3 2 Greece , Attica , Keratea , Kivouri Postal: 19001 , P.O. box: 4791 Tel.: (+30) 22990 63518-19 | Fax: (+30) 22990 63521 info@zambelislights.gr | zambelislights.gr info@alphabetlights.com I alphabetlights.com ZAMPELIS S.A. : _A to...Zambelis > ALPHABET comes with the signature and know-how of Zambelis Lights, one of the most dynamic, modern, Greek companies, specializing in the wholesale of professional architectural and decorative lighting. Founded in 1967 in Greece, Zambelis Lights has 55 years of experience in manufacturing high quality products, with innovative designs, driven by customers insights and a dedicated R&D department. Since 2017, this experience is shared beyond borders, as the company has established its international presence, with exports to both EU and non EU countres. Index <p:_O3> : _Section // ALPHA > 24mm Profiles <p:_10> 34mm Profiles <p:_40> 48mm Profiles <p:_84> 50mm Profiles <p:_148> 52mm Profiles <p:_170> 78mm Profiles <p:_192> : _Section // BETA > : _Section // GAMMA > 3 Circuite Track System <p:_234> Downlights <p:_244> Acoustic <p:_282> 48V Magnetic System <p:_24>
4 5 : _In-House Design> You could consider it a passion to continuously surprise and inspire people with new lighting languages. An essential attribute in ALPHABET creativeprocess is the extensive in-house design, development, testing, engineering, and manufacturing of all products. This enables us to achieve our short idea-to-market philosophy, resulting in extensive new collections being launched on a regular basis. Our in-house design team crafts cuttingedge lighting solutions, that combine an architectural design language, a minimalist approach, and a boldness that challenges the boundaries of technology. In-house design is the foundation of our product portfolio, but we also love to collaborate with architects and designers, from different industries to create and innovate. ALPHABET’s extensive design and R&D teams are constantly discovering future trends, both in terms of design and use of materials, whilst remaining focused on the power of imagination. We are focused on the detail. The looks, how a fixture moves, how it can be specified and installed, the ease of enjoying the light and so much more. : _About Alphabet > The ALPHABET team is motivated by your passion in light, speaks your “language” and has the know-how and background to make things work for you. After all, ALPHABET comes with the signture and know-how of Zambelis Lights, one of the most dynamic, modern, Greek companies, specializing in the wholesale of professional architectural and decorative lighting. : _Behind the Letters > ALPHABET is more than a lighting brand. It is an archetypal code of communication among lighting exprts. It is a lighting concept. It is a code we share together to “script” light and achieve the perfect fusion of decorative and architectural in lighting. : _Talk “alphabet” to me > Complex lighting combinations do not require complex ordering processes. ALPHABET can make it easy for you to code what you need...kind of like scripting light (yes, it is not our motto without a reason). So...give it a try and discover how to talk “alphabet” to us. : _Create Your Code > We have chosen to name our lighting solutions after alphabet letters. Let’s say we see lighting projects - or lighting challenges - like crosswords. Choosing the right “letter”, you can fill every gap in the crossword and help the project make sense. /scripting_light < >
: _Research and Development> Our company has advanced solar panels to have autonomy of operation of our entire factory only from the solar energy that is collected. By manufacturing our personal solar panels we ensure our continuous operation and energy savings. ALPHABET and Zambelis Lights contributing in practice to energy recovery through the use of renewable energy sources. Continuous research and development help us to dissolve and produce new methods of construction and use of lighting that will help reduce energy degradation. : _Cutting-Edge LED Technology > As luminaire designers and manufacturers, we always strive to create the best possible thermal conditions in the luminaire, to ensure the LEDs operate at their optimum. From the design of the LED circuit boards and heat sink, to the selection of materials, to the assembly process and installation techniques… everything is engineered to reach optimal life expectancy and maximum efficiency. By partnering with the best LED suppliers in the world, we ensure a consistent LED selection with colour uniformity across all product ranges. A minimum of MacAdam Step 2 is standard throughout our collection, whilst many of our new collection LEDs offer MacAdam Step 3. : _Certified Laboratory Testing> Product quality and safety testing within our laboratory conform to the International Electrotechnical Commission standards. An important feature in ALPHABET’s creative process is the use of state-of-the-art development techniques. The intensive use of 3D printing,goniophotometer measurement and an in-house third party recognised lab.efficient and ‘first time right’ development process. As such, it is an essential attribute in the company’s short idea-to-market philosophy. Throughout the entire production process ALPHABET distinguishes itself by handling the strictest quality parameters, to ensure products and services are designed and produced to exceed customer requirements. Every step in the production process has a routine quality procedure, covering both product quality and testing. Every single product that leaves ALPHABET, has been inspected and tested thoroughly, resulting in minimal returns and maximum efficiency. 7 6 /scripting_light < >
8 9 The curtain of the Light + Building 22 exhibition has fallen! At our booths, visitors had the opportunity to meet the family of Zambelis Lights and ALPHABET by Zambelis up close and learn about the possibilities of designing and implementing high-end residential-professional and architectural lighting that we offer! A big thank you to the customers, partners, and everyone who visited our booths for their interest, and an extra thank you to the awesome and tireless family of Zambelis Lights and ALPHABET by Zambelis who participated in the design, implementation, and support of the booths! But also for those who were not able to visit our booths in person, we are always here to help your ideas come true!
10 11 In the TAF24 case, a tube combines all that attributes with light, bringing into life a modern, minimalistic lighting system with endless, playful combinations. Discover TAF24 Family /scripting_light < >
12 13 A tube connects. A tube transfers. A tube encourages the flow. In the TAF24 case, a tube combines all that attributes with light, bringing into life a modern, minimalistic lighting system with endless, playful combinations. TAF24, the new, innovative lighting fixture by Alphabet by Zambelis, is an extruded aluminum tube, consisting of numerous lighting instruments, which can be combined in infinite ways in order to create unique lighting installations. Interior lighting design has now a modular, customizable ally, as TAF24 can transform into any type of lighting fixture: from pendant, to wall mounted, wall-to-wall, and so on. All TAF24 lighting instruments are 355º rotatable. Colors and materials can be applied to preference, in order to achieve the perfect fusion of decorative & architectural in lighting. System TAF24 comes as all the Alphabet products with a guaranty of 5 years and equipped with the latest generation of well known LED brands with small color tolerance MacAdam 3. The system needs 24V power supply and can be supplied from one point. Available 24V drivers,On-Off , DALI. /scripting_light < >
14 15 Techical Specifications & Constraints Open Edit Length Available in any length from 30cm to 250cm CCT 2200K and 2700K 3000K and 4000K Optionally, Tunable White and RGB CRi Available in CRi80 or CRi90 UGR Low UGR <16 A tube connects. A tube transfers. A tube encourages the flow. In the “T24” case, a tube combines all that attributes with light, bringing into life a modern, minimalistic lighting system with endless, playful combinations. “T24”, the new, innovative lighting fixture by Alphabet by Zambelis, is an extruded aluminum tube, consisting of numerous lighting instruments, which can be combined in infinite ways in order to create unique lighting installations. Interior lighting design has now a modular, customizable ally, as “T24” can transform into any type of lighting fixture: from pendant, to wall mounted, wall-to-wall, and so on. All “T24” lighting instruments are 355º rotatable. Colors and materials can be applied to preference, in order to achieve the perfect fusion of decorative & architectural in lighting. System ‘TAF24’ comes as all the Alphabet products with a guaranty of 5 years and equipped with the latest generation of well known LED brands with small color tolerance MacAdam 3. The system needs 24V power supply and can be supplied from one point. Available 24V drivers,On-Off , DALI. TAF24 ALPHA Select technical features to configure your code. Length* LED Strip Type CRi CCT Optic/Diffuser Driver Body Colour 030 = 30cm 050 = 50cm 100 = 100cm 150 = 150cm 250 = 250cm 3 = OSRAM TEC Flex TF1500S 4 = LINEAR light Flex POWER 4000 5 = OSRAM TEC Flex TUNNABLE WHITE 6 = OSRAM TEC Flex RGB 8 = 80 9 = 90 27 = 2700K 30 = 3000K 40 = 4000K 11 = TUNABLE WHITE 12 = RGB P = OPAL O = ON-OFF D = DALI V = 1-10V W = WHITE B = BLACK S = SPECIAL RAL *Open Edit Length min 30cm - max 250cm. Your Code : T24A Length Led Strip Type CRi CCT Optic/ Diffuser Driver Body Colour Example Code : T24A 250 5 9 30 P D B Spots “Skewer” spots Giota31 or Giota34 Incorporated into the linear tube forms LED Drivers 24V On-Off 24V DALI 24V 1-10V Optics / Diffusers Diffusers and Louver to reduce UGR in Taf Alpha 12°, 24° or 36° on Spots Body and Cover Colours White | Black | Gold | Copper | Your Special RAL Select technical features to configure your code. Length* Body Colour 030 = 30cm 050 = 50cm 100 = 100cm 150 = 150cm 250 = 250cm W = WHITE B = BLACK S = SPECIAL RAL *Open Edit Length min 30cm - max 250cm. Your Code : T24L Length Body Colours TAF24 LAMDA OSRAM TEC Flex TF1500S LINEAR light Flex POWER 4000 OSRAM TEC Flex TUNNABLE WHITE OSRAM TEC Flex RGB LED Strips ID Boarder LED Strip Type CCT LOR Lm/m Lm/W 4000K 4000K 4000K 4000K 50 50 50 50 1660 3800 1940 400 163,3 133 144 33,3 Ø24 Ø24 LED Strip Types OSRAM TEC Flex TF1500S LINEAR light Flex POWER 4000 OSRAM TEC Flex TUNNABLE WHITE OSRAM TEC Flex RGB
16 TAF24 GIOTA34 17 Your Code : T24I34 Length Number of Spots Wattage CRi CCT Optic Driver Body Colour Cover Colour Select technical features to configure your code. Length* Number of Spots** Wattage CRi CCT Optic Driver Body Colour 030 = 30cm 035 = 35cm 050 = 50cm 100 = 100cm 150 = 150cm 200 = 200cm 1 = 1 Spot 2 = 2 Spots 6 = 6 Spots 7 = 7W 8 = 80 9 = 90 27 = 2700K 30 = 3000K 40 = 4000K N = 15® R = 36® O = 24® O = ON-OFF D = DALI V = 1-10V W = WHITE B = BLACK S = SPECIAL RAL *Open Edit Length min 30cm - max 200cm || **Number of Spots min 1spot - max 6spots / max 3spots per meter. Cover Colour W = WHITE B = BLACK O = GOLD C = COPPER S = SPECIAL RAL Segment | T24I34 | Ø40mm TAF24 GIOTA31 Segment | T24I31 | Ø30mm Your Code : T24I31 Length Number of Spots Wattage CRi CCT Optic Driver Body Colour Cover Colour Select technical features to configure your code. Length* Number of Spots** Wattage CRi CCT Optic Driver Body Colour 030 = 30cm 035 = 35cm 050 = 50cm 100 = 100cm 150 = 150cm 200 = 200cm 1 = 1 Spot 2 = 2 Spots 6 = 6 Spots 9 = 9W 8 = 80 9 = 90 27 = 2700K 30 = 3000K 40 = 4000K R = 36® O = 24® O = ON-OFF D = DALI V = 1-10V W = WHITE B = BLACK S = SPECIAL RAL *Open Edit Length min 30cm - max 200cm || **Number of Leds min 1spot - max 6spots / max 3spots per meter. Cover Colour W = WHITE B = BLACK O = GOLD C = COPPER S = SPECIAL RAL 90 *Dimensions Indicated In Millimeters Ø40 154 Ø30 Ø24 Ø24
18 19 *Dimensions Indicated In Millimeters Your Code : T24PD Driver Wattage TAF24 PENDANT BOX DRIVER 26 562 52 Your Code : T24RD Wattage Driver REMOTE DRIVER KIT 32 162.5 42.5 Select technical features to configure your code. Wattage 100 = 100W 150 = 150W Driver Body Colour O = ON-OFF D = DALI P = PUSH V = 1-10V B = BLUETOOTH W = WHITE B = BLACK S = SPECIAL RAL Your Code : T24J Model Body Color T24JD | TAF24 JOINT DOWN | Ø24 x 100 x 100mm code D T24JU | TAF24 JOINT UP | Ø24 code U code A T24JA | TAF24 JOINT 90® | Ø24 x 100 x 100mm 100 100 100 100 100 100 562 52 26 . . T24JL | TAF24 LINEAR CONNECTOR | Ø24 code L 200 T24JE | TAF24 END CAP | Ø24 code E 100 T24JK | TAF24 LINEAR CONNECTOR WITH FEEDER | Ø24 code K T24JP | TAF24 FEEDER | Ø24 code P 100 200 code F T24JF | TAF24 JOINT WITH FEEDER 90® | Ø24 x 100 x 100mm 100 100 T24JT | TAF24 JOINT ‘T’ SHARE | Ø24 code Τ T24JC | TAF24 CROSS | Ø24 code C 200 200 100 200 Body Colours
20 21 EXAMPLE OF APPLICATION TAF24 SYSTEM T24L032_SEGMENT OF 32cm WITH DIFFUSED LIGHT T24I312_SEGMENT WITH 2x9W SPOTS , 2x970Lm T24JL_LINEAR CONNECTION T24JA_JOINT 90® T24A188_SEGMENT OF 188cm WITH DIFFUSED LIGHT T24JA_JOINT 90® T24L084_SEGMENT OF 84cm WITHOUT DIFFUSED LIGHT T24JA_JOINT 90® /scripting_light < > T24I34_SEGMENT WITH 1x7W SPOT , 1x970Lm T24JL_LINEAR CONNECTION T24A084_SEGMENT OF 84cm WITH DIFFUSED LIGHT T24JL_LINEAR CONNECTION T24I342_SEGMENT WITH 2x7W SPOT , 2x970Lm T24JT_JOINT ‘T’ SHARE T24L032_SEGMENT OF 32cm WITHOUT DIFFUSED LIGHT T24JU_JOINT UP T24L032_SEGMENT OF 32cm WITH DIFFUSED LIGHT T24JD_JOINT DOWN T24A084_SEGMENT OF 84cm WITH DIFFUSED LIGHT T24JL_LINEAR CONNECTION T24I31_SEGMENT WITH 1x9W SPOT , 1x970Lm T24P_FEEDER DRIVER SUPPLIED BY 24V On-Off / DALI 1-10V / BLUETOOTH
23 /scripting_light < > 22
/scripting_light < > The magnetic track system by Alphabet is a Class III - SELV product.The supply voltage must be between 0 and 60 VDC and the supply current must not exceed 15 A. The four track conductors can be used to create two separate power supply circuits, or one circuit for the power supply and one for the ‘DATA BUS’. The track bars with 1-2-3 m length are supplied with the copper wires already recessed with respect to the aluminium, to prevent them from coming into contact with one another in case of dual power supply, or, if end caps are used, to prevent the copper wires from coming into contact with them. Discover 48V MAGNETIC TRACK SYSTEM Family 25 24 /scripting_light < >
26 27 /scripting_light < > MAGNETIC CEILING DEEP TRACK Your Code : MCD Length Body Colour Length* Body Colour 100 = 100cm 200 = 200cm 300 = 300cm W = WHITE B = BLACK S = SPECIAL RAL *Make your choices from the above dimensions only. Is not an open edit length track. Your Code : MCDG Body Colour MECHANICAL CORNER CONNECTOR HORIZONTAL Your Code : MCDGD Body Colour MECHANICAL CORNER CONNECTOR VERTICAL Your Code : MCDEE Body Colour Your Code : MCDEH Body Colour END CAP WITHOUT HOLE END CAP WITH HOLE Your Code : MPCTD Body Colour PLASTIC COVER 300cm SUSPENSION KIT WITH ADJUSTABLE WIRE 200cm Your Code : TRSMCD MAGNETIC TRIMLESS DEEP TRACK *Dimensions Indicated In Millimeters Length* Body Colour 100 = 100cm 200 = 200cm 300 = 300cm W = WHITE B = BLACK S = SPECIAL RAL *Make your choices from the above dimensions only. Is not an open edit length track. For MECHANICAL CORNER CONNECTORS HORIZONTAL required also to order FLEX CONNECTOR WITH CABLE (MF). For MECHANICAL CORNER CONNECTORS VERTICAL required also to order FLEX CONNECTOR WITH CABLE (MF). The magnetic track system by Alphabet is a Class III - SELV product. The supply voltage must be between 0 and 60 VDC and the supply current must not exceed 15 A. The four track conductors can be used to create two separate power supply circuits, or one circuit for the power supply and one for the ‘DATA BUS’. The track bars with 1-2-3 m length are supplied with the copper wires already recessed with respect to the aluminium, to prevent them from coming into contact with one another in case of dual power supply, or, if end caps are used, to prevent the copper wires from coming into contact with them. *It is forbidden to use control gear, drivers, DATA BUS systems and components that are not SELV-approved and/ or with U-OUT greater than 60 VDC. During assembly operations, respect the polarity only for the light fittings that require it. • 2 circuits: 2x +/- 15A/0-60V dc • 1 circuit + Data Bus: +/- 15A/0-60V + D+/D- • External extruded body in aluminium. Available colours: black and white or special ral • Insulated extruded body in PVC • Copper conductors Your Code : MTD Length Body Colour Your Code : MTDG Body Colour MECHANICAL CORNER CONNECTOR HORIZONTAL Your Code : MTDGD Body Colour MECHANICAL CORNER CONNECTOR VERTICAL Your Code : MTDEE Body Colour Your Code : MTDEH Body Colour END CAP WITHOUT HOLE END CAP WITH HOLE Your Code : MPCTD Body Colour PLASTIC COVER 300cm For MECHANICAL CORNER CONNECTORS HORIZONTAL required also to order ELECTRIC CORNER CONNECTOR (MG or MF). For MECHANICAL CORNER CONNECTORS VERTICAL required also to order ELECTRIC FLEX CONNECTOR WITH CABLE (MF). *for MTDG also order MF *for MTDGD also order MF *for MCDG also order MG or MF *for MCDGD also order MF For Ceiling Installation, a special set of clips-springs are included. *Clips-Spring for Installation Every 1m (1couple).
28 29 /scripting_light < > MAGNETIC CEILING SHALLOW TRACK Your Code : MCS Length Body Colour Length* Body Colour 100 = 100cm 200 = 200cm 300 = 300cm W = WHITE B = BLACK S = SPECIAL RAL *Make your choices from the above dimensions only. Is not an open edit length track. Your Code : MCSGD Body Colour Your Code : MCSG Body Colour MECHANICAL CORNER CONNECTOR HORIZONTAL MECHANICAL CORNER CONNECTOR VERTICAL Your Code : MCSEE Body Colour END CAP WITHOUT HOLE *Dimensions Indicated In Millimeters The magnetic track system by Alphabet is a Class III - SELV product. The supply voltage must be between 0 and 60 VDC and the supply current must not exceed 15 A. The four track conductors can be used to create two separate power supply circuits, or one circuit for the power supply and one for the ‘DATA BUS’. The track bars with 1-2-3 m length are supplied with the copper wires already recessed with respect to the aluminium, to prevent them from coming into contact with one another in case of dual power supply, or, if end caps are used, to prevent the copper wires from coming into contact with them. *It is forbidden to use control gear, drivers, DATA BUS systems and components that are not SELV-approved and/ or with U-OUT greater than 60 VDC. During assembly operations, respect the polarity only for the light fittings that require it. • 2 circuits: 2x +/- 15A/0-60V dc • 1 circuit + Data Bus: +/- 15A/0-60V + D+/D- • External extruded body in aluminium. Available colours: black and white or special ral • Insulated extruded body in PVC • Copper conductors MAGNETIC TRIMLESS SHALLOW TRACK Length* Body Colour 100 = 100cm 200 = 200cm 300 = 300cm W = WHITE B = BLACK S = SPECIAL RAL *Make your choices from the above dimensions only. Is not an open edit length track. Your Code : MTS Length Body Colour Your Code : MTSG Body Colour MECHANICAL CORNER CONNECTOR HORIZONTAL Your Code : MTSGD Body Colour MECHANICAL CORNER CONNECTOR VERTICAL Your Code : MTSEE Body Colour Your Code : MTSEH Body Colour END CAP WITHOUT HOLE END CAP WITH HOLE SUSPENSION KIT WITH ADJUSTABLE WIRE 200cm Your Code : TRSMCS For MECHANICAL CORNER CONNECTORS HORIZONTAL required also to order ELECTRIC CORNER CONNECTOR (MG or MF). For MECHANICAL CORNER CONNECTORS VERTICAL required also to order ELECTRIC FLEX CONNECTOR WITH CABLE (MF). For MECHANICAL CORNER CONNECTORS HORIZONTAL required also to order FLEX CONNECTOR WITH CABLE (MF). For MECHANICAL CORNER CONNECTORS VERTICAL required also to order FLEX CONNECTOR WITH CABLE (MF). *for MTSG also order MF *for MTSGD also order MF *for MCSG also order MG or MF *for MCSGD also order MF *Flange for Installation Every 1m (1couple). For Trimless Shallow Track, a special set of flange are included.
31 *Dimensions Indicated In Millimeters EPSILON 52 Pendant MAGNETIC ‘EPSILON 50 Magnetic’ Pendant is a LED profile, made of an extruded aluminum, powder-coated with fine matte finish. Incorporated magnetic Track with ‘ready to plug’ at 48V power supply. Designed for pendant installation. Coming in white, black and grey powder coated and in special decorative black and red oxidation. Optionally in your special RAL. Available from 100cm to 300cm Remote Driver in the Box. Your Code : E52P Length Body Colour Body Colour W = WHITE B = BLACK G = GREY L = BLACK OXIDATION R = RED OXIDATION S = SPECIAL RAL Length 100 = 100cm 200 = 200cm 300 = 300cm EPSILON 34 Up & Down MAGNETIC ‘EPSILON 34 Magnetic’ Up & Down is a LED profile, made of an extruded aluminum, powder-coated with fine matte finish. Incorporated magnetic Track with ‘ready to plug’ at 48V power supply. Designed for pendant installation with uplight, providing direct and indirect light emission. Coming in white, black and grey powder coated and in special decorative black and red oxidation. Optionally in your special RAL. Available from 100cm to 300cm Driver 48V for Magnetic and Driver 220V for Uplight Incorporated. 75mm 34mm 30 MAGNETIC RECESSED SHALLOW TRACK Your Code : MRS Length Body Colour ‘Magnetic Shallow Track’ Recessed is a LED profile, made of an extruded aluminum, powder-coated with fine matte finish. Incorporated magnetic Track with ‘ready to plug’ at 48V power supply. Designed for recessed installation. Coming in white and black powder coated. Optionally in your special RAL. Available from 100cm to 300cm *Remote Driver in the Box. Body Colour W = WHITE B = BLACK S = SPECIAL RAL Length 100 = 100cm 200 = 200cm 300 = 300cm Uplight Inset 1 = HE 3357Lm/m | 200Lm/W 2 = HO 5640Lm/m | 188Lm/W 3 = EXTRA BRIGHT 7032Lm/m | 179Lm/W 4 = TUNABLE WHITE 5265Lm/m | 162Lm/W CRI 8 = 80 9 = 90 CCT 27 = 2700K 30 = 3000K 40 = 4000K 11 = TUNABLE WHITE Driver O = ON-OFF D = DALI V = 1-10V Body Colour W = WHITE B = BLACK G = GREY L = BLACK OXIDATION R = RED OXIDATION S = SPECIAL RAL Length 100 = 100cm 200 = 200cm 300 = 300cm Your Code : E34UM Uplight Inset CRi CCT Driver Body Colour Length *Spring for Recessed Track Every 1m (1couper). Your Code : MRSEE Body Colour END CAP WITHOUT HOLE 200cm Cable Adjustable Included 200cm Cable Adjustable Included For Recessed Installation, a special set of springs are included.
32 33 /scripting_light < > FLEX CONNECTOR WITH CABLE Your Code : MF 112 Power by : Available App on : 143 40 BLUETOOTH WIRELESS CONTROL BLACK Your Code : MBB CORNER CONNECTOR Your Code : MG 105 105 INNER CONNECTOR Your Code : MI 105 FEEDER Your Code : MP 112 For all MECHANICAL CORNER CONNECTORS HORIZONTAL required also to order CORNER CONNECTOR (MG). For all MECHANICAL CORNER CONNECTORS VERTICAL required also to order FLEX CONNECTOR WITH CABLE (MGF). FEEDER and all CONNECTORS comes only in BLACK body colour RAL 9005 & WHITE body colour RAL 9016. Body Colour Body Colour Body Colour Body Colour Your Code : MD Mounting Watt Driver Body Colour *Dimensions Indicated In Millimeters REMOTE DRIVER KIT 32 162.5 42.5 Your Code : MDR Watt Driver Mounting Watt C = Ceiling P = Pendant 75 = 75W 150 = 150W 200 = 200W Driver Body Colour O = ON-OFF D = DALI P = PUSH V = 1-10V B = BLUETOOTH W = WHITE B = BLACK W BOX DRIVER KIT 26 562 52 26 562 Watt 60 = 60W 100 = 100W 150 = 150W 200 = 200W Driver O = ON-OFF D = DALI P = PUSH V = 1-10V B = BLUETOOTH W Ceiling Pendant *for ceiling deep magnetic tracks only *Optional Driver box with left and right feeder for ceiling mounting. Body Colour W = WHITE B = BLACK
/scripting_light < > 2700K 3000K 4000K CCT CONSUMPION W 9 9 9 LED CHIP Lumen Output Lm 1071 1296 1458 Consumpion values of LED circuit PF: 0,91-0,95 . Lumen Output values of LED chip @CRi 80 . ZETA MAGNETIC 30® | 60® FINAL* Lumen Output Lm 910 1102 1239 3000K CCT CONSUMPION W 10 LED CHIP Lumen Output Lm 1050 Consumpion values of LED circuit PF: 0,91-0,95 . Lumen Output values of LED chip @CRi 80 . WASHER MAGNETIC FINAL* Lumen Output Lm 624 3000K 4000K CCT CONSUMPION W 5 5 LED CHIP Lumen Output Lm 782 825 Consumpion values of LED circuit PF: 0,91-0,95 . Lumen Output values of LED chip @CRi 80 . SPHERE MAGNETIC 6® FINAL* Lumen Output Lm 512 535 2700K 3000K 4000K CCT CONSUMPION W 3 3 3 LED CHIP Lumen Output Lm 325 350 368 Consumpion values of LED circuit PF: 0,91-0,95 . Lumen Output values of LED chip @CRi 80 . SIGMAx1 MAGNETIC 10® | 36® FINAL* Lumen Output Lm 255 273 287 2700K 3000K 4000K CCT CONSUMPION W 6 6 6 LED CHIP Lumen Output Lm 650 700 736 Consumpion values of LED circuit PF: 0,91-0,95 . Lumen Output values of LED chip @CRi 80 . SIGMAx2 MAGNETIC 10® | 36® FINAL* Lumen Output Lm 510 546 574 2700K 3000K 4000K CCT CONSUMPION W 7 7 7 LED CHIP Lumen Output Lm 760 940 1014 Consumpion values of LED circuit PF: 0,91-0,95 . Lumen Output values of LED chip @CRi 80 . GIOTA 34 MAGNETIC 15® | 24® | 36® FINAL* Lumen Output Lm 525 645 695 2700K 3000K 4000K CCT CONSUMPION W 10 10 10 LED CHIP Lumen Output Lm 1260 1566 1650 Consumpion values of LED circuit PF: 0,91-0,95 . Lumen Output values of LED chip @CRi 80 . GIOTA 40 ZOOMABLE MAGNETIC 15® to 36® FINAL* Lumen Output Lm 770 960 1010 580 860 LUMINAIRE LENGTH CONSUMPION W 10 15 LOUMEN OUTPUT Lm 1972 2956 Lumen Output values of PCB @4000K CRi 80 . LOR ALPHA MAGNETIC : 62 . INSET 1 CONSUMPION W 17 26 ALPHA MAGNETIC INSET 2 LOUMEN OUTPUT Lm 3272 4904 35 34 Magnetic Track Luminaires Lifetime up to 50.000h 3 MacAdam step External extruded body in aluminium Available colours: black and white or special ral Insulated extruded body in PVC. Input Voltage: 2 circuits: 2x +/- 15A/0-60V dc 1 circuit + Data Bus: +/- 15A/0-60V + D+/DPower Factor: 0.9 CCT:3000K, 4000K & 2700K or Tunable White optionally CRi: 80 & 90 optionally Color tolerance: 2 MacAdam THD<20% Electronic short-circuit protection Overload protection Overtemperature protection Protection against “no load” operation Operation temperature: -25° +45° Operation lifetime 50.000h 5 years warranty L90B10 @ 50.000h Ambient temperature +24°
36 37 /scripting_light < > 45 SIGMAx2 MAGNETIC Wattage 7 = 7W CRI 8 = 80 9 = 90 W CCT 27 = 2700K 30 = 3000K 40 = 4000K Optic/Diffuser N = 15® K = 30® Driver O = ON-OFF D = DALI V = 1-10V B = BLUETOOTH Body Colour W = WHITE B = BLACK S = SPECIAL RAL Your Code : SMx2 Wattage CRi CCT Optic/ Diffuser Driver Body Colour SPHERE PENDANT D4.8 MAGNETIC Your Code : SP Wattage CRi CCT Optic/ Diffuser Driver Body Colour Wattage 5 = 5W CRI Optic/Diffuser 8 = 80 9 = 90 F = 38® W CCT 30 = 3000K Driver O = ON-OFF D = DALI V = 1-10V B = BLUETOOTH Body Colour W = WHITE B = BLACK SIGMAx1 MAGNETIC Wattage 3 = 3W CRI Optic/Diffuser 8 = 80 9 = 90 N = 15® K = 30® W CCT 27 = 2700K 30 = 3000K 40 = 4000K Driver O = ON-OFF D = DALI V = 1-10V B = BLUETOOTH Body Colour W = WHITE B = BLACK S = SPECIAL RAL *only for Shallow Tracks *only for Shallow Tracks ZETA MAGNETIC Your Code : ZM Wattage CRi CCT Optic/ Diffuser Driver Body Colour Wattage 10 = 10W CRI Optic/Diffuser 8 = 80 9 = 90 K = 30® W = 60® W CCT 27 = 2700K 30 = 3000K 40 = 4000K 11 = TUNABLE WHITE Driver O = ON-OFF D = DALI V = 1-10V B = BLUETOOTH Body Colour W = WHITE B = BLACK S = SPECIAL RAL WASHER MAGNETIC Your Code : WM Wattage CRi CCT Optic/ Diffuser Driver Body Colour Wattage 10 = 10W CRI Optic/Diffuser 8 = 80 9 = 90 H = WALL WASHER W CCT 30 = 3000K Driver O = ON-OFF D = DALI V = 1-10V B = BLUETOOTH Body Colour W = WHITE B = BLACK S = SPECIAL RAL *Dimensions Indicated In Millimeters 220 95 150 Ø48 Ø30 45 Ø30 45 TUBE 25 MAGNETIC Your Code : TM Length LED Strip Type CRI CCT Diffuser Driver Length 052 = 52cm 062 = 62cm 092 = 92cm 122 = 122cm CRI Diffuser 8 = 80 9 = 90 P = OPAL B = BLACK CCT 27 = 2700K 30 = 3000K 40 = 4000K Driver O = ON-OFF D = DALI V = 1-10V B = BLUETOOTH LED Strip Type 3 = OSRAM TEC Flex TF1500S 4 = LINEAR Light Flex POWER 4000 520 | 620 | 920 | 1220 Ø25 100 100 OSRAM TEC Flex TF1500S LINEAR light Flex POWER 4000 LED Strip Type CCT LOR Lm/m Lm/W 4000K 4000K 50 50 1660 3800 163,3 133 Cover Colour W = WHITE B = BLACK O = GOLD C = COOPER Cover Colour W = WHITE B = BLACK O = GOLD C = COOPER Cover Colour Your Code : SMx1 Wattage CRi CCT Optic/ Diffuser Driver Body Colour Cover Colour
38 39 /scripting_light < > 45 GIOTA 40 ZOOM MAGNETIC Your Code : I40ZM Wattage CRi CCT Optic/ Diffuser Driver Body Colour Wattage 7 = 7W 10 = 10W CRI 8 = 80 9 = 90 W CCT 27 = 2700K 30 = 3000K 40 = 4000K Optic/Diffuser N = 15® Driver O = ON-OFF D = DALI V = 1-10V B = BLUETOOTH Body Colour W = WHITE B = BLACK S = SPECIAL RAL GIOTA 34 MAGNETIC Your Code : I34M Wattage CRi CCT Optic/ Diffuser Driver Body Colour ALPHA MAGNETIC Inset 1 = HE 3357Lm/m 200Lm/w 2 = HO 5640Lm/m 188Lm/w 4 = TUNABLE WHITE 5265Lm/m 162Lm/w CRI Optic/Diffuser 8 = 80 9 = 90 O = OPAL CCT 27 = 2700K 30 = 3000K 40 = 4000K 11 = TUNABLE WHITE Driver O = ON-OFF D = DALI V = 1-10V B = BLUETOOTH Body Colour W = WHITE B = BLACK S = SPECIAL RAL Length 058 = 58cm 086 = 86cm 114 = 114cm Your Code : AM Inset CRi CCT Optic/ Diffuser Driver Body Colour Length *Dimensions Indicated In Millimeters 328 Ø45 98 Ø40 90 Wattage 7 = 7W CRI 8 = 80 9 = 90 W CCT 27 = 2700K 30 = 3000K 40 = 4000K Optic/Diffuser N = 15® O = 24® R = 36® Driver O = ON-OFF D = DALI V = 1-10V B = BLUETOOTH Body Colour W = WHITE B = BLACK S = SPECIAL RAL Cover Colour W = WHITE B = BLACK O = GOLD C = COOPER *Beam Angle 15®- 30® Cover Colour When CCT Tunable White Chosen, Inset Tunable White and Dimm Driver is Required.
40 41 /scripting_light < > 580 860 1140 1420 1700 1980 2260 2540 2820 3100 3380 3660 3940 4220 4500 LUMINAIRE LENGTH CONSUMPION W 10 15 20 25 30 35 39 44 49 54 59 64 69 74 79 LUMEN OUTPUT Lm 1.972 2.956 3.944 4.928 5.916 6.900 7.888 8.872 9.860 10.844 11.832 12.816 13.804 14.788 15.776 CONSUMPION W 17 26 35 43 52 60 69 78 86 95 104 112 121 129 138 LUMEN OUTPUT Lm 3.272 4.904 6.543 8.176 9.815 11.447 13.086 14.719 16.358 17.990 19.629 21.262 22.901 24.533 26.172 INSET 1 INSET 2 Consumpion values of LED circuit PF: 0,91-0,95 . Lumen Output values of PCB @4000K CRi 80 . LOR ALPHA34 : Opal 60 | Micro Opal 62 | Black 18 . U-LOR for all Up & Down 50 . ALPHA 34 2700K 3000K 4000K CCT CONSUMPION W 10 10 10 LED CHIP Lumen Output Lm 1555 1600 1645 Consumpion values of LED circuit PF: 0,91-0,95 . Lumen Output values of LED chip @CRi 90 . ZETA34 15® | 30® | 45® FINAL* Lumen Output Lm 933 960 987 2700K 3000K 4000K CCT CONSUMPION W 10 10 10 LED CHIP Lumen Output Lm 1555 1600 1645 Consumpion values of LED circuit PF: 0,91-0,95 . Lumen Output values of LED chip @CRi 80 . ZETA34 WALL WASHER FINAL* Lumen Output Lm 466,5 480 493,5
42 43 Discover ALPHA34 Family Alpha is a top lighting product line. Easy, simply to fit any project, with superb functionality and minimalistic design. Designed for ceiling, pendant, recessed, trimless and pendant up & down with uplight installation. /scripting_light < >
45 /scripting_light < > ALPHA34 Ceiling Select technical features to configure your code. Length* Inset CRi 058 = 58cm 086 = 86cm 114 = 114cm 142 = 142cm 170 = 170cm 198 = 198cm 226 = 226cm 254 = 254cm 282 = 282cm 310 = 310cm 338 = 338cm 366 = 366cm 394 = 394cm 422 = 422cm 450 = 450cm 1 = HE 3357Lm/m 200Lm/W 2 = HO 5640Lm/m 188Lm/W 4 = TUNNABLE WHITE 5265Lm/m 162Lm/W 8 = 80 9 = 90 CCT Optic/Diffuser Driver Body Colour 27 = 2700K 30 = 3000K 40 = 4000K 65 = 6500K 11 = TUNABLE WHITE P = OPAL M = MICRO PRISMATIC OPAL Β = BLACK DIFFUSER O = ON-OFF D = DALI P = PUSH V = 1-10V B = BLUETOOTH W = WHITE B = BLACK G = GREY S = SPECIAL RAL *Make your choices from the above dimensions only. Is not an open edit length profile. Your Code : A34C Length Inset CRi CCT Optic/ Diffuser Driver Body Colour Your Code : A34P Length Inset CRi CCT Optic/ Diffuser Driver Body Colour ALPHA34 Pendant Ceiling Pendant Techical Specifications & Constraints Length Available from 58cm to 450cm CCT 3000K and 4000K Optionally 2700K, 6500K and Tunable White Color Consistency <3SDCM CRi Available in CRi80 and Optionally CRi90 LED Board & Driver up to 200Lm/W L80 B10 @50.000h (Ta 24°C) Flicker @100Hz<3 LED Drivers On-Off DALI Push Button 1-10V Bluetooth Optic / Diffuser Opal Diffuser, Micro Prismatic Opal, Black Diffuser Body Colours White | Black | Grey | Your Special RAL “ALPHA34” Ceiling or Pendant... is a LED profile luminaire, made of an extruded aluminum, powder-coated with fine matte finish. Designed for ceiling or pendant mounting, providing direct light emission through a diffuser made either of satined polycarbonate for an almost homogeneous emission of light or microprismatic for reduced UGR<19. Luminaire equipped with the latest generation of well known LED boards, with small color tolerance MacAdam 3, according to Zhaga book 7. Drivers On-Off or dimmable. Features: • Available from 58cm to 450cm. • Three different Lumen Output types (HE, HO or Tunable White). • Two different CRi (80 or 90). • Five different CCT (2700K, 3000K, 4000K, 6500K or Tunable White). • Three Optic-Diffuser (Opal, Micro Prismatic Opal or Black Diffuser). • On-Off or Dimmable Drivers (Dali, Push Button, 1-10V or Bluetooth). • Coming in White, Black or Grey powder coated, Optionally in Special RAL. • L80 B10 @50.000h (Ta 24°). • Flicker @100Hz <3. • Color Consistency <3SDCM. Installation Ceiling | Pendant Ceiling Pendant For Ceiling Installation, a special set of clips-springs are included Mechanical IK05 IP20 75.5mm 34mm 34mm 75.5mm Opal Diffuser Micro Prismatic Opal Black Diffuser 200cm Cable Adjustable Included 44 /scripting_light < > When CCT Tunable White Chosen, Inset Tunable White and Dimm Driver is Required.
47 Select technical features to configure your code. Length* Inset CRi CCT Optic/Diffuser Driver Body Colour 058 = 58cm 086 = 86cm 114 = 114cm 142 = 142cm 170 = 170cm 198 = 198cm 226 = 226cm 254 = 254cm 282 = 282cm 310 = 310cm 338 = 338cm 366 = 366cm 394 = 394cm 422 = 422cm 450 = 450cm 1 = HE 3357Lm/m 200Lm/W 2 = HO 5640Lm/m 188Lm/W 4 = TUNNABLE WHITE 5265Lm/m 162Lm/W 8 = 80 9 = 90 27 = 2700K 30 = 3000K 40 = 4000K 65 = 6500K 11 = TUNABLE WHITE P = OPAL M = MICRO PRISMATIC OPAL Β = BLACK DIFFUSER O = ON-OFF D = DALI P = PUSH V = 1-10V B = BLUETOOTH W = WHITE B = BLACK G = GREY S = SPECIAL RAL *Make your choices from the above dimensions only. Is not an open edit length profile. Your Code : A34R Length Inset CRi CCT Optic/ Diffuser Driver Body Colour ALPHA34 Recessed ALPHA34 Trimless Your Code : A34T Length Inset CRi CCT Optic/ Diffuser Driver Body Colour Recessed Trimless “ALPHA34” Recessed or Trimless... are LED profile luminaires, made of an extruded aluminum, powder-coated with fine matte finish. Designed for recessed (with 8mm frame) or trimless mounting, providing direct light emission through a diffuser made either of satined polycarbonate for an almost homogeneous emission of light or microprismatic for reduced UGR<19. Luminaire equipped with the latest generation of well known LED boards, with small color tolerance MacAdam 3, according to Zhaga book 7. Drivers On-Off or dimmable. Features: • Available from 58cm to 450cm. • Three different Lumen Output types (HE, HO or Tunable White). • Two different CRi (80 or 90). • Five different CCT (2700K, 3000K, 4000K, 6500K or Tunable White). • Three Optic-Diffuser (Opal, Micro Prismatic Opal or Black Diffuser). • On-Off or Dimmable Drivers (Dali, Push Button, 1-10V or Bluetooth). • Coming in White, Black or Grey powder coated, Optionally in Special RAL. • L80 B10 @50.000h (Ta 24°). • Flicker @100Hz <3. • Color Consistency <3SDCM. Techical Specifications & Constraints Length Available from 58cm to 450cm CCT 3000K and 4000K Optionally 2700K, 6500K and Tunable White Color Consistency <3SDCM CRi Available in CRi80 and Optionally CRi90 LED Board & Driver up to 200Lm/W L80 B10 @50.000h (Ta 24°C) Flicker @100Hz<3 Installation Recessed | Trimless Body Colours LED Drivers On-Off DALI Push Button 1-10V Bluetooth Optic / Diffuser Opal Diffuser, Micro Prismatic Opal, Black Diffuser Mechanical IK05 IP20 White | Black | Grey | Your Special RAL Recessed Trimless 55mm min required distance 45mm min required distance 35mm 40mm 34mm 47.9mm 75mm 34mm 12.5mm cutting hole frame width cutting hole min distance between plasterboard raster Opal Diffuser Micro Prismatic Opal Black Diffuser 46 /scripting_light < > When CCT Tunable White Chosen, Inset Tunable White and Dimm Driver is Required.
49 “ALPHA34” Up & Down... is a LED profile luminaire, made of an extruded aluminum, powder-coated with fine matte finish. Designed for pendant mounting with uplight, providing direct and indirect light emission through a diffuser made either of satined polycarbonate for an almost homogeneous emission of light or microprismatic for reduced UGR<19. Luminaire equipped with the latest generation of well known LED boards, with small color tolerance MacAdam 3, according to Zhaga book 7. Drivers On-Off or dimmable. Features: • Available from 58cm to 450cm. • Three different Lumen Output types (HE, HO or Tunable White). • Two different CRi (80 or 90). • Five different CCT (2700K, 3000K, 4000K, 6500K or Tunable White). • Three Optic-Diffuser (Opal, Micro Prismatic Opal or Black Diffuser). • On-Off or Dimmable Drivers (Dali, Push Button, 1-10V or Bluetooth). • Coming in White, Black or Grey powder coated, Optionally in Special RAL. • L80 B10 @50.000h (Ta 24°). • Flicker @100Hz <3. • Color Consistency <3SDCM. • U-LOR 50 . ALPHA34 Up & Down Your Code : A34U Length Inset CRi CCT Optic/ Diffuser Driver Up & Down Select technical features to configure your code. Length* Inset CRi CCT Optic/Diffuser Driver Body Colour 058 = 58cm 086 = 86cm 114 = 114cm 142 = 142cm 170 = 170cm 198 = 198cm 226 = 226cm 254 = 254cm 282 = 282cm 310 = 310cm 338 = 338cm 366 = 366cm 394 = 394cm 422 = 422cm 450 = 450cm 1 = HE 3357Lm/m 200Lm/W 2 = HO 5640Lm/m 188Lm/W 4 = TUNNABLE WHITE 5265Lm/m 162Lm/W 8 = 80 9 = 90 27 = 2700K 30 = 3000K 40 = 4000K 65 = 6500K 11 = TUNABLE WHITE P = OPAL M = MICRO PRISMATIC OPAL Β = BLACK DIFFUSER O = ON-OFF D = DALI P = PUSH V = 1-10V B = BLUETOOTH W = WHITE B = BLACK G = GREY S = SPECIAL RAL *Make your choices from the above dimensions only. Is not an open edit length profile. Body Colour Techical Specifications & Constraints Length Available from 58cm to 450cm CCT 3000K and 4000K Optionally Tunable White Color Consistency <3SDCM CRi Available in CRi80 Light Emission Direct and indirect light emission with LED Board in 2 different Lumen Output + Tunable White. LED Board & Driver Up to 180Lm/W L80 B10 @50.000h (Ta 24°C) Flicker @100Hz<3 LED Drivers On-Off DALI Push Button 1-10V Bluetooth Body Colours White | Black | Grey | Your Special RAL Installation Pendant Up & Down Mechanical IK05 IP20 Optic / Diffuser Opal Diffuser, Micro Prismatic Opal, Black Diffuser Up & Down 34mm 75.5mm Opal Diffuser Micro Prismatic Opal Black Diffuser 200cm Cable Adjustable Included 48 /scripting_light < > When CCT Tunable White Chosen, Inset Tunable White and Dimm Driver is Required.
51 /scripting_light < > Select technical features to configure your code. Length* Inset CRi CCT Optic/Diffuser Driver Body Colour 058 = 58cm 086 = 86cm 114 = 114cm 142 = 142cm 170 = 170cm 198 = 198cm 226 = 226cm 254 = 254cm 282 = 282cm 310 = 310cm 338 = 338cm 366 = 366cm 394 = 394cm 422 = 422cm 450 = 450cm 1 = HE 3357Lm/m 200Lm/W 2 = HO 5640Lm/m 188Lm/W 4 = TUNNABLE WHITE 5265Lm/m 162Lm/W 8 = 80 9 = 90 27 = 2700K 30 = 3000K 40 = 4000K 65 = 6500K 11 = TUNABLE WHITE P = OPAL M = MICRO PRISMATIC OPAL Β = BLACK DIFFUSER O = ON-OFF D = DALI P = PUSH V = 1-10V B = BLUETOOTH W = WHITE B = BLACK G = GREY S = SPECIAL RAL *Make your choices from the above dimensions only. Is not an open edit length profile. Your Code : A34CS Length Inset CRi CCT Optic/ Diffuser Driver Body Colour ALPHA34 Ceiling Shallow ALPHA34 Pendant Shallow Ceiling Shallow Pendant Shallow Your Code : A34PS Length Inset CRi CCT Optic/ Diffuser Driver Body Colour Discover ALPHA34 SHALLOW Techical Specifications & Constraints Length Available from 58cm to 450cm CCT 3000K and 4000K Optionally 2700K, 6500K and Tunable White Color Consistency <3SDCM CRi Available in CRi80 and Optionally CRi90 LED Board & Driver up to 200Lm/W L80 B10 @50.000h (Ta 24°C) Flicker @100Hz<3 Installation LED Drivers On-Off DALI Push Button 1-10V Bluetooth Optic / Diffuser Opal Diffuser, Micro Prismatic Opal, Black Diffuser Body Colours Features: • Available from 58cm to 450cm. • Three different Lumen Output types (HE, HO or Tunable White). • Two different CRi (80 or 90). • Five different CCT (2700K, 3000K, 4000K, 6500K or Tunable White). • Three Optic-Diffuser (Opal, Micro Prismatic Opal or Black Diffuser). • On-Off or Dimmable Drivers (Dali, Push Button, 1-10V or Bluetooth). • Coming in White, Black or Grey powder coated, Optionally in Special RAL. • L80 B10 @50.000h (Ta 24°). • Flicker @100Hz <3. • Color Consistency <3SDCM. 50 Ceiling | Pendant Mechanical IK05 IP20 White | Black | Grey | Your Special RAL For Ceiling Installation, a special set of clips-springs are included Ceiling Shallow Pendant Shallow 34mm 35mm 34mm 35mm Opal Diffuser Micro Prismatic Opal Black Diffuser Driver in Ceiling Box 200cm Cable Adjustable Included One Driver Every 2.26m Remote Driver When CCT Tunable White Chosen, Inset Tunable White and Dimm Driver is Required. For Pendant Shallow fixtures, the Driver is on a Ceiling Box with the following dimensions W: 3.4cm H: 3.5cm L: 42cm for Length 58-226cm. W: 4.8cm H: 7.8cm L: 42cm for Length 254-450cm.
/scripting_light < > Black Diffuser Lights Off 53 52 Black Diffuser Lights On
54 55 /scripting_light < > Discover ZETA34 Family Zeta is a top lighting product line. Easy, simply to fit any project, with superb functionality and minimalistic design. Designed for ceiling, pendant, recessed, trimless and pendant up & down with uplight installation. <
57 ZETA34 Ceiling Select technical features to configure your code. Length* Number of Blocks** CRi CCT Optic/Diffuser Driver Body Colour 013 = 13cm 015 = 15cm 026 = 26cm 039 = 39cm 050 = 50cm 100 = 100cm 200 = 200cm 300 = 300cm 450 = 450cm 1 = 1 Block 2 = 2 Blocks 6 = 6 Blocks 10 = 10 Blocks 15 = 15 Blocks 25 = 25 Blocks 30 = 30 Blocks 8 = 80 9 = 90 27 = 2700K 30 = 3000K 40 = 4000K N = 15® K = 30® G = 45® H = WALL WASHER O = ON-OFF D = DALI P = PUSH V = 1-10V B = BLUETOOTH W = WHITE B = BLACK G = GREY S = SPECIAL RAL *Open Edit Length min 13cm - max 450cm. || **Number of Blocks min 1block (of 5 SMD , 10W) - max 30blocks. (13cm each). Cover Colour W = WHITE B = BLACK G = GREY O = GOLD C = COPPER S = SPECIAL RAL Your Code : Z34C Length Number of Blocks of 5LED CRi CCT Optic/ Diffuser Driver Body Colour Cover Colour ZETA34 Pendant Ceiling Pendant Your Code : Z34P Length Number of Blocks of 5LED CRi CCT Optic/ Diffuser Driver Body Colour Cover Colour “ZETA34” Ceiling or Pendant... are LED profiles, made of an extruded aluminum, powder-coated with fine matte finish. Designed for ceiling and pendant mounting, providing direct light emission through SMD 5x2W, 1100Lm each. Luminaire equipped with the latest generation of well known LED boards, with small color tolerance MacAdam 3. Drivers On-Off or dimmable. Features: • Available from 13cm up to 450cm. • Two different CRi (80 or 90). • Three different CCT (2700K, 3000K or 4000K). • Four different Optics-Diffusers (15® , 30® , 45® or Wall Washer). • On-Off or Dimmable Drivers (Dali, Push Button, 1-10V or Bluetooth). • Coming in White, Black or Grey powder coated, Optionally in Special RAL. • L80 B20 @50.000h (Ta 24°). • Flicker @100Hz <3. • UGR <16. Techical Specifications & Constraints Open Edit Length Available in any length from 13cm to 450cm CCT 3000K and 4000K Optionally 2700K Color Consistency < 3 SDCM CRi Available in CRi80 and Optionally CRi90 LED Board & Driver Up to 120Lm/W L80 B20 @50.000h (Ta 24® C) Flicker @100Hz<3 UGR<16 SMD Block of 5LED Total 10W LED Drivers On-Off DALI Push Button 1-10V Bluetooth Optic / Diffuser 15® , 30® , 45® or Wall Washer Body Colours White | Black | Grey | Your Special RAL Installation Ceiling | Pendant Ceiling Pendant For Ceiling Installation, a special set of clips-springs are included Mechanical IK05 IP20 Cover Colours White | Black | Grey | Gold | Copper | Your Special RAL 34mm 75.5mm 34mm 75.5mm 200cm Cable Adjustable Included Wall Washer Diffuser 56 /scripting_light < > Standard Cover Colours
59 Your Code : Z34R Length Number of Blocks of 5LED CRi CCT Optic/ Diffuser Driver Body Colour Cover Colour ZETA34 Recessed ZETA34 Trimless Recessed Trimless Your Code : Z34T Length Number of Blocks of 5LED CRi CCT Optic/ Diffuser Driver Body Colour Cover Colour Select technical features to configure your code. Length* Number of Blocks** CRi CCT Optic/Diffuser Driver Body Colour 013 = 13cm 015 = 15cm 026 = 26cm 039 = 39cm 050 = 50cm 100 = 100cm 200 = 200cm 300 = 300cm 450 = 450cm 1 = 1 Block 2 = 2 Blocks 6 = 6 Blocks 10 = 10 Blocks 15 = 15 Blocks 25 = 25 Blocks 30 = 30 Blocks 8 = 80 9 = 90 27 = 2700K 30 = 3000K 40 = 4000K N = 15® K = 30® G = 45® H = WALL WASHER O = ON-OFF D = DALI P = PUSH V = 1-10V B = BLUETOOTH W = WHITE B = BLACK G = GREY *Open Edit Length min 13cm - max 450cm. || **Number of Blocks min 1block (of 5 SMD , 10W) - max 30blocks. (13cm each) Cover Colour W = WHITE B = BLACK G = GREY O = GOLD C = COPPER S = SPECIAL RAL “ZETA34” Recesed or Trimless... is a LED profile luminaire, made of an extruded aluminum, powder-coated with fine matte finish. Designed for recessed (with 8mm frame) and trimless mounting, providing direct light emission through SMD 5x2W, 1100Lm each. Luminaire equipped with the latest generation of well known LED boards, with small color tolerance MacAdam 3. Drivers On-Off or dimmable. Features: • Available from 13,3cm up to 450cm. • Two different CRi (80 or 90). • Three different CCT (2700K, 3000K or 4000K). • Four different Optics / Diffusers (15® , 30® , 45® or Wall Washer). • On-Off or Dimmable Drivers (Dali, Push Button, 1-10V or Bluetooth). • Coming in White, Black or Grey powder coated. • L80 B20 @50.000h (Ta 24°). • Flicker @100Hz<3 • UGR<16 Recessed | Trimless Techical Specifications & Constraints Open Edit Length Available in any length from 13.3cm to 450cm CCT 3000K and 4000K Optionally 2700K Color Consistency < 3 SDCM CRi Available in CRi80 and Optionally CRi90 LED Board & Driver Up to 120Lm/W L80 B20 @50.000h (Ta 24® C) Flicker @100Hz<3 UGR<16 SMD Block of 5LED Total 10W LED Drivers On-Off DALI Push Button 1-10V Bluetooth Optic / Diffuser 15® , 30® , 45® or Wall Washer Body Colours White | Black | Grey Installation Mechanical IK05 IP20 Cover Colours White | Black | Grey | Gold | Copper | Your Special RAL Recessed Trimless 55mm min required distance 45mm min required distance 35mm 40mm 34mm 47.9mm 75mm 34mm 12.5mm cutting hole frame width cutting hole min distance between plasterboard raster 58 /scripting_light < > Wall Washer Diffuser Standard Cover Colours
61 /scripting_light < > ZETA34 Up & Down “ZETA34” Up & Down... is a LED profile luminaire, made of an extruded aluminum, powder-coated with fine matte finish. Designed for pendant mounting with uplight, providing direct and indirect light emission through SMD 5x2W, 1100Lm each. Luminaire equipped with the latest generation of well known LED boards, with small color tolerance MacAdam 3. Drivers On-Off or dimmable. Features: • Available from 13cm up to 450cm. • Two different Lumen Output types (HE or HO). • Two different CRi (80 or 90). • Three different CCT (2700K, 3000K or 4000K). • Four different Optics-Diffusers (15® , 30® , 45® or Wall Washer). • On-Off or Dimmable Drivers (Dali, Push Button, 1-10V or Bluetooth). • Coming in White, Black or Grey powder coated. • L80 B20 @50.000h (Ta 24°). • Flicker @100Hz <3. • UGR <16. • U-LOR 50. Uplight Emission Uplight with LED Board in 2 Lumen Output. Techical Specifications & Constraints Open Edit Length Available in any length from 13cm to 450cm CCT 3000K and 4000K Optionally 2700K Color Consistency < 3 SDCM CRi Available in CRi80 and Optionally CRi90 LED Board & Driver Up to 120Lm/W L80 B20 @50.000h (Ta 24® C) Flicker @100Hz<3 UGR<16 SMD Block of 5LED Total 10W LED Drivers On-Off DALI Push Button 1-10V Bluetooth Optic / Diffuser 15® , 30® , 45® or Wall Washer Body Colours White | Black | Grey Mechanical IK05 IP20 Cover Colours White | Black | Grey | Gold | Copper | Your Special RAL Installation Pendant Up & Down Up & Down 34mm 75.5mm 200cm Cable Adjustable Included 60 /scripting_light < > Select technical features to configure your code. Length* CRi CCT Optic/Diffuser Driver Cover Colour 013 = 13cm 015 = 15cm 026 = 26cm 039 = 39cm 050 = 50cm 100 = 100cm 200 = 200cm 300 = 300cm 450 = 450cm 8 = 80 9 = 90 27 = 2700K 30 = 3000K 40 = 4000K N = 15® K = 30® G = 45® H = WALL WASHER O = ON-OFF D = DALI P = PUSH V = 1-10V B = BLUETOOTH W = WHITE B = BLACK G = GREY O = GOLD C = COPPER S = SPECIAL RAL *Open Edit Length min 13cm - max 450cm. || **Number of Blocks min 1block (of 5 SMD , 10W) - max 30blocks. (13cm each) Uplight Inset 1 = HE 3357Lm/m 200Lm/W 2 = HO 5640Lm/m 188Lm/W Body Colour W = WHITE B = BLACK G = GREY Number of Blocks** 1 = 1 Block 2 = 2 Blocks 6 = 6 Blocks 10 = 10 Blocks 15 = 15 Blocks 25 = 25 Blocks 30 = 30 Blocks Up & Down Your Code : Z34U Length Number of Blocks of 5LED CRi CCT Optic/ Diffuser Driver Body Colour Cover Colour Uplight Inset Wall Washer Diffuser Standard Cover Colours
63 /scripting_light < > ZETA34 Ceiling Shallow ZETA34 Pendant Shallow Ceiling Shallow Pendant Shallow Your Code : Z34CS Length Number of Blocks of 5LED CRi CCT Optic/ Diffuser Driver Body Colour Cover Colour Your Code : Z34PS Length Number of Blocks of 5LED CRi CCT Optic/ Diffuser Driver Body Colour Cover Colour Select technical features to configure your code. Length* Number of Blocks** CRi CCT Optic/Diffuser Driver Body Colour 013 = 13cm 015 = 15cm 026 = 26cm 039 = 39cm 050 = 50cm 100 = 100cm 200 = 200cm 300 = 300cm 450 = 450cm 1 = 1 Block 2 = 2 Blocks 6 = 6 Blocks 10 = 10 Blocks 15 = 15 Blocks 25 = 25 Blocks 30 = 30 Blocks 8 = 80 9 = 90 27 = 2700K 30 = 3000K 40 = 4000K N = 15® K = 30® G = 45® H = WALL WASHER O = ON-OFF D = DALI P = PUSH V = 1-10V B = BLUETOOTH W = WHITE B = BLACK G = GREY *Open Edit Length min 13cm - max 450cm. || **Number of Blocks min 1block (of 5 SMD , 10W) - max 30blocks. (13cm each) Cover Colour W = WHITE B = BLACK G = GREY O = GOLD C = COPPER S = SPECIAL RAL Discover ZETA34 SHALLOW Features: • Available from 13cm up to 450cm. • Two different CRi (80 or 90). • Three different CCT (2700K, 3000K or 4000K). • Four different Optics-Diffusers (15® , 30® , 45® or Wall Washer). • On-Off or Dimmable Drivers (Dali, Push Button, 1-10V or Bluetooth). • Coming in White, Black or Grey powder coated. • L80 B20 @50.000h (Ta 24°). • Flicker @100Hz <3. • UGR <16. 62 For Ceiling Installation, a special set of clips-springs are included Techical Specifications & Constraints Open Edit Length Available in any length from 13cm to 450cm CCT 3000K and 4000K Optionally 2700K Color Consistency < 3 SDCM CRi Available in CRi80 and Optionally CRi90 LED Board & Driver Up to 120Lm/W L80 B20 @50.000h (Ta 24® C) Flicker @100Hz<3 UGR<16 SMD Block of 5LED Total 10W LED Drivers On-Off DALI Push Button 1-10V Bluetooth Optic / Diffuser 15® , 30® , 45® or Wall Washer Body Colours White | Black | Grey Installation Ceiling | Pendant Mechanical IK05 IP20 Cover Colours White | Black | Grey | Gold | Copper | Your Special RAL Ceiling Shallow Pendant Shallow 34mm 35mm 34mm 35mm Wall Washer Diffuser Standard Cover Colours Driver in Ceiling Box 200cm Cable Adjustable Included One Driver Every 10 Blocks of 5 LED Remote Driver
