A G N E T I C S Y S T E M 97 *Dimensions Indicated In Millimeters
99 98 Power 8W Input 48V Color Temperature 3000K Lumen 780Lm Cri 80 Dimensions Curved: 900mm Ø: 45mm L: 110mm Beam Angle 36o DALI Dimmable Material Aluminium - Acrylic Color Sandy Black / Code 22101 Lights for D: 900mm Curved Tracks - Circle Power 8W Input 48V Color Temperature 3000K Lumen 780Lm Cri 80 Dimensions Curved: 900mm L: 195mm W: 23mm H: 45mm Beam Angle 36o DALI Dimmable Material Aluminium - Acrylic Color Sandy Black / Code 22099 195 23 45 110 45 Power 8W Input 48V Color Temperature 3000K Lumen 780Lm Cri 80 Dimensions Curved: 900mm L: 195mm W: 23mm H: 45mm Beam Angle 120o DALI Dimmable Material Aluminium - Acrylic Color Sandy Black / Code 22100 195 23 45 Power 2W Input 48V Color Temperature 3000K Lumen 170Lm Cri 80 Dimensions Curved: 900mm L: 30mm W: 23mm H: 45mm Beam Angle 25o Non Dimmable Material Acrylic Color Sandy Black / Code 22107 30 23 45 Power 8W Input 48V Color Temperature 3000K Lumen 780Lm Cri 80 Dimensions Curved: 600mm L: 195mm W: 23mm H: 45mm Beam Angle 36o DALI Dimmable Material Aluminium - Acrylic Color Sandy Black / Code 22092 195 23 45 Power 8W Input 48V Color Temperature 3000K Lumen 780Lm Cri 80 Dimensions Curved: 600mm Ø: 45mm L: 110mm Beam Angle 36o DALI Dimmable Material Aluminium - Acrylic Color Sandy Black / Code 22094 Power 8W Input 48V Color Temperature 3000K Lumen 780Lm Cri 80 Dimensions Curved: 600mm L: 195mm W: 23mm H: 45mm Beam Angle 120o DALI Dimmable Material Aluminium - Acrylic Color Sandy Black / Code 22093 195 23 45 110 45 Lights for D: 600mm Curved Tracks - Circle Lights for D: 1200mm Curved Tracks Circle Power 8W Input 48V Color Temperature 3000K Lumen 780Lm Cri 80 Dimensions Curved: 1200mm L: 195mm W: 23mm H: 45mm Beam Angle 36o DALI Dimmable Material Aluminium - Acrylic Color Sandy Black / Code 22104 195 23 45 Power 8W Input 48V Color Temperature 3000K Lumen 780Lm Cri 80 Dimensions Curved: 1200mm Ø: 45mm L: 110mm Beam Angle 36o DALI Dimmable Material Aluminium - Acrylic Color Sandy Black / Code 22106 Power 8W Input 48V Color Temperature 3000K Lumen 780Lm Cri 80 Dimensions Curved: 1200mm L: 195mm W: 23mm H: 45mm Beam Angle 120o DALI Dimmable Material Aluminium - Acrylic Color Sandy Black / Code 22105 195 23 45 110 45 Accesorries for Curved Tracks End Cap Material Metal Color Black / Code 22097-E Curved Mechanic Connector Material Metal Color Black / Code 22097-C Feeder for 48V Curved Magnetic Tracks 30cm Cable Available Surface | Trimless Application Code 22095 / Color Black Flex Connector for 48V Curved Magnetic Tracks Code 22096 / Color Black Feeder for 48V Curved Magnetic Tracks 200cm Cable Available Pendant Application Code 22120 / Color Black Suspension Kit (2pcs) / Adjustable Wire 2m Material Metal Code 22121 *Dimensions Indicated In Millimeters
101 100 *Dimensions Indicated In Millimeters Remote Driver 100W 48V 5Years Guarantee ON-OFF / Code 20296 DALI KIT / Code 20298 PUSH BUTTON KIT / Code 20301 BLUETOOTH KIT / Code 20304 37 190 52 Remote Driver 150W 48V 5Years Guarantee ON-OFF / Code 20297 DALI KIT / Code 20299 PUSH BUTTON KIT / Code 20302 BLUETOOTH KIT / Code 20305 88 191 35.5 Remote Driver 60W 48V 5Years Guarantee ON-OFF / Code 20295 DALI KIT / Code 20322 PUSH BUTTON KIT / Code 20300 BLUETOOTH KIT / Code 20303 32 162.5 42.5 Remote Drivers for Curved Tracks - Circle A R C H I T E C T U R A L L I G H T I N G | 4 8 V C I R C L E S - C U R V E D M A G N E T I C S Y S T E M *Dimensions Indicated In Millimeters
103 102 Ceiling Driver Box for Pendant Curved Tracks - Circles Pendant Base with Driver for Surface Magnetic Track Power 100W Input 220-240 , 50-60Hz Output 48V Special Feature 200cm Cable Available - 48V Feeder Color Sandy Black Guarantee 5Years ON-OFF / Code 22284 BLUETOOTH KIT / Code 22282 Pendant Base with Driver for Surface Magnetic Track Power 200W Input 220-240 , 50-60Hz Output 48V Special Feature 200cm Cable Available - 48V Feeder Color Sandy Black Guarantee 5Years ON-OFF / Code 22286 BLUETOOTH KIT / Code 22280 26 562 52 26 562 52 Pendant Base with Driver for Surface Magnetic Track Power 100W Input 220-240 , 50-60Hz Output 48V Special Feature 200cm Cable Available - 48V Feeder Color Sandy Black Guarantee 5Years DALI KIT / Code 22285 PUSH BUTTON KIT / Code 22281 Pendant Base with Driver for Surface Magnetic Track Power 200W Input 220-240 , 50-60Hz Output 48V Special Feature 200cm Cable Available - 48V Feeder Color Sandy Black Guarantee 5Years DALI KIT / Code 22287 PUSH BUTTON KIT / Code 22279 A R C H I T E C T U R A L L I G H T I N G | 4 8 V C I R C L E S - C U R V E D M A G N E T I C S Y S T E M *Dimensions Indicated In Millimeters
105 104 Magnetic Surface | Pendant Circle Dimensions Ø: 600mm Material Aluminium Color Sandy Black / Code 22270 Magnetic Surface | Pendant Circle Dimensions Ø: 900mm Material Aluminium Color Sandy Black / Code 22271 Magnetic Surface | Pendant Circle Dimensions Ø: 1200mm Material Aluminium Color Sandy Black / Code 22272 *Dimensions Indicated In Millimeters A R C H I T E C T U R A L L I G H T I N G | 4 8 V C I R C L E S - C U R V E D M A G N E T I C S Y S T E M Suspension Kit (3pcs) for Magnetic Circles Adjustable Wire 2m Material Metal Code 22283 23 28 56 600 23 28 56 23 28 56 900 1200
107 106 2 4 V M I N I S U R F A C E M A G N E T I C S Y S T E M | p . 1 0 6 - 1 1 5
109 108 Smaller, Lighter and Slimmer... R9>90, Closer to True Colors R9 is the index to present the color of Red. Red is a very important icon to many objects like photography, textiles, bones and skins. For human eyes, the red is a key reference to distinguish the real true colors. A higher R9 index can better present the true colors. MINI TRACK, with R9 higher than 90, can better present the world closer to true colors. CRI>90, High Quality Light Output Because ambient light produces Colors differently, the Color rendering index (CRI) is used as reference. The CRI indicates the ratio by which the illuminated object or the illuminated area deviates from the maximum value of 100 (daylight). MINI TRACK has an impressively high CRI of 90, which means that it comes very close to natural light and is suitable for Color-sensitive applications such as display cases and special exhibition spaces. The material quality, feel, and Color authenticity of merchandise and artworks need to be rendered as accurately as possible to accentuate object's value. The especially small light surface of the LEDs and high light density allow the luminaires to perfectly reflect the three-dimensionality of amorphous surfaces. Products with a CRI of 90 are perfect for high-end sales floors and art settings. Attractive Color Presentation... A R C H I T E C T U R A L L I G H T I N G | 2 4 V M I N I S U R F A C E M A G N E T I C S Y S T E M
111 110 Mini Linear Light Mini Fix Spots Mini Adjustable Eyes Power 1.5W Input 24V Color Temperature 3000K Lumen 80Lm Cri 97 Dimensions L: 50mm W: 11mm H: 36mm Spot Ø: 15mm H: 27mm Beam Angle 20o DALI Dimmable Material Aluminium - Acrilyc Special Feature Movable Spot Color Black Matt / Code 22251 Power 2.6W Input 24V Color Temperature 3000K Lumen 160Lm Cri 97 Dimensions L: 100mm W: 11mm H: 36mm Spots Ø: 15mm H: 27mm Beam Angle 20o DALI Dimmable Material Aluminium - Acrilyc Special Feature Movable Spots Color Black Matt / Code 22252 Power 2.5W Input 24V Color Temperature 3000K Lumen 150Lm Cri 97 Dimensions L: 150mm W: 11mm H: 9mm Beam Angle 30o DALI Dimmable Material Aluminium - Acrilyc Color Black Matt / Code 22253 *Dimensions Indicated In Millimeters 50 100 150 27 27 A R C H I T E C T U R A L L I G H T I N G | 2 4 V M I N I S U R F A C E M A G N E T I C S Y S T E M 9 9 9
