2 Founded in 2002, Doxis Lighting Factory is a young and dynamic company. We design, develop, produce and assemble architectural lighting fixtures at our facilities in Genk, Belgium. This offers more flexibility, faster lead times and a better quality control. Quality, customer support and short delays is what we stand for. Long-term partnership is what we are looking for. Doxis has partnerships with well-known designers, engineers and tool builders. We create very up-to-date designs using first-quality components and the latest technology from well-known European suppliers such as Philips, Bridgelux, TCI, Vossloh Schwabe and Citizen to name a few. We serve dealers, architects, light planners and installers in numerous countries all over the globe. We manufacture lighting fixtures used in private homes, shops, museums, offices, etc… Some references include Nike sportswear, Tommy Hilfiger, Mc Donalds, Airport Hong Kong, Airport Bremen Germany, City Hall Luxemburg, City Hall Strassbourg France, Ferrari München Germany, Living Tomorrow Brussels Belgium, Kérastase, Postbank Amsterdam, Opera House Sydney Australia, Chiquita Banana HQ Charlotte NC, Ministry of foreign affairs Kabul Afganistan, Airbus Toulouse France and …..

3 Electric Light is not the result of continuous improvement of candles! made in Belgium

4

5 Quality Guarantee Modern CNC equipment and machinery guarantee quality parts needed to assemble. Highly qualified workers guarantee short lead times and a constant quality. Last year, Doxis invested in a brand new coating facility, applying both powdercoating and liquid coatings. Standard we offer 10 different colors, and on request we can coat any existing RAL tone. Our coating facility applies the strongest possible ecological norms.

6 Recessed Semi-Recessed Downlights overview Juno Fix Titan Semi-Recessed Atlas Semi-Recessed Tektus 45 Recessed Tektus 60 Recessed Tektus 45 Telescopic Tektus 60 Telescopic Titan Fix Titan Wallwasher Vesto Single FlatLED T1 Atlas Fix Atlas Mix 150 p.24 p.102 p.104 p.94 p.96 p.98 p.98 p.50 p.60 p.40 p.80 p.82 p.86 Juno Fix Titan IP54 Juno IP54 p.26 p.58 p.36 Juno Mix Titan Mix Vesto Double FlatLED T2 Atlas Mix Atlas Mix Square p.28 p.52 p.42 p.80 p.84 p.88 Atlas Mix Double Rectangle p.90 Atlas Mix Double Oval p.90 Juno Mix Titan IP54 Juno IP54 p.30 p.58 p.36 Juno Mix Deep Titan Fix Vesto Triple p.32 p.54 p.44 Juno Mix Deep Titan 1-Way p.34 p.62 Juno Orientation Titan Mix Vesto Quadro Focus Rec. Plus Focus Rec. Base Kana Aster Fix Aster Mix IP54 Aster Fix IP54 Aster Mix p.38 p.56 p.46 p.70 p.70 p.78 p.72 p.74 p.72 p.74 Juno Orientation Titan 2-Way Titan Double Oval Titan Double Rectangle p.38 p.64 p.66 p.68 Tektus 45 Discus 55 p.100 *In combination with optional front glass.

7 Trimless 3-Phase Juno Trimless Titan Trimless Standard FlatLED Trimless T1 Tektus 60 Trimless Concrete Aster Trimless Deep Square Double Tektus 60 3-Phase Tektus 60 3-Phase Flush Tektus 45 Susp. 3-Phase Tektus 45 3-Phase Tektus 60 Susp. 3-Phase Tektus 45 3-Phase Flush Tektus 45 Susp. 3-Phase Titan Trimless Deep Aster Trimless Deep Square Single FlatLED Trimless T2 Tektus 45 Trimless Planar Concrete Aster Trimless Deep Square Triple Focus Trimless Tektus 45 Trimless Planar Standard Tektus 45 Trimless Standard Atlas Trimless Deep Square Tektus 45 Trimless Concrete Titan Trimless Deep Square Aster Trimless Fix Tektus 45 Trimless Flush Aster Trimless Mix p.106 p.108 Seperate kits p.326 Cassette p.327 p.130 p.120 p.126 p.204 p.206 p.208 p.204 p.210 p.206 p.208 p.110 Seperate kits p.326 Cassette p.327 p.126 p.130 p.118 p.126 p.122 p.118 p.116 p.128 p.116 p.112 p.124 p.114 p.124 Titan 3-Phase Single Atlas 3-Phase Double Atlas 3-Phase Single p.212 p.214 p.214 Tektus 60 Trimless Standard p.120

8 Atlas Slim 3-Way p.162 Surface Mounted Titan Surface Mounted FlatLED T1 Atlas Box Double Titan Base Single FlatLED T2 Titan 200 Atlas Base Single Titan 140 Titan Box Single Titan Multi Double Atlas Base Double Titan Box Double Titan Multi Triple Titan Multi Quadro Atlas Box Single p.132 p.156 p.160 p.134 p.156 p.140 p.158 p.138 p.142 Tektus 45 2-Way Rectangle p.168 Tektus 45 3-Way Rectangle p.168 Tektus 45 3-Way Square p.168 Tektus 60 2-Way Rectangle p.170 Tektus 60 3-Way Rectangle p.170 Tektus 60 3-Way Square p.170 Tektus 45 2-Way Round D480 p.172 Tektus 45 3-Way Round D480 p.172 Tektus 60 2-Way Round D480 p.174 Tektus 60 3-Way Round D640 p.174 Tektus 45 4-Way Round D640 p.177 Tektus 45 5-Way Round D640 p.177 p.136 p.158 p.144 p.136 p.136 p.160 Tektus 45 1-Way Square p.166 Tektus 60 1-Way Square p.166 Tektus 45 1-Way Round p.164 Tektus 60 1-Way Round p.164 Suspended & Surface Mounted overview Tektus Slim 1-Way Tektus 45 Magnetic Tektus Slim 2-Way Tektus 45 Surf. Mounted Tektus Slim 3-Way Tektus 60 Ceiling Mounted 200 Tektus Slim 4-Way Tektus 60 Ceiling Mounted 200 p.150 p.146 p.152 p.148 p.152 p.154 p.152 p.154

9 Suspended Wall Mounted Atlas Box Double Atlas Slim 3-Way Atlas Box Single Tektus Wall Cross Titan 200 Tektus Wall Double Titan 140 Tektus Wall Single p.140 p.182 p.138 p.182 p.160 p.162 p.160 p.182 Tektus 45 Suspended Slim 1-way 114mm Tektus 60 Suspended Slim 1-way Tektus 45 Suspended Compact 114mm Tektus 45 Round D300 Suspended 114mm Tektus 45 Suspended Slim 2-way 114mm Tektus 60 Suspended Slim 2-way Tektus 45 Suspended Compact 200mm Tektus 45 Round D480 Suspended 114mm Tektus 45 Suspended Slim 4-way 114mm Tektus 60 Suspended Slim 4-way Tektus 60 Suspended Slim 4-way Tektus 45 Round D300 Suspended 200mm Tektus 45 Suspended Slim 3-way 114mm Tektus 60 Suspended Slim 3-way Tektus 60 Suspended Compact Tektus 45 Round D640 Suspended 114mm Tektus 45 Suspended Slim 1-way 200mm Tektus 60 Round D300 Suspended Tektus 45 Round D480 Suspended 200mm Tektus 45 Suspended Slim 2-way 200mm Tektus 60 Round D480 Suspended Tektus 45 Round D640 Suspended 200mm Tektus 45 Suspended Slim 3-way 200mm Tektus 60 Round D640 Suspended Tektus 45 Suspended Slim 4-way 200mm p.186 p.186 p.184 p.194 p.188 p.188 p.184 p.196 p.192 p.192 p.154 p.194 p.190 p.190 p.184 p.198 p.186 p.200 p.196 p.188 p.200 p.198 p.190 p.200 p.192

10 Suspended Surface Mounted & Suspended Wall Mounted Surface Mounted Tektus 60 Linear Freeliner Square F1560 Freeliner Linear F2536 Freeliner Paperclip Acoustic Panel Freeliner Round D480 Full Moon 900 Indirect Flat Iron 80.50 Freeliner Paperclip F2080 Freeliner Round F1050 p.242 p.222 p.226 p.228 p.250 p.234 p.248 p.224 p.218 Tektus 45 Linear Freeliner Square F1550 Freeliner Linear F2524 Freeliner Round D300 Full Moon 600 Indirect Flat Iron 60.60 Freeliner Paperclip F2060 Freeliner Round F1030 Tektus Spotless Freeliner Square F1570 Freeliner Linear F2544 Freeliner Round Acoustic Panel Freeliner Round D640 Flat Iron 110.30 Flat Iron 140.30 Freeliner Paperclip F2099 Freeliner Round F1070 Freeliner Round F1099 p.240 p.222 p.226 p.250 p.234 p.248 p.224 p.218 p.244 p.222 p.226 p.228 p.250 p.248 p.248 p.224 p.218 p.220 Full Moon 400 p.232 Full Moon 600 Full Moon 900 p.232 p.232 Office Lounge overview Suspended LEDliner20 Atlas Longus p.230 p.238

11 Suspended Lounge overview Tunnel Round Palladino Dome 720 p.256 p.262 p.270 Tunnel T2 Palladium Dome 900 Eclipse Globe 800 Pollux 450 Conicus p.254 p.262 p.272 p.266 p.278 p.292 p.268 Tunnel Round Double Palladium T2 Solar Globe 500 Apollo 800 Apollo 600 Tunnel Round Triple p.258 p.262 p.266 p.276 p.286 p.284 p.258

12 Suspended Recessed Trimless Ceiling Mounted Custom made profiles LEDliner35 LEDliner20 LEDliner40 LEDliner40 LEDliner35 p.302 p.230 p.302 p.382 p.390 LEDliner47 LEDliner40 LEDliner40 LEDliner100 LEDliner47 LEDliner66 LEDliner100 LEDliner66 LEDliner170 LEDliner170 p.322 p.310 p.310 p.322 p.394 Wall Mounted LEDliner 35 p.302 LEDliner 47 p.322 p.342 p.342 p.387 p.374 p.374 LEDliner65 LEDliner65 LEDliner80 LEDliner70 LEDliner70 LEDliner80 p.334 p.334 p.366 p.352 p.352 p.366 *Optional

13 Ready To Go profiles Spot modules for profiles Up&Down Suspended Up&Down Suspended Up&Down Wall Mounted Single Circuit .S1 LL40 (p.318-319) LL47 (p.328) LL66 (p.348) LL70 (p.362-363) LL80 (p.372) LL170 (p.380) Double Circuit .S2 LL40 (p.320-321) LL47 (p.329) LL66 (p.349) LL70 (p.364-365) LL80 (p.373) LL170 (p.381) Single Circuit .W1 LL47 (p.331) Double Circuit .W2 LL47 (p.333) Down Down Suspended LL20 (p.230) LL35 (p.305) LL40 (p.314-315) LL47 (p.326) LL65 (p.338) LL66 (p.346) LL70 (p.358-359) LL80 (p.370) LL170 (p.380) .SU .CM .WA .RE .TR Down Ceiling Mounted LL35 (p.306) LL40 (p.316-317) LL47 (p.327) LL65 (p.339) LL66 (p.347) LL70 (p.360-361) LL80 (p.371) LL170 (p.379) Down Wall Mounted LL35 (p.307) LL47 (p.330) Down Recessed LL40 (p.384) LL100 (p.388) Down Trimless LL40 (p.392) LL100 (p.396) Juno Soft Beam Mix Module Juno Reflector Mix Module Tektus 45 Spot Module Tektus 45 200mm Suspended Module Juno Soft Beam Fix Module Juno Reflector Fix Module Tektus 45 114mm Suspended Module Tektus 60 Spot Module Tektus 60 Suspended Module Atlas Recessed Module Tektus 45 Slim Spot Module Titan Module Tektus 60 Slim Spot Module Atlas Spot Module p.307 p.307 p.409 p.106 p.306 p.306 p.98 p.409 p.106 p.412 p.300 p.412 p.301 p.413

14 Skyscraper Denison Street 1, Sydney, Australia. This project is most likely the biggest challenge Doxis ever accepted. Custom designed aluminium and opal profiles. 260 and 900mm LED boards were custom designed to fit all 3600mm linear sections with smooth light all over. 4600 meters of straight and 650 meters of curved custom made profiles are installed. Aluminium and opal profiles were bended with extreme small tolerances.

15

16 Coloma Church Mechelen, Belgium Custom designed suspended luminaire. Diameter of 2750mm Indirect lighting: 39600lm Direct lighting: 21000 + 52800lm DALI converters: Philips LED boards: Ra90 2700K Philips

17

18 Church Gosheim, Germany Custom designed structure Structure based on LEDliner170 equipped with Atlas spots Project by 3000k

19

20 Thor Park Genk, Belgium Profiles used: LEDliner35 and LEDliner65 Quantity: 3700 meters Installation: Suspended, Recessed and Surface Mounted Finish: Matt White Texture with both opal and prismatic overs. DALI converters: Philips LED boards: Ra80 3000K Philips

21

22 Project in Germany diesigner konzept GmbH https://www.diesigner.de/ Luminaires used: Atlas Longus Installation: Suspended Finish: Matt White Texture

23

24 Juno Fix Round Type Downlight Mounting Recessed Material Aluminium Adjustable No El. class / IP Class III / IP20 El. class driver Class II Warranty see p.443 Bridgelux Vero 10 LED (150mA) CCT 2700K / 3000K / 4000K CRI Ra97 (Ra90 on request) SDCM 3 Ra97 Ra90 Luminous Flux 2700K 421lm (120lm/W) 458lm (130lm/W) LED 3000K 450lm (129lm/W) 476lm (135lm/W) 4000K 478lm (133lm/W) 487lm (138lm/W) Luminous Flux 2700K 350lm (89lm/W) 380lm (97lm/W) System 3000K 374lm (95lm/W) 400lm (102lm/W) 4000K 396lm (98lm/W) 409lm (104lm/W) (Values based on Juno Reflector) Beam angle 44° / Soft beam LED Power 3.5W (excl. driver) System Power 3.9W (incl. driver) Current 150mA Forward voltage 21V (min.) - 23.4V (typ.) - 25.8V (max.) Outside diameter: Ø50mm Trapezium springs Bended steel sides for easy Insertion & removal in ceiling Power supply min. 50mm Air circulation notice: Do not topload with insulation materials Weight: 204g (excl. driver) Ø43mm Ceiling thickness min. 9mm Height: 28mm Build-in depth: 50mm

25 Juno Fix Round Soft Beam Independant driver included in article and pricing Soft Beam - Non dim 2700K - Ra97 - 3.9W - 350lm 1501.44.24.H27.XX € 89.20 3000K - Ra97 - 3.9W - 374lm 1501.44.24.H30.XX € 89.20 4000K - Ra97 - 3.9W - 396lm 1501.44.24.H40.XX € 89.20 Juno Fix Round Reflector Independant driver included in article and pricing 44° Reflector - Non dim 2700K - Ra97 - 3.9W - 350lm 1500.44.24.H27.XX € 99.30 3000K - Ra97 - 3.9W - 374lm 1500.44.24.H30.XX € 99.30 4000K - Ra97 - 3.9W - 396lm 1500.44.24.H40.XX € 99.30 Dimmable drivers for remote placement available on request *UGR <19 for Juno Soft Beam Black Matt Texture. 01 15 18 07 03 25 16 36 40 More info see “Color info” p.421 Colors Standard 01 - White Matt Texture 18 - Grey Matt Texture 07 - Anthracite Matt Text. 03 - Black Matt Texture 25 - Smoked Brown Text. 36 - Bronze Colors Special 15 - Corten........................... +€ 26.50 16 - Gold.............................. +€ 26.50 40 - Champagne. ................ +€ 26.50 00000.00.CCC.XX Available colors (see below) Other RAL colors on request Hxx: CRI 97 (standard) 9xx: CRI 90 CRI97

26 Juno Fix Square Width: 50mm Length: 50mm Type Downlight Mounting Recessed Material Aluminium Adjustable No El. class / IP Class III / IP20 El. class driver Class II Warranty: see p.443 Bridgelux Vero 10 LED (150mA) CCT 2700K / 3000K / 4000K CRI Ra97 (Ra90 on request) SDCM 3 Ra97 Ra90 Luminous Flux 2700K 421lm (120lm/W) 458lm (130lm/W) LED 3000K 450lm (129lm/W) 476lm (135lm/W) 4000K 478lm (133lm/W) 487lm (138lm/W) Luminous Flux 2700K 350lm (89lm/W) 380lm (97lm/W) System 3000K 374lm (95lm/W) 400lm (102lm/W) 4000K 396lm (98lm/W) 409lm (104lm/W) (Values based on Juno Reflector) Beam angle 44° / Soft beam LED Power 3.5W (excl. driver) System Power 3.9W (incl. driver) Current 150mA Forward voltage 21V (min.) - 23.4V (typ.) - 25.8V (max.) Weight: 200g Power supply min. 50mm Air circulation notice: Do not topload with insulation materials (excl. driver) Ø43mm Ceiling thickness min. 9mm Trapezium springs Bended steel sides for easy Insertion & removal in ceiling Height: 28mm Build-in depth: 50mm

27 Juno Fix Square Soft Beam Independant driver included in article and pricing Soft Beam - Non dim 2700K - Ra97 - 3.9W - 350lm 1505.44.24.H27.XX € 90.50 3000K - Ra97 - 3.9W - 374lm 1505.44.24.H30.XX € 90.50 4000K - Ra97 - 3.9W - 396lm 1505.44.24.H40.XX € 90.50 Juno Fix Square Reflector Independant driver included in article and pricing 44° Reflector - Non dim 2700K - Ra97 - 3.9W - 350lm 1504.44.24.H27.XX € 100.10 3000K - Ra97 - 3.9W - 374lm 1504.44.24.H30.XX € 100.10 4000K - Ra97 - 3.9W - 396lm 1504.44.24.H40.XX € 100.10 Dimmable drivers for remote placement on request *UGR <19 for Juno Soft Beam Black Matt Texture. 01 15 18 07 03 25 16 36 40 More info see “Color info” p.421 Colors Standard 01 - White Matt Texture 18 - Grey Matt Texture 07 - Anthracite Matt Text. 03 - Black Matt Texture 25 - Smoked Brown Text. 36 - Bronze Colors Special 15 - Corten........................... +€ 26.50 16 - Gold.............................. +€ 26.50 40 - Champagne. ................ +€ 26.50 00000.00.CCC.XX Available colors (see below) Other RAL colors on request Hxx: CRI 97 (standard) 9xx: CRI 90 CRI97

28 Juno Mix Round Type Downlight Mounting Recessed Material Aluminium Adjustable Yes (33°/359°) El. class / IP Class III / IP20 El. class driver Class II Warranty: see p.443 Bridgelux Vero 10 LED (150mA) CCT 2700K / 3000K / 4000K CRI Ra97 (Ra90 on request) SDCM 3 Ra97 Ra90 Luminous Flux 2700K 421lm (120lm/W) 458lm (130lm/W) LED 3000K 450lm (129lm/W) 476lm (135lm/W) 4000K 478lm (133lm/W) 487lm (138lm/W) Luminous Flux 2700K 350lm (89lm/W) 380lm (97lm/W) System 3000K 374lm (95lm/W) 400lm (102lm/W) 4000K 396lm (98lm/W) 409lm (104lm/W) (Values based on Juno Reflector) Beam angle 44° / Soft beam LED Power 3.5W (excl. driver) System Power 3.9W (incl. driver) Current 150mA Forward voltage 21V (min.) - 23.4V (typ.) - 25.8V (max.) Weight: 200g (excl. driver) Outside diameter: Ø60mm Trapezium springs Bended steel sides for easy Insertion & removal in ceiling Height: 28mm Build-in depth: 50mm (non dim) 120mm (dimmable) Power supply Non dim.: min. 50mm Dimmable: min. 120mm Air circulation notice: Do not topload with insulation materials Ceiling thickness min. 9mm 359° 33° Ø54mm

29 Juno Mix Round Soft Beam Independant driver included in article and pricing Soft Beam - Non dim 2700K - Ra97 - 3.9W - 350lm 1503.44.24.H27.XX € 98.60 3000K - Ra97 - 3.9W - 374lm 1503.44.24.H30.XX € 98.60 4000K - Ra97 - 3.9W - 396lm 1503.44.24.H40.XX € 98.60 Soft Beam - 1-10V dim 2700K - Ra97 - 3.9W - 350lm 1503.44.25.H27.XX € 123.80 3000K - Ra97 - 3.9W - 374lm 1503.44.25.H30.XX € 123.80 4000K - Ra97 - 3.9W - 396lm 1503.44.25.H40.XX € 123.80 Soft Beam - DALI dim 2700K - Ra97 - 3.9W - 350lm 1503.44.26.H27.XX € 130.20 3000K - Ra97 - 3.9W - 374lm 1503.44.26.H30.XX € 130.20 4000K - Ra97 - 3.9W - 396lm 1503.44.26.H40.XX € 130.20 Soft Beam - Push/Touch dim 2700K - Ra97 - 3.9W - 350lm 1503.44.29.H27.XX € 123.80 3000K - Ra97 - 3.9W - 374lm 1503.44.29.H30.XX € 123.80 4000K - Ra97 - 3.9W - 396lm 1503.44.29.H40.XX € 123.80 Juno Mix Round Reflector Independant driver included in article and pricing 44° Reflector - Non dim 2700K - Ra97 - 3.9W - 350lm 1502.44.24.H27.XX € 106.10 3000K - Ra97 - 3.9W - 374lm 1502.44.24.H30.XX € 106.10 4000K - Ra97 - 3.9W - 396lm 1502.44.24.H40.XX € 106.10 44° Reflector - 1-10V dim 2700K - Ra97 - 3.9W - 350lm 1502.44.25.H27.XX € 131.30 3000K - Ra97 - 3.9W - 374lm 1502.44.25.H30.XX € 131.30 4000K - Ra97 - 3.9W - 396lm 1502.44.25.H40.XX € 131.30 44° Reflector - DALI dim 2700K - Ra97 - 3.9W - 350lm 1502.44.26.H27.XX € 137.70 3000K - Ra97 - 3.9W - 374lm 1502.44.26.H30.XX € 137.70 4000K - Ra97 - 3.9W - 396lm 1502.44.26.H40.XX € 137.70 44° Reflector - Push/Touch dim 2700K - Ra97 - 3.9W - 350lm 1502.44.29.H27.XX € 131.30 3000K - Ra97 - 3.9W - 374lm 1502.44.29.H30.XX € 131.30 4000K - Ra97 - 3.9W - 396lm 1502.44.29.H40.XX € 131.30 *UGR <19 for Juno Soft Beam Black Matt Texture. More info see “Color info” p.421 01 15 18 07 03 25 16 36 40 Colors Standard 01 - White Matt Texture 18 - Grey Matt Texture 07 - Anthracite Matt Text. 03 - Black Matt Texture 25 - Smoked Brown Text. 36 - Bronze Colors Special 15 - Corten........................... +€ 35.30 16 - Gold.............................. +€ 35.30 40 - Champagne. ................ +€ 35.30 00000.00.CCC.XX Available colors (see below) Other RAL colors on request Hxx: CRI 97 (standard) 9xx: CRI 90 CRI97

30 Juno Mix Square Living Tomorrow Brussels - Beliën Architects Type Downlight Mounting Recessed Material Aluminium Adjustable Yes (33°/359°) El. class / IP Class III / IP20 El. class driver Class II Warranty: see p.443 Bridgelux Vero 10 LED (150mA) CCT 2700K / 3000K / 4000K CRI Ra97 (Ra90 on request) SDCM 3 Ra97 Ra90 Luminous Flux 2700K 421lm (120lm/W) 458lm (130lm/W) LED 3000K 450lm (129lm/W) 476lm (135lm/W) 4000K 478lm (133lm/W) 487lm (138lm/W) Luminous Flux 2700K 350lm (89lm/W) 380lm (97lm/W) System 3000K 374lm (95lm/W) 400lm (102lm/W) 4000K 396lm (98lm/W) 409lm (104lm/W) (Values based on Juno Reflector) Beam angle 44° / Soft beam LED Power 3.5W (excl. driver) System Power 3.9W (incl. driver) Current 150mA Forward voltage 21V (min.) - 23.4V (typ.) - 25.8V (max.) Weight: 200g (excl. driver) 359° 33° Ø54mm Power supply Non dim.: min. 50mm Dimmable: min. 120mm Air circulation notice: Do not topload with insulation materials Ceiling thickness min. 9mm Width: 58mm Length: 58mm Trapezium springs Bended steel sides for easy Insertion & removal in ceiling Height: 28mm Build-in depth: 50mm (non dim) 120mm (dimmable)

31 Juno Mix Square Soft Beam Independant driver included in article and pricing Soft Beam - Non dim 2700K - Ra97 - 3.9W - 350lm 1507.44.24.H27.XX € 101.90 3000K - Ra97 - 3.9W - 374lm 1507.44.24.H30.XX € 101.90 4000K - Ra97 - 3.9W - 396lm 1507.44.24.H40.XX € 101.90 Soft Beam - 1-10V dim 2700K - Ra97 - 3.9W - 350lm 1507.44.25.H27.XX € 127.20 3000K - Ra97 - 3.9W - 374lm 1507.44.25.H30.XX € 127.20 4000K - Ra97 - 3.9W - 396lm 1507.44.25.H40.XX € 127.20 Soft Beam - DALI dim 2700K - Ra97 - 3.9W - 350lm 1507.44.26.H27.XX € 133.50 3000K - Ra97 - 3.9W - 374lm 1507.44.26.H30.XX € 133.50 4000K - Ra97 - 3.9W - 396lm 1507.44.26.H40.XX € 133.50 Soft Beam - Push/Touch dim 2700K - Ra97 - 3.9W - 350lm 1507.44.29.H27.XX € 127.20 3000K - Ra97 - 3.9W - 374lm 1507.44.29.H30.XX € 127.20 4000K - Ra97 - 3.9W - 396lm 1507.44.29.H40.XX € 127.20 Juno Mix Square Reflector Independant driver included in article and pricing 44° Reflector - Non dim 2700K - Ra97 - 3.9W - 350lm 1506.44.24.H27.XX € 109.30 3000K - Ra97 - 3.9W - 374lm 1506.44.24.H30.XX € 109.30 4000K - Ra97 - 3.9W - 396lm 1506.44.24.H40.XX € 109.30 44° Reflector - 1-10V dim 2700K - Ra97 - 3.9W - 350lm 1506.44.25.H27.XX € 134.50 3000K - Ra97 - 3.9W - 374lm 1506.44.25.H30.XX € 134.50 4000K - Ra97 - 3.9W - 396lm 1506.44.25.H40.XX € 134.50 44° Reflector - DALI dim 2700K - Ra97 - 3.9W - 350lm 1506.44.26.H27.XX € 141.00 3000K - Ra97 - 3.9W - 374lm 1506.44.26.H30.XX € 141.00 4000K - Ra97 - 3.9W - 396lm 1506.44.26.H40.XX € 141.00 44° Reflector - Push/Touch dim 2700K - Ra97 - 3.9W - 350lm 1506.44.29.H27.XX € 134.50 3000K - Ra97 - 3.9W - 374lm 1506.44.29.H30.XX € 134.50 4000K - Ra97 - 3.9W - 396lm 1506.44.29.H40.XX € 134.50 *UGR <19 for Juno Soft Beam Black Matt Texture. 01 15 18 07 03 25 16 36 40 More info see “Color info” p.421 Colors Standard 01 - White Matt Texture 18 - Grey Matt Texture 07 - Anthracite Matt Text. 03 - Black Matt Texture 25 - Smoked Brown Text. 36 - Bronze Colors Special 15 - Corten........................... +€ 35.30 16 - Gold ........................... +€ 35.30 40 - Champagne. ................ +€ 35.30 00000.00.CCC.XX Available colors (see below) Other RAL colors on request Hxx: CRI 97 (standard) 9xx: CRI 90 CRI97

32 Juno Mix Deep Round Type Downlight Mounting Recessed Material Aluminium Adjustable Yes (33°/359°) El. class / IP Class III / IP20 El. class driver Class II Warranty: see p.443 Bridgelux Vero 10 LED (150mA) CCT 2700K / 3000K / 4000K CRI Ra97 (Ra90 on request) SDCM 3 Ra97 Ra90 Luminous Flux 2700K 421lm (120lm/W) 458lm (130lm/W) LED 3000K 450lm (129lm/W) 476lm (135lm/W) 4000K 478lm (133lm/W) 487lm (138lm/W) Luminous Flux 2700K 350lm (89lm/W) 380lm (97lm/W) System 3000K 374lm (95lm/W) 400lm (102lm/W) 4000K 396lm (98lm/W) 409lm (104lm/W) (Values based on Juno Reflector) Beam angle 44° / Soft beam LED Power 3.5W (excl. driver) System Power 3.9W (incl. driver) Current 150mA Forward voltage 21V (min.) - 23.4V (typ.) - 25.8V (max.) Weight: 200g (excl. driver) 359° 33° Ø54mm Power supply Non dim.: min. 50mm Dimmable: min. 120mm Air circulation notice: Do not topload with insulation materials Ceiling thickness min. 9mm Outside diameter: Ø60mm Height: 38mm Build-in depth: 50mm (non dim) 120mm (dimmable) Trapezium springs Bended steel sides for easy Insertion & removal in ceiling

33 Juno Mix Deep Round Soft Beam Independant driver included in article and pricing Soft Beam - Non dim 2700K - Ra97 - 3.9W - 350lm 1511.44.24.H27.XX € 100.20 3000K - Ra97 - 3.9W - 374lm 1511.44.24.H30.XX € 100.20 4000K - Ra97 - 3.9W - 396lm 1511.44.24.H40.XX € 100.20 Soft Beam - 1-10V dim 2700K - Ra97 - 3.9W - 350lm 1511.44.25.H27.XX € 125.30 3000K - Ra97 - 3.9W - 374lm 1511.44.25.H30.XX € 125.30 4000K - Ra97 - 3.9W - 396lm 1511.44.25.H40.XX € 125.30 Soft Beam - DALI dim 2700K - Ra97 - 3.9W - 350lm 1511.44.26.H27.XX € 131.90 3000K - Ra97 - 3.9W - 374lm 1511.44.26.H30.XX € 131.90 4000K - Ra97 - 3.9W - 396lm 1511.44.26.H40.XX € 131.90 Soft Beam - Push/Touch dim 2700K - Ra97 - 3.9W - 350lm 1511.44.29.H27.XX € 125.30 3000K - Ra97 - 3.9W - 374lm 1511.44.29.H30.XX € 125.30 4000K - Ra97 - 3.9W - 396lm 1511.44.29.H40.XX € 125.30 Juno Mix Deep Round Reflector Independant driver included in article and pricing 44° Reflector - Non dim 2700K - Ra97 - 3.9W - 350lm 1510.44.24.H27.XX € 107.60 3000K - Ra97 - 3.9W - 374lm 1510.44.24.H30.XX € 107.60 4000K - Ra97 - 3.9W - 396lm 1510.44.24.H40.XX € 107.60 44° Reflector - 1-10V dim 2700K - Ra97 - 3.9W - 350lm 1510.44.25.H27.XX € 132.70 3000K - Ra97 - 3.9W - 374lm 1510.44.25.H30.XX € 132.70 4000K - Ra97 - 3.9W - 396lm 1510.44.25.H40.XX € 132.70 44° Reflector - DALI dim 2700K - Ra97 - 3.9W - 350lm 1510.44.26.H27.XX € 139.30 3000K - Ra97 - 3.9W - 374lm 1510.44.26.H30.XX € 139.30 4000K - Ra97 - 3.9W - 396lm 1510.44.26.H40.XX € 139.30 44° Reflector - Push/Touch dim 2700K - Ra97 - 3.9W - 350lm 1510.44.29.H27.XX € 132.70 3000K - Ra97 - 3.9W - 374lm 1510.44.29.H30.XX € 132.70 4000K - Ra97 - 3.9W - 396lm 1510.44.29.H40.XX € 132.70 *UGR <19 for Juno Soft Beam Black Matt Texture. 01 15 18 07 03 25 16 36 40 More info see “Color info” p.421 Colors Standard 01 - White Matt Texture 18 - Grey Matt Texture 07 - Anthracite Matt Text. 03 - Black Matt Texture 25 - Smoked Brown Text. 36 - Bronze Colors Special 15 - Corten........................... +€ 35.30 16 - Gold.............................. +€ 35.30 40 - Champagne. ................ +€ 35.30 00000.00.CCC.XX Available colors (see below) Other RAL colors on request Hxx: CRI 97 (standard) 9xx: CRI 90 CRI97

34 Juno Mix Deep Square Type Downlight Mounting Recessed Material Aluminium Adjustable Yes (33°/359°) El. class / IP Class III / IP20 El. class driver Class II Warranty: see p.443 Bridgelux Vero 10 LED (150mA) CCT 2700K / 3000K / 4000K CRI Ra97 (Ra90 on request) SDCM 3 Ra97 Ra90 Luminous Flux 2700K 421lm (120lm/W) 458lm (130lm/W) LED 3000K 450lm (129lm/W) 476lm (135lm/W) 4000K 478lm (133lm/W) 487lm (138lm/W) Luminous Flux 2700K 350lm (89lm/W) 380lm (97lm/W) System 3000K 374lm (95lm/W) 400lm (102lm/W) 4000K 396lm (98lm/W) 409lm (104lm/W) (Values based on Juno Reflector) Beam angle 44° / Soft beam LED Power 3.5W (excl. driver) System Power 3.9W (incl. driver) Current 150mA Forward voltage 21V (min.) - 23.4V (typ.) - 25.8V (max.) Weight: 200g (excl. driver) 359° 33° Ø54mm Power supply Non dim.: min. 50mm Dimmable: min. 120mm Air circulation notice: Do not topload with insulation materials Ceiling thickness min. 9mm Width: 58mm Length: 58mm Height: 38mm Build-in depth: 50mm (non dim) 120mm (dimmable) Trapezium springs Bended steel sides for easy Insertion & removal in ceiling

35 Juno Mix Deep Square Soft Beam Independant driver included in article and pricing Soft Beam - Non dim 2700K - Ra97 - 3.9W - 350lm 1516.44.24.H27.XX € 106.10 3000K - Ra97 - 3.9W - 374lm 1516.44.24.H30.XX € 106.10 4000K - Ra97 - 3.9W - 396lm 1516.44.24.H40.XX € 106.10 Soft Beam - 1-10V dim 2700K - Ra97 - 3.9W - 350lm 1516.44.25.H27.XX € 131.20 3000K - Ra97 - 3.9W - 374lm 1516.44.25.H30.XX € 131.20 4000K - Ra97 - 3.9W - 396lm 1516.44.25.H40.XX € 131.20 Soft Beam - DALI dim 2700K - Ra97 - 3.9W - 350lm 1516.44.26.H27.XX € 137.60 3000K - Ra97 - 3.9W - 374lm 1516.44.26.H30.XX € 137.60 4000K - Ra97 - 3.9W - 396lm 1516.44.26.H40.XX € 137.60 Soft Beam - Push/Touch dim 2700K - Ra97 - 3.9W - 350lm 1516.44.29.H27.XX € 131.20 3000K - Ra97 - 3.9W - 374lm 1516.44.29.H30.XX € 131.20 4000K - Ra97 - 3.9W - 396lm 1516.44.29.H40.XX € 131.20 Juno Mix Deep Square Reflector Independant driver included in article and pricing 44° Reflector - Non dim 2700K - Ra97 - 3.9W - 350lm 1515.44.24.H27.XX € 113.40 3000K - Ra97 - 3.9W - 374lm 1515.44.24.H30.XX € 113.40 4000K - Ra97 - 3.9W - 396lm 1515.44.24.H40.XX € 113.40 44° Reflector - 1-10V dim 2700K - Ra97 - 3.9W - 350lm 1515.44.25.H27.XX € 138.50 3000K - Ra97 - 3.9W - 374lm 1515.44.25.H30.XX € 138.50 4000K - Ra97 - 3.9W - 396lm 1515.44.25.H40.XX € 138.50 44° Reflector - DALI dim 2700K - Ra97 - 3.9W - 350lm 1515.44.26.H27.XX € 145.10 3000K - Ra97 - 3.9W - 374lm 1515.44.26.H30.XX € 145.10 4000K - Ra97 - 3.9W - 396lm 1515.44.26.H40.XX € 145.10 44° Reflector - Push/Touch dim 2700K - Ra97 - 3.9W - 350lm 1515.44.29.H27.XX € 138.50 3000K - Ra97 - 3.9W - 374lm 1515.44.29.H30.XX € 138.50 4000K - Ra97 - 3.9W - 396lm 1515.44.29.H40.XX € 138.50 *UGR <19 for Juno Soft Beam Black Matt Texture. 01 15 18 07 03 25 16 36 40 More info see “Color info” p.421 Colors Standard 01 - White Matt Texture 18 - Grey Matt Texture 07 - Anthracite Matt Text. 03 - Black Matt Texture 25 - Smoked Brown Text. 36 - Bronze Colors Special 15 - Corten........................... +€ 35.30 16 - Gold.............................. +€ 35.30 40 - Champagne. ................ +€ 35.30 00000.00.CCC.XX Available colors (see below) Other RAL colors on request Hxx: CRI 97 (standard) 9xx: CRI 90 CRI97

36 Juno IP54 Round & Square Type Downlight Mounting Recessed Material Aluminium Adjustable No El. class / IP Class III / IP54 El. class driver Class II Warranty: see p.443 Bridgelux Vero 10 LED (150mA) CCT 4000K CRI Ra97 (Ra90 on request) SDCM 3 Ra97 Ra90 Luminous Flux 4000K 478lm (133lm/W) 487lm (138lm/W) LED Luminous Flux 4000K 396lm (98lm/W) 409lm (104lm/W) System (Values based on Juno Reflector) Beam angle 44° / Soft beam LED Power 3.5W (excl. driver) System Power 3.9W (incl. driver) Current 150mA Forward voltage 21V (min.) - 23.4V (typ.) - 25.8V (max.) Outside diameter: Ø50mm Total height: 28mm Build-in depth: min. 50 mm Total height: 28mm Build-in depth: min. 50 mm Width: 50mm Length: 50mm Bended steel sides for easy insertion & removal in ceiling Trapezium springs IP54 Weight: 200g (excl. driver) Ø43mm Power supply min. 50mm Air circulation notice: Do not topload with insulation materials Ceiling thickness min. 9mm

37 Juno IP54 Square Soft Beam Independant driver included in article and pricing Soft Beam - Non dim 4000K - Ra97 - 3.9W - 396lm 1518.44.24.H40.XX € 140.20 Juno IP54 Round Soft Beam Independant driver included in article and pricing Soft Beam - Non dim 4000K - Ra97 - 3.9W - 396lm 1517.44.24.H40.XX € 149.70 Dimmable drivers for remote placement available on request *Important note: Using silicone compound increases the CCT (color temperature) Example: Utilizing 3000K LEDs results in an increase to approx. 4300K IP54 *UGR <19 for Juno Soft Beam Black Matt Texture. 01 15 18 07 03 25 16 36 40 More info see “Color info” p.421 Colors Standard 01 - White Matt Texture 18 - Grey Matt Texture 07 - Anthracite Matt Text. 03 - Black Matt Texture 25 - Smoked Brown Text. 36 - Bronze Colors Special 15 - Corten........................... +€ 26.50 16 - Gold.............................. +€ 26.50 40 - Champagne. ................ +€ 26.50 00000.00.CCC.XX Available colors (see below) Other RAL colors on request H40: CRI 97 (standard) 940: CRI 90 CRI97

38 Juno Orientation Optic diffuser inside for soft and diffuse light Powdercoated aluminium front for blocking glare Detail: Weight: 200g Outside diameter: Ø50mm Total height: 28mm Build-in depth: min. 50 mm Type Orientation lighting Mounting Recessed Material Aluminium Adjustable No El. class / IP Class III / IP20 El. class driver Class II Warranty: see p.443 Bridgelux Vero 10 LED (150mA) CCT 2700K / 3000K / 4000K CRI Ra97 (Ra90 on request) SDCM 3 Ra97 Ra90 Luminous Flux 2700K 421lm (120lm/W) 458lm (130lm/W) LED 3000K 450lm (129lm/W) 476lm (135lm/W) 4000K 478lm (133lm/W) 487lm (138lm/W) Luminous Flux 2700K 350lm (89lm/W) 380lm (97lm/W) System 3000K 374lm (95lm/W) 400lm (102lm/W) 4000K 396lm (98lm/W) 409lm (104lm/W) (Values based on Juno Reflector) Beam angle 44° / Soft beam LED Power 3.5W (excl. driver) System Power 3.9W (incl. driver) Current 150mA Forward voltage 21V (min.) - 23.4V (typ.) - 25.8V (max.) Total height: 28mm Build-in depth: min. 50 mm Width: 50mm Length: 50mm Bended steel sides for easy insertion & removal in ceiling Trapezium springs (excl. driver) Ø43mm

39 Juno Orientation Square Independant driver included in article and pricing Soft Beam - Non dim 2700K - Ra97 - 3.9W - 350lm 1508.44.24.H27.XX € 116.40 3000K - Ra97 - 3.9W - 374lm 1508.44.24.H30.XX € 116.40 4000K - Ra97 - 3.9W - 396lm 1508.44.24.H40.XX € 116.40 Juno Orientation Round Independant driver included in article and pricing Soft Beam - Non dim 2700K - Ra97 - 3.9W - 350lm 1509.44.24.H27.XX € 115.50 3000K - Ra97 - 3.9W - 374lm 1509.44.24.H30.XX € 115.50 4000K - Ra97 - 3.9W - 396lm 1509.44.24.H40.XX € 115.50 Dimmable drivers for remote placement available on request 01 15 18 07 03 25 16 36 40 More info see “Color info” p.421 Colors Standard 01 - White Matt Texture 18 - Grey Matt Texture 07 - Anthracite Matt Text. 03 - Black Matt Texture 25 - Smoked Brown Text. 36 - Bronze Colors Special 15 - Corten........................... +€ 29.50 16 - Gold.............................. +€ 29.50 40 - Champagne. ................ +€ 29.50 00000.00.CCC.XX Available colors (see below) Other RAL colors on request Hxx: CRI 97 (standard) 9xx: CRI 90 CRI97

40 Vesto Single Power supply min. 95mm Air circulation notice: Do not topload with insulation materials For easy placement and removal in ceiling Boobytrap springs Ceiling thickness min. 9mm Type Downlight Mounting Recessed Material Aluminium Adjustable No El. class / IP Class III / IP20 El. class driver Class II Warranty: see p.443 CREE CXB LED (350mA) CCT 2700K / 3000K / 4000K CRI Ra90 (Ra98 on request) SDCM 3 Ra90 Ra98 Luminous Flux 2700K 346lm (115lm/W) 403lm (136lm/W) LED 3000K 374lm (125lm/W) 408lm (137lm/W) 4000K 401lm (134lm/W) 438lm (147lm/W) Luminous Flux 2700K 280lm (82lm/W) 307lm (92lm/W) System 3000K 302lm (88lm/W) 310lm (93lm/W) 4000K 324lm (95lm/W) 334lm (100lm/W) LED Power 3.0W (excl. driver) System Power 3.4W (incl. driver) Current 350mA Forward voltage 8.6V (typ.) CREE CXB LED (500mA) CCT 2700K / 3000K / 4000K CRI Ra90 (Ra98 on request) SDCM 3 Ra90 Ra98 Luminous Flux 2700K 468lm (106lm/W) 545lm (124lm/W) LED 3000K 505lm (114lm/W) 550lm (125lm/W) 4000K 542lm (123lm/W) 592lm (134lm/W) Luminous Flux 2700K 378lm (76lm/W) 415lm (84lm/W) System 3000K 408lm (82lm/W) 419lm (85lm/W) 4000K 438lm (88lm/W) 451lm (91lm/W) LED Power 4.4W (excl. driver) System Power 5.0W (incl. driver) Current 500mA Forward voltage 8.9V (typ.) 52x52mm (+4/-0) Outside measurements: 62x62mm Height: 75mm Build-in depth: 95mm 350mA/500mA Weight: 200g (excl. driver) Optional Protection glass for Vesto Single (1pc) 1066.00.00.000.00 € 7.50

41 Vesto 350 Single Independant driver included in article and pricing Non dim 350mA 2700K - Ra90 - 3.4W - 280lm 1066.AA.24.927.XX € 104.70 3000K - Ra90 - 3.4W - 302lm 1066.AA.24.930.XX € 104.70 4000K - Ra90 - 3.4W - 324lm 1066.AA.24.940.XX € 104.70 1-10V dim 350mA 2700K - Ra90 - 3.4W - 280lm 1066.AA.25.927.XX € 139.20 3000K - Ra90 - 3.4W - 302lm 1066.AA.25.930.XX € 139.20 4000K - Ra90 - 3.4W - 324lm 1066.AA.25.940.XX € 139.20 DALI dim 350mA 2700K - Ra90 - 3.4W - 280lm 1066.AA.26.927.XX € 147.10 3000K - Ra90 - 3.4W - 302lm 1066.AA.26.930.XX € 147.10 4000K - Ra90 - 3.4W - 324lm 1066.AA.26.940.XX € 147.10 Mains dim 1x Vesto Single: not available 2x Vesto Single connected in series: on request* 3x/4x Vesto Single connected in series: on request* *max. distance driver to last Vesto in loop: 15m (wire diam. min. 1mm²) Push/Touch dim 350mA 2700K - Ra90 - 3.4W - 280lm 1066.AA.29.927.XX € 139.20 3000K - Ra90 - 3.4W - 302lm 1066.AA.29.930.XX € 139.20 4000K - Ra90 - 3.4W - 324lm 1066.AA.29.940.XX € 139.20 Vesto 500 Single Independant driver included in article and pricing Non dim 500mA 2700K - Ra90 - 5.0W - 378lm 1096.AA.24.927.XX € 124.80 3000K - Ra90 - 5.0W - 408lm 1096.AA.24.930.XX € 124.80 4000K - Ra90 - 5.0W - 438lm 1096.AA.24.940.XX € 124.80 1-10V dim 500mA 2700K - Ra90 - 5.0W - 378lm 1096.AA.25.927.XX € 139.20 3000K - Ra90 - 5.0W - 408lm 1096.AA.25.930.XX € 139.20 4000K - Ra90 - 5.0W - 438lm 1096.AA.25.940.XX € 139.20 DALI dim 500mA 2700K - Ra90 - 5.0W - 378lm 1096.AA.26.927.XX € 147.10 3000K - Ra90 - 5.0W - 408lm 1096.AA.26.930.XX € 147.10 4000K - Ra90 - 5.0W - 438lm 1096.AA.26.940.XX € 147.10 Mains dim 500mA 2700K - Ra90 - 5.0W - 378lm 1096.AA.27.927.XX € 139.20 3000K - Ra90 - 5.0W - 408lm 1096.AA.27.930.XX € 139.20 4000K - Ra90 - 5.0W - 438lm 1096.AA.27.940.XX € 139.20 Push/Touch dim 500mA 2700K - Ra90 - 5.0W - 378lm 1096.AA.29.927.XX € 139.20 3000K - Ra90 - 5.0W - 408lm 1096.AA.29.930.XX € 139.20 4000K - Ra90 - 5.0W - 438lm 1096.AA.29.940.XX € 139.20 01 18 11 07 12 03 41 05 42 25 16 36 40 More info see “Color info” p.421 Colors Standard 01 - White Matt Texture 18 - Grey Matt Texture 07 - Anthracite Matt Text. 03 - Black Matt Texture 05 - White + Black 25 - Smoked Brown Text. 36 - Bronze 15 Colors Special 15 - Corten........................... +€ 35.30 11 - Black + Gold................ +€ 29.50 12 - White + Gold................ +€ 29.50 41 - Black + Champagne.... +€ 29.50 42 - White + Champagne ... +€ 29.50 16 - Gold.............................. +€ 35.30 40 - Champagne. ................ +€ 35.30 36: 36° Reflector 55: 55° Reflector 00000.AA.CCC.XX Available colors (see below) Other RAL colors on request 9xx: CRI 90 (standard) Hxx: CRI 98 CRI98 Available *In combination with optional front glass.

42 Vesto Double Power supply min. 95mm Air circulation notice: Do not topload with insulation materials Ceiling thickness min. 9mm Type Downlight Mounting Recessed Material Aluminium Adjustable No El. class / IP Class III / IP20 El. class driver Class II Warranty: see p.443 CREE CXB LED (350mA) CCT 2700K / 3000K / 4000K CRI Ra90 (Ra98 on request) SDCM 3 Ra90 Ra98 Luminous Flux 2700K 346lm (115lm/W) 403lm (136lm/W) LED 3000K 374lm (125lm/W) 408lm (137lm/W) 4000K 401lm (134lm/W) 438lm (147lm/W) Luminous Flux 2700K 280lm (82lm/W) 307lm (92lm/W) System 3000K 302lm (88lm/W) 310lm (93lm/W) 4000K 324lm (95lm/W) 334lm (100lm/W) LED Power 3.0W (excl. driver) System Power 3.4W (incl. driver) Current 350mA Forward voltage 8.6V (typ.) CREE CXB LED (500mA) CCT 2700K / 3000K / 4000K CRI Ra90 (Ra98 on request) SDCM 3 Ra90 Ra98 Luminous Flux 2700K 468lm (106lm/W) 545lm (124lm/W) LED 3000K 505lm (114lm/W) 550lm (125lm/W) 4000K 542lm (123lm/W) 592lm (134lm/W) Luminous Flux 2700K 378lm (76lm/W) 415lm (84lm/W) System 3000K 408lm (82lm/W) 419lm (85lm/W) 4000K 438lm (88lm/W) 451lm (91lm/W) LED Power 4.4W (excl. driver) System Power 5.0W (incl. driver) Current 500mA Forward voltage 8.9V (typ.) 52x93mm (+4/-0) For easy placement and removal in ceiling Boobytrap springs Outside measurements: 103x62mm Height: 75mm Build-in depth: 95mm 350mA/500mA Weight: 380g (excl. driver) Optional Protection glass for Vesto Double (2pcs) 1067.00.00.000.00 € 15.00

43 Vesto 500 Double Independant driver included in article and pricing Non dim 500mA (2x) 2700K - Ra90 - 5.0W - 378lm 1097.AA.24.927.XX € 167.00 (2x) 3000K - Ra90 - 5.0W - 408lm 1097.AA.24.930.XX € 167.00 (2x) 4000K - Ra90 - 5.0W - 438lm 1097.AA.24.940.XX € 167.00 1-10V dim (2x) 2700K - Ra90 - 5.0W - 378lm 1097.AA.25.927.XX € 181.20 (2x) 3000K - Ra90 - 5.0W - 408lm 1097.AA.25.930.XX € 181.20 (2x) 4000K - Ra90 - 5.0W - 438lm 1097.AA.25.940.XX € 181.20 DALI dim 500mA (2x) 2700K - Ra90 - 5.0W - 378lm 1097.AA.26.927.XX € 189.00 (2x) 3000K - Ra90 - 5.0W - 408lm 1097.AA.26.930.XX € 189.00 (2x) 4000K - Ra90 - 5.0W - 438lm 1097.AA.26.940.XX € 189.00 Mains dim 500mA (2x) 2700K - Ra90 - 5.0W - 378lm 1097.AA.27.927.XX € 181.20 (2x) 3000K - Ra90 - 5.0W - 408lm 1097.AA.27.930.XX € 181.20 (2x) 4000K - Ra90 - 5.0W - 438lm 1097.AA.27.940.XX € 181.20 Push/Touch dim 500mA (2x) 2700K - Ra90 - 5.0W - 378lm 1097.AA.29.927.XX € 181.20 (2x) 3000K - Ra90 - 5.0W - 408lm 1097.AA.29.930.XX € 181.20 (2x) 4000K - Ra90 - 5.0W - 438lm 1097.AA.29.940.XX € 181.20 Vesto 350 Double Independant driver included in article and pricing Non dim 350mA (2x) 2700K - Ra90 - 3.4W - 280lm 1067.AA.24.927.XX € 146.80 (2x) 3000K - Ra90 - 3.4W - 302lm 1067.AA.24.930.XX € 146.80 (2x) 4000K - Ra90 - 3.4W - 324lm 1067.AA.24.940.XX € 146.80 1-10V dim (2x) 2700K - Ra90 - 3.4W - 280lm 1067.AA.25.927.XX € 181.20 (2x) 3000K - Ra90 - 3.4W - 302lm 1067.AA.25.930.XX € 181.20 (2x) 4000K - Ra90 - 3.4W - 324lm 1067.AA.25.940.XX € 181.20 DALI dim 350mA (2x) 2700K - Ra90 - 3.4W - 280lm 1067.AA.26.927.XX € 189.00 (2x) 3000K - Ra90 - 3.4W - 302lm 1067.AA.26.930.XX € 189.00 (2x) 4000K - Ra90 - 3.4W - 324lm 1067.AA.26.940.XX € 189.00 Mains dim 350mA (2x) 2700K - Ra90 - 3.4W - 280lm 1067.AA.27.927.XX € 142.60 (2x) 3000K - Ra90 - 3.4W - 302lm 1067.AA.27.930.XX € 142.60 (2x) 4000K - Ra90 - 3.4W - 324lm 1067.AA.27.940.XX € 142.60 Push/Touch dim 350mA (2x) 2700K - Ra90 - 3.4W - 280lm 1067.AA.29.927.XX € 181.20 (2x) 3000K - Ra90 - 3.4W - 302lm 1067.AA.29.930.XX € 181.20 (2x) 4000K - Ra90 - 3.4W - 324lm 1067.AA.29.940.XX € 181.20 More info see “Color info” p.421 Colors Standard 01 - White Matt Texture 18 - Grey Matt Texture 07 - Anthracite Matt Text. 03 - Black Matt Texture 05 - White + Black 25 - Smoked Brown Text. 36 - Bronze 01 18 11 07 12 03 41 05 42 25 16 36 40 15 Colors Special 15 - Corten........................... +€ 35.30 11 - Black + Gold................ +€ 29.50 12 - White + Gold................ +€ 29.50 41 - Black + Champagne.... +€ 29.50 42 - White + Champagne ... +€ 29.50 16 - Gold.............................. +€ 35.30 40 - Champagne. ................ +€ 35.30 36: 36° Reflector 55: 55° Reflector 00000.AA.CCC.XX Available colors (see below) Other RAL colors on request 9xx: CRI 90 (standard) Hxx: CRI 98 *In combination with optional front glass. CRI98 Available

44 Type Downlight Mounting Recessed Material Aluminium Adjustable No El. class / IP Class III / IP20 El. class driver Class II Warranty: see p.443 CREE CXB LED (350mA) CCT 2700K / 3000K / 4000K CRI Ra90 (Ra98 on request) SDCM 3 Ra90 Ra98 Luminous Flux 2700K 346lm (115lm/W) 403lm (136lm/W) LED 3000K 374lm (125lm/W) 408lm (137lm/W) 4000K 401lm (134lm/W) 438lm (147lm/W) Luminous Flux 2700K 280lm (82lm/W) 307lm (92lm/W) System 3000K 302lm (88lm/W) 310lm (93lm/W) 4000K 324lm (95lm/W) 334lm (100lm/W) LED Power 3.0W (excl. driver) System Power 3.4W (incl. driver) Current 350mA Forward voltage 8.6V (typ.) CREE CXB LED (500mA) CCT 2700K / 3000K / 4000K CRI Ra90 (Ra98 on request) SDCM 3 Ra90 Ra98 Luminous Flux 2700K 468lm (106lm/W) 545lm (124lm/W) LED 3000K 505lm (114lm/W) 550lm (125lm/W) 4000K 542lm (123lm/W) 592lm (134lm/W) Luminous Flux 2700K 378lm (76lm/W) 415lm (84lm/W) System 3000K 408lm (82lm/W) 419lm (85lm/W) 4000K 438lm (88lm/W) 451lm (91lm/W) LED Power 4.4W (excl. driver) System Power 5.0W (incl. driver) Current 500mA Forward voltage 8.9V (typ.) 52x135mm (+4/-0) Power supply min. 95mm Air circulation notice: Do not topload with insulation materials Ceiling thickness min. 9mm Vesto Triple For easy placement and removal in ceiling Boobytrap springs Outside measurements: 145x62mm Height: 75mm Build-in depth: 95mm 350mA/500mA Weight: 520g (excl. driver) Optional Protection glass for Vesto Triple (3pcs) 1068.00.00.000.00 € 22.50

45 Vesto 350 Triple Independant driver included in article and pricing Non dim 350mA (3x) 2700K - Ra90 - 3.4W - 280lm 1068.AA.24.927.XX € 188.80 (3x) 3000K - Ra90 - 3.4W - 302lm 1068.AA.24.930.XX € 188.80 (3x) 4000K - Ra90 - 3.4W - 324lm 1068.AA.24.940.XX € 188.80 1-10V dim 350mA (3x) 2700K - Ra90 - 3.4W - 280lm 1068.AA.25.927.XX € 223.30 (3x) 3000K - Ra90 - 3.4W - 302lm 1068.AA.25.930.XX € 223.30 (3x) 4000K - Ra90 - 3.4W - 324lm 1068.AA.25.940.XX € 223.30 DALI dim 350mA (3x) 2700K - Ra90 - 3.4W - 280lm 1068.AA.26.927.XX € 231.20 (3x) 3000K - Ra90 - 3.4W - 302lm 1068.AA.26.930.XX € 231.20 (3x) 4000K - Ra90 - 3.4W - 324lm 1068.AA.26.940.XX € 231.20 Mains dim 350mA (3x) 2700K - Ra90 - 3.4W - 280lm 1068.AA.27.927.XX € 223.30 (3x) 3000K - Ra90 - 3.4W - 302lm 1068.AA.27.930.XX € 223.30 (3x) 4000K - Ra90 - 3.4W - 324lm 1068.AA.27.940.XX € 223.30 Push/Touch dim 350mA (3x) 2700K - Ra90 - 3.4W - 280lm 1068.AA.29.927.XX € 223.30 (3x) 3000K - Ra90 - 3.4W - 302lm 1068.AA.29.930.XX € 223.30 (3x) 4000K - Ra90 - 3.4W - 324lm 1068.AA.29.940.XX € 223.30 Vesto 500 Triple Independant driver included in article and pricing Non dim 500mA (3x) 2700K - Ra90 - 5.0W - 378lm 1098.AA.24.927.XX € 182.90 (3x) 3000K - Ra90 - 5.0W - 408lm 1098.AA.24.930.XX € 182.90 (3x) 4000K - Ra90 - 5.0W - 438lm 1098.AA.24.940.XX € 182.90 1-10V dim 500mA (3x) 2700K - Ra90 - 5.0W - 378lm 1098.AA.25.927.XX € 223.30 (3x) 3000K - Ra90 - 5.0W - 408lm 1098.AA.25.930.XX € 223.30 (3x) 4000K - Ra90 - 5.0W - 438lm 1098.AA.25.940.XX € 223.30 DALI dim 500mA (3x) 2700K - Ra90 - 5.0W - 378lm 1098.AA.26.927.XX € 231.20 (3x) 3000K - Ra90 - 5.0W - 408lm 1098.AA.26.930.XX € 231.20 (3x) 4000K - Ra90 - 5.0W - 438lm 1098.AA.26.940.XX € 231.20 Mains dim 500mA (3x) 2700K - Ra90 - 5.0W - 378lm 1098.AA.27.927.XX € 223.30 (3x) 3000K - Ra90 - 5.0W - 408lm 1098.AA.27.930.XX € 223.30 (3x) 4000K - Ra90 - 5.0W - 438lm 1098.AA.27.940.XX € 223.30 Push/Touch dim 500mA (3x) 2700K - Ra90 - 5.0W - 378lm 1098.AA.29.927.XX € 223.30 (3x) 3000K - Ra90 - 5.0W - 408lm 1098.AA.29.930.XX € 223.30 (3x) 4000K - Ra90 - 5.0W - 438lm 1098.AA.29.940.XX € 223.30 More info see “Color info” p.421 Colors Standard 01 - White Matt Texture 18 - Grey Matt Texture 07 - Anthracite Matt Text. 03 - Black Matt Texture 05 - White + Black 25 - Smoked Brown Text. 36 - Bronze 01 18 11 07 12 03 41 05 42 25 16 36 40 15 Colors Special 15 - Corten........................... +€ 35.30 11 - Black + Gold................ +€ 29.50 12 - White + Gold................ +€ 29.50 41 - Black + Champagne.... +€ 29.50 42 - White + Champagne ... +€ 29.50 16 - Gold.............................. +€ 35.30 40 - Champagne. ................ +€ 35.30 36: 36° Reflector 55: 55° Reflector 00000.AA.CCC.XX Available colors (see below) Other RAL colors on request 9xx: CRI 90 (standard) Hxx: CRI 98 *In combination with optional front glass. CRI98 Available

46 Type Downlight Mounting Recessed Material Aluminium Adjustable No El. class / IP Class III / IP20 El. class driver Class II Warranty: see p.443 CREE CXB LED (350mA) CCT 2700K / 3000K / 4000K CRI Ra90 (Ra98 on request) SDCM 3 Ra90 Ra98 Luminous Flux 2700K 346lm (115lm/W) 403lm (136lm/W) LED 3000K 374lm (125lm/W) 408lm (137lm/W) 4000K 401lm (134lm/W) 438lm (147lm/W) Luminous Flux 2700K 280lm (82lm/W) 307lm (92lm/W) System 3000K 302lm (88lm/W) 310lm (93lm/W) 4000K 324lm (95lm/W) 334lm (100lm/W) LED Power 3.0W (excl. driver) System Power 3.4W (incl. driver) Current 350mA Forward voltage 8.6V (typ.) CREE CXB LED (500mA) CCT 2700K / 3000K / 4000K CRI Ra90 (Ra98 on request) SDCM 3 Ra90 Ra98 Luminous Flux 2700K 468lm (106lm/W) 545lm (124lm/W) LED 3000K 505lm (114lm/W) 550lm (125lm/W) 4000K 542lm (123lm/W) 592lm (134lm/W) Luminous Flux 2700K 378lm (76lm/W) 415lm (84lm/W) System 3000K 408lm (82lm/W) 419lm (85lm/W) 4000K 438lm (88lm/W) 451lm (91lm/W) LED Power 4.4W (excl. driver) System Power 5.0W (incl. driver) Current 500mA Forward voltage 8.9V (typ.) Power supply min. 95mm Air circulation notice: Do not topload with insulation materials Ceiling thickness min. 9mm Vesto Quadro 52x176mm (+4/-0) For easy placement and removal in ceiling Boobytrap springs Outside measurements: 186x62mm Height: 75mm Build-in depth: 95mm 350mA/500mA Weight: 700g (excl. driver) Optional Protection glass for Vesto Quadro (4pcs) 1069.00.00.000.00 € 30.00

47 Vesto 500 Quadro Independant driver included in article and pricing Non dim 500mA (4x) 2700K - Ra90 - 5.0W - 378lm 1099.AA.24.927.XX € 230.90 (4x) 3000K - Ra90 - 5.0W - 408lm 1099.AA.24.930.XX € 230.90 (4x) 4000K - Ra90 - 5.0W - 438lm 1099.AA.24.940.XX € 230.90 1-10V dim 500mA (4x) 2700K - Ra90 - 5.0W - 378lm 1099.AA.25.927.XX € 265.40 (4x) 3000K - Ra90 - 5.0W - 408lm 1099.AA.25.930.XX € 265.40 (4x) 4000K - Ra90 - 5.0W - 438lm 1099.AA.25.940.XX € 265.40 DALI dim 500mA (4x) 2700K - Ra90 - 5.0W - 378lm 1099.AA.26.927.XX € 273.30 (4x) 3000K - Ra90 - 5.0W - 408lm 1099.AA.26.930.XX € 273.30 (4x) 4000K - Ra90 - 5.0W - 438lm 1099.AA.26.940.XX € 273.30 Mains dim 500mA (4x) 2700K - Ra90 - 5.0W - 378lm 1099.AA.27.927.XX € 265.40 (4x) 3000K - Ra90 - 5.0W - 408lm 1099.AA.27.930.XX € 265.40 (4x) 4000K - Ra90 - 5.0W - 438lm 1099.AA.27.940.XX € 265.40 Push/Touch dim 500mA (4x) 2700K - Ra90 - 5.0W - 378lm 1099.AA.29.927.XX € 265.40 (4x) 3000K - Ra90 - 5.0W - 408lm 1099.AA.29.930.XX € 265.40 (4x) 4000K - Ra90 - 5.0W - 438lm 1099.AA.29.940.XX € 265.40 Vesto 350 Quadro Independant driver included in article and pricing Non dim 350mA (4x) 2700K - Ra90 - 3.4W - 280lm 1069.AA.24.927.XX € 230.90 (4x) 3000K - Ra90 - 3.4W - 302lm 1069.AA.24.930.XX € 230.90 (4x) 4000K - Ra90 - 3.4W - 324lm 1069.AA.24.940.XX € 230.90 1-10V dim 350mA (4x) 2700K - Ra90 - 3.4W - 280lm 1069.AA.25.927.XX € 265.40 (4x) 3000K - Ra90 - 3.4W - 302lm 1069.AA.25.930.XX € 265.40 (4x) 4000K - Ra90 - 3.4W - 324lm 1069.AA.25.940.XX € 265.40 DALI dim 350mA (4x) 2700K - Ra90 - 3.4W - 280lm 1069.AA.26.927.XX € 273.30 (4x) 3000K - Ra90 - 3.4W - 302lm 1069.AA.26.930.XX € 273.30 (4x) 4000K - Ra90 - 3.4W - 324lm 1069.AA.26.940.XX € 273.30 Mains dim 350mA (4x) 2700K - Ra90 - 3.4W - 280lm 1069.AA.27.927.XX € 265.40 (4x) 3000K - Ra90 - 3.4W - 302lm 1069.AA.27.930.XX € 265.40 (4x) 4000K - Ra90 - 3.4W - 324lm 1069.AA.27.940.XX € 265.40 Push/Touch dim 350mA (4x) 2700K - Ra90 - 3.4W - 280lm 1069.AA.29.927.XX € 265.40 (4x) 3000K - Ra90 - 3.4W - 302lm 1069.AA.29.930.XX € 265.40 (4x) 4000K - Ra90 - 3.4W - 324lm 1069.AA.29.940.XX € 265.40 More info see “Color info” p.421 Colors Standard 01 - White Matt Texture 18 - Grey Matt Texture 07 - Anthracite Matt Text. 03 - Black Matt Texture 05 - White + Black 25 - Smoked Brown Text. 36 - Bronze 01 15 18 11 07 12 03 41 05 42 25 16 36 40 Colors Special 15 - Corten........................... +€ 35.30 11 - Black + Gold................ +€ 29.50 12 - White + Gold................ +€ 29.50 41 - Black + Champagne.... +€ 29.50 42 - White + Champagne ... +€ 29.50 16 - Gold.............................. +€ 35.30 40 - Champagne. ................ +€ 35.30 36: 36° Reflector 55: 55° Reflector 00000.AA.CCC.XX Available colors (see below) Other RAL colors on request 9xx: CRI 90 (standard) Hxx: CRI 98 *In combination with optional front glass. CRI98 Available
