Fantasia Light Designers P r em i um Co l l e c t i o n Designed with passion in Belgium. The lights in this catalogue are part of the Fantasia Premium Collection. They are the result of a team of light designers with over 60 years of experience. We have a passion for beautiful, timeless, flexible and affordable designs. Discover our craftsmanship on www.fantasia.be
PREMIUM Catalogue EDITION 2023 PRODUCT COORDINATION Fantasia Verlichting NV DESIGN Tim Vanhoucke Welcome to our new Premium catalog. This catalogue represents a snapshot of the current collection. Novelties will be introduced throughout the year. Please use the following QR-code to access our premium website, which is frequently updated. In this new catalogue we introduce QR codes for every product family. Scan the QR codes, with the camera of your smartphone, to gain access to: - Detailed technical information about the item - Complete overview of items within a product family - Extra files, instructions, IES, LDT, ... - Demonstration and tutorial videos - ... Premium website:
Aeon LED spots AR111 → page 004 Box LED spots AR111 → page 010 Infinitus Profile for tracks → page 016 Lopal LED spots → page 026 Nobu E27 pendants → page 044 Nysit LED spots GU10 → page 048 Orbit LED spots → page 062 Pure LED lighting → page 076 Talu LED wall light → page 098 Xandar LED track lighting → page 100 Xolo LED pendants → page 104 Zolan LED spots GU10 → page 108 Zoom LED downlights GU10 → page 116 Zoom AR111 LED downlights AR111 → page 128 Hybriz gen 2 LED modules → page 132 Bulbs LED modules and bulbs → page 140 Coming soon → page 142
AEON - Unique and modern design with powerful replaceable LED spots - Rotate and tilt spot heads freely in any direction - Warm white light, powerful lumen output - Complete with replaceable dimmable driver and AR111 LED spots White version: 4014320 AEON 1 light, 1x AR111 LED 12,4 Watt 4014321 AEON 2 light, 2x AR111 LED 12,4 Watt 4014322 AEON 3 light, 3x AR111 LED 12,4 Watt 4014323 AEON 4 light, 4x AR111 LED 12,4 Watt
005
AEON - Unique and modern design with powerful replaceable LED spots - Rotate and tilt spot heads freely in any direction - Warm white light, powerful lumen output - Complete with dimmable driver and AR111 LED spots Black version: 4014325 AEON 1 light, 1x AR111 LED 12,4 Watt 4014326 AEON 2 light, 2x AR111 LED 12,4 Watt 4014327 AEON 3 light, 3x AR111 LED 12,4 Watt 4014328 AEON 4 light, 4x AR111 LED 12,4 Watt
007
AR111 LED 12,4 Watt 30° 2700K (8202705) 650 Lumen with lens cover 1386 Lumen without lens cover AR111 LED bulb overview: page 140 Dimmable bulb 0-100% * Dimmable driver included (3419052) Material: aluminium Colour: matte white matte black Power: 220-240 Volt 200mm 120mm 140mm 440mm 120mm 140mm 580mm 120mm 140mm 720mm 120mm 140mm 100% 0% * Bulbs dimmable when used with the correct LED dimmer. AEON 009
BOX - Industrial design with powerful replaceable LED spots - Rotate and tilt spot heads freely in any direction - Warm white light, powerful lumen output - Complete with dimmable driver and AR111 LED spots White version: 4014300 BOX 1 light round, 1x AR111 LED 12,4 Watt 4014301 BOX 1 light square, 1x AR111 LED 12,4 Watt 4014302 BOX 2 light, 2x AR111 LED 12,4 Watt 4014303 BOX 3 light, 3x AR111 LED 12,4 Watt 4014304 BOX 4 light, 4x AR111 LED 12,4 Watt
011
BOX - Industrial design with powerful replaceable LED spots - Rotate and tilt spot heads freely in any direction - Warm white light, powerful lumen output - Complete with dimmable driver and AR111 LED spots Black version: 4014305 BOX 1 light round, 1x AR111 LED 12,4 Watt 4014306 BOX 1 light square, 1x AR111 LED 12,4 Watt 4014307 BOX 2 light, 2x AR111 LED 12,4 Watt 4014308 BOX 3 light, 3x AR111 LED 12,4 Watt 4014309 BOX 4 light, 4x AR111 LED 12,4 Watt
013
120mm Ø120mm 120mm 120mm 120mm 120mm 120mm 120mm 241mm 120mm 120mm 241mm 241mm 360mm BOX AR111 LED 12,4 Watt 30° 2700K (8202705) 650 Lumen with lens cover 1386 Lumen without lens cover AR111 LED bulb overview: page 140 Dimmable bulb 0-100% * Dimmable driver included (3419052) Material: aluminium Colour: matte white matte black Power: 220-240 Volt 100% 0% * Bulbs dimmable when used with the correct LED dimmer. 015
INFINITUS - Modern sleek profile + monophase tracksystem - Can be installed directly on the ceiling or as a pendant - Compatible with monophase trackspots and pendants - Easy to expand (up to 20m max) - Max watt for total connected lights = 1200W Profile + monophase track + power supply + accessories: TR0200W INFINITUS Profile 1,2m white TR0200B INFINITUS Profile 1,2m black TR0201W INFINITUS Profile 1,8m white TR0201B INFINITUS Profile 1,8m black TR0202W INFINITUS Profile 2,9m white TR0202B INFINITUS Profile 2,9m black accessories: power supply, track endcap x 1, profile endcaps x2 Profile + monophase track, extension: TR0203W INFINITUS Profile 1,2m white TR0203B INFINITUS Profile 1,2m black TR0204W INFINITUS Profile 1,8m white TR0204B INFINITUS Profile 1,8m black TR0205W INFINITUS Profile 2,9m white TR0205B INFINITUS Profile 2,9m black Profile, empty (no internal track, no accessories): TR0210W INFINITUS Profile 3m white TR0210B INFINITUS Profile 3m black Internal connection pieces: TR0111B/W Monophase track linear connector TR0211B/W INFINITUS 60mm connection piece 40mm 70mm
017
INFINITUS - Modern sleek profile + monophase tracksystem - Can be installed directly on the ceiling or as a pendant - Compatible with monophase trackspots and pendants - Easy to expand (up to 20m max) - Max watt for total connected lights = 1200W Connection pieces: TR0206W INFINITUS T-connector white + choose according to earth wire position: TR0115W Monophase T-connector earthwire inside TR0116W Monophase T-connector earthwire outside TR0206B INFINITUS T-connector black + choose according to earth wire position: TR0115B Monophase T-connector earthwire inside TR0116B Monophase T-connector earthwire outside TR0207W INFINITUS L-connector white + choose according to earth wire position: TR0113W Monophase L-connector earthwire outside TR0114W Monophase L-connector earthwire inside TR0207B INFINITUS L-connector black + choose according to earth wire position: TR0113B Monophase L-connector earthwire outside TR0114B Monophase L-connector earthwire inside Endcaps: For Infinitus profile: TR0213W INFINITUS Profile endcap white TR0213B INFINITUS Profile endcap black For internal monophase track: TR0120W Monophase track endcap white TR0120B Monophase track endcap black 91mm 65mm 65mm 65mm
019
INFINITUS - Modern sleek profile + monophase tracksystem - Can be installed directly on the ceiling or as a pendant - Compatible with monophase trackspots and pendants - Easy to expand (up to 20m max) - Max watt for total connected lights = 1200W Pendant installation: TR0208W INFINITUS Suspension kit white TR0208B INFINITUS Suspension kit black Suspension kits consist of: 2x 5m steelcable 2x steelcable ceiling fixations 2x 60mm internal profile connection pieces TR0209W INFINITUS Power supply kit white TR0209B INFINITUS Power supply kit black Power supply kits consist of: 1x canopy 1x 5m powercable (maximum Amps (A) 10A, cable thickness 1.5mm) 1x 60mm internal profile connection piece 2x powercable strain relief Extras: TR0212 INFINITUS Screw guide Included with every profile, helps guide the screws inside the profile, during the installation. TR0214W INFINITUS Safety cover white, 1m TR0214B INFINITUS Safety cover black, 1m The safety cover protects the internal monophase track from external foreign objects and fingers. Recommended when installing the Infinitus on a wall.
021
INFINITUS Scan the QR codes below to get access to movies and an overview of the different parts available for the INFINITUS monophase tracksystem. DEMO MOVIE HOW TO MOVIES OVERVIEW PARTS
INFINITUS Compatible trackspots and pendants for the INFINITUS + monophase track from our premium collection. LOPAL trackspots LOPAL pendant, requires a track adapter (ref TR0123) More information about this series p. 026 NYSIT trackspots More information about this series p. 048 XANDAR trackspots More information about this series p. 100 ORBIT trackspots ORBIT pendants More information about this series p. 062
INFINITUS Compatible trackspots for the INFINITUS + monophase track from our deco collection. LITHIUM - Modern monophase trackspot - Warm white light (2700K), high lumen output - Also available in dim-to-warm (3000K - 2000K) TR0140B LITHIUM 12 Watt LED trackspot black TR0140W LITHIUM 12 Watt LED trackspot white TR0141B LITHIUM 12 Watt LED dim-to-warm trackspot black TR0141W LITHIUM 12 Watt LED dim-to-warm trackspot white XZIBIT - Decorative trackspot - Black with bronze details - Ready for GU10 (recommended bulb 8202652) TR0133B XZIBIT trackspot black / bronze, GU10 excluded TSURU - Decorative series with bronze accent and smoke grey glass - Pendants, wall light, floor and table lamp, and ceiling light available - G9 LED bulb included TR0134B TSURU track spot, G9 LED included
INFINITUS Compatible pendants for the INFINITUS + monophase track from our deco collection. Almost all LED, E14 and E27 pendants in our deco collection can be installed on the INFINITUS. How? Remove the canopy of the pendant and install a track adapter (TR0123). OONAH 3432136 OONAH 3432139 RAGA 3403550 KOBAR 3416240 KOBAR 3416230 KOBAR 3416220 TSURU 3416264 Scan the QR code to take a look at our deco catalog. More pendants can be found in the chapter ‘Modern’. If you are unsure if a specific pendant can be used with the INFINITUS, contact us for more information.
LOPAL - Modern and slim design - Small canopy (2,5 cm wide - 4 cm high) - Built-in dimmable AC COB LED - Warm white light, high lumen output White version: 4014350 LOPAL 1 light, complete with 1x 4,5 Watt AC COB LED 4014351 LOPAL 2 light, complete with 2x 4,5 Watt AC COB LED 4014352 LOPAL 3 light, complete with 3x 4,5 Watt AC COB LED 4014353 LOPAL 4 light, complete with 4x 4,5 Watt AC COB LED Gold inserts for all Lopal spots available separately (4014369)
027
LOPAL - Modern and slim design - Small canopy (2,5 cm wide - 4 cm high) - Built-in dimmable AC COB LED - Warm white light, high lumen output Black version: 4014360 LOPAL 1 light, complete with 1x 4,5 Watt AC COB LED 4014361 LOPAL 2 light, complete with 2x 4,5 Watt AC COB LED 4014362 LOPAL 3 light, complete with 3x 4,5 Watt AC COB LED 4014363 LOPAL 4 light, complete with 4x 4,5 Watt AC COB LED Gold inserts for all Lopal spots available separately (4014369)
Gold insert available separately (4014369) 029
LOPAL - Modern and slim design - Small canopy with light switch (2,5 cm wide - 4 cm high) - Flexible neck - Built-in dimmable AC COB LED - Warm white light, high lumen output Wall light: 4014354 LOPAL 1 light, wall light, complete with 4,5 Watt AC COB LED, white 4014364 LOPAL 1 light, wall light, complete with 4,5 Watt AC COB LED, black
LOPAL - Modern and slim design - Can easily be converted for use with tracks 1 phase track adapter: TR0123W, TR0123B - sold separately 3 phase track adapter: TR0023W, TR0023B - sold separately - Built-in dimmable AC COB LED - Warm white light, high lumen output Pendant: 4014355 LOPAL 1 light, pendant complete with 4,5 Watt AC COB LED, white 4014365 LOPAL 1 light, pendant complete with 4,5 Watt AC COB LED, black 031
LOPAL - Modern and slim design - Built-in dimmable AC COB LED - Warm white light, high lumen output Pendant: 4014358 LOPAL 5 light, pendant complete with 5x 4,5 Watt AC COB LED, white 4014368 LOPAL 5 light, pendant complete with 5x 4,5 Watt AC COB LED, black
033
LOPAL - Modern and slim design - Made for monophase tracks - Built-in dimmable AC COB LED - Warm white light, high lumen output Track light: TR0150W LOPAL 1 light, for 1-F tracks, complete with 4,5 Watt AC COB LED, white TR0150B LOPAL 1 light, for 1-F tracks, complete with 4,5 Watt AC COB LED, black 129mm 132mm 80mm 100mm
035
LOPAL - Insert for Zoom recessed spots (see page 123) - Can also be installed in Zolan spots (see page 108) - Built-in dimmable AC COB LED - Warm white light, high lumen output Lopal insert: 4014113 LOPAL insert, complete with 4,5 Watt AC COB LED, matte white 4014114 LOPAL insert, complete with 4,5 Watt AC COB LED, matte black
037
LOPAL - Modern and slim design - Table lamp with touch dimmer 0-100% - Built-in dimmable LED - Warm white light, high lumen output Table lamp: 4014356 LOPAL 2 light, complete with 2x 4 Watt LED, white 4014366 LOPAL 2 light, complete with 2x 4 Watt LED, black 400mm 150mm 100mm
039
LOPAL - Modern and slim design - Floor lamp with touch dimmer 0-100% - Built-in dimmable LED - Warm white light, high lumen output Floor lamp: 4014357 LOPAL 3 light, complete with 3x 4 Watt LED, white 4014367 LOPAL 3 light, complete with 3x 4 Watt LED, black 230mm 180mm 1600mm
041
LOPAL LED for spots LED 4,5 Watt 2700K 300 Lumen (90°) LED for table and floorlamp LED 4 Watt 2700K 320 Lumen (90°) CRI>80 Dimmable 0-100%* Material: aluminium Colour: matte white, matte black Power: 220-240 Volt Reflectors: 35° and 60° (Standard reflector spot: 35°, pendant: 60°) Gold insert: 4014369 100% 0% 90mm 25mm 40mm 137mm 100mm 137mm 40mm 25mm 180mm 137mm 40mm 25mm 270mm 137mm 40mm 25mm 360mm max 1500mm Ø56mm Ø34,5mm max 180mm max 263mm 90mm 25mm 40mm 250mm 1000mm 40mm max 1500mm * Dimmable when used with the correct LED dimmer. 043
NOBU - Modern pendant ready for E27 LED retrofit bulbs - Available completely in white or black with bronze accent - Impressive size, 60cm diameter Available versions: 3432160 NOBU Pendant E27 white 3432161 NOBU Pendant E27 black / bronze
045
NOBU Ready for E27 LED retrofit bulbs Material: aluminium Colour: matte white matte black + bronze Power: 220-240 Volt 3060mm 419mm 600mm 047
NYSIT - Complete with dimmable and replaceable LED spots - Warm white light - Cover available in black, white, concrete look - Cilinders available in black, white, aluminium, concrete look, antique copper and gold leaf - The cilinders and cover can be customized and painted in any RAL colour (on request) - The base of the fixture is always black Premade - black base, white cover, white cilinders: 3427091 NYSIT 1 light, 1x GU10 LED 4,5 Watt included 3427092 NYSIT 2 light, 2x GU10 LED 4,5 Watt included 3427093 NYSIT 3 light, 3x GU10 LED 4,5 Watt included 3427094 NYSIT 4 light, 4x GU10 LED 4,5 Watt included
049
NYSIT Premade - black base, black cover, black cilinders: 3427101 NYSIT 1 light, 1x GU10 LED 4,5 Watt included 3427102 NYSIT 2 light, 2x GU10 LED 4,5 Watt included 3427103 NYSIT 3 light, 3x GU10 LED 4,5 Watt included 3427104 NYSIT 4 light, 4x GU10 LED 4,5 Watt included
051
NYSIT Premade - black base, white cover, black cilinders: 3427081 NYSIT 1 light, 1x GU10 LED 4,5 Watt included 3427082 NYSIT 2 light, 2x GU10 LED 4,5 Watt included 3427083 NYSIT 3 light, 3x GU10 LED 4,5 Watt included 3427084 NYSIT 4 light, 4x GU10 LED 4,5 Watt included
Premade: 3427105 NYSIT 7 light, 7x GU10 LED 4,5 Watt included 3427195 NYSIT 7 light, 7x GU10 LED 4,5 Watt included 053
NYSIT Custom-made Choose and combine different colours for the cilinders and cover, to create your own Nysit version. Covers : White Black Concrete 1 light 3427165 3427166 3427185 2 light 3427168 3427169 3427186 3 light 3427171 3427172 3427187 4 light 3427174 3427175 3427188 Cilinders : 3427177 white 3427178 black 3427179 aluminium 3427181 gold leaf 3427182 concrete look 3427183 antique copper Base (bulbs included) : 3427160 1 light base 3427161 2 light base 3427162 3 light base 3427163 4 light base Easy installation : Attach base to ceiling. Attach cover to base using preinstalled magnets. Put light bulbs in. Slide cilinder into place over light bulb. Bulbs, cover and cilinders are easily replaced or changed.
055
NYSIT Custom-made - black base, choose a cover colour, choose the cilinders: base: 3427160, cover concrete: 3427185, cilinder concrete: 3427182, 1 light, 1x GU10 LED 4,5 Watt included base: 3427161, cover black: 3427169, cilinder white: 2x 3427177, 2 light, 2x GU10 LED 4,5 Watt included base: 3427162, cover concrete: 3427187, cilinder concrete: 3x 3427182, 3 light, 3x GU10 LED 4,5 Watt included base: 3427163, cover black: 3427175, cilinder aluminium: 4x 3427179, 4 light, 4x GU10 LED 4,5 Watt included
Custom-made - black base, choose a cover colour, choose the cilinders: base: 3427160, cover black: 3427166, cilinder gold: 3427181, 1 light, 1x GU10 LED 4,5 Watt included base: 3427161, cover black: 3427169, cilinder aluminium: 2x 3427179, 2 light, 2x GU10 LED 4,5 Watt included base: 3427162, cover black: 3427172, cilinder white: 3x 3427177, 3 light, 3x GU10 LED 4,5 Watt included base: 3427163, cover white: 3427174, cilinder gold: 4x 3427181, 4 light, 4x GU10 LED 4,5 Watt included 057
NYSIT Custom-made - black base, choose a cover colour, choose the cilinders: base: 3427160, cover white: 3427165, cilinder bronze: 3427183, 1 light, 1x GU10 LED 4,5 Watt included base: 3427161, cover black: 3427169, cilinder bronze: 2x 3427183, 2 light, 2x GU10 LED 4,5 Watt included base: 3427162, cover white: 3427171, cilinder bronze: 3x 3427183, 3 light, 3x GU10 LED 4,5 Watt included base: 3427163, cover black: 3427175, cilinder white: 4x 3427177, 4 light, 4x GU10 LED 4,5 Watt included
- Ready for GU10 LED spots (recommended bulb 8202650) - Made for monophase tracks - Cilinders available in black, white, aluminium, concrete look, antique copper and gold leaf Premade: TR0131B NYSIT track spot black, GU10 LED excluded TR0131W NYSIT track spot white, GU10 LED excluded 059
GU10 LED (8202650) 4,5 Watt 246 Lumen (90°) 2700K CRI >90 Dimmable bulb 0-100% * Material: aluminium and steel Colour: choose pre-made models -or- pick and match cilinder and cover colours to create your own version Power: 220-240 Volt 100% 0% 120mm 120mm 120mm 120mm 120mm 80mm 120mm 120mm 120mm 120mm 120mm 1135mm 650mm 500mm 350mm 200mm NYSIT 132mm 82mm * Bulbs dimmable when used with the correct LED dimmer. 061
ORBIT The ORBIT is a series of lighting fixtures with multi-functional optics and different kinds of profiles. Available as spotlight and pendant for monophase tracks, and as wall light and ceiling pendant. Easily switch between 6W and 9W on the LED chip. The base of the ORBIT is always black, choose the correct optic and a corresponding insert, to create a light that suits your needs. The ORBIT is dimmable, has warm white light 2700K, and a CRI >90. 4 different profiles and optics to choose from: BIG LENS The BIG LENS features a large and flat optic, it is a three-quarters spherical accessory with a minimum beam angle of 10°. Optics available in 10°, 20°, 36° and 60° MINI LENS The MINI LENS is a spherical accessory with a mini recessed anti-glare reflector. Optics available in 18°, 30°, 42° and 55° Inserts available in different colours, gold, white, black and specular. FLOOD LENS The FLOOD LENS is a spherical accessory providing ambient lighting and flood lighting with a milky white diffuser optic (150°). DECORATIVE LENS The DECORATIVE LENS is a spherical accessory featuring flat cilinder optics with anti-glare and a decorative reflector. Optics available in 15°, 24°, 36° and 60° Inserts available in different colours, gold, white, black and specular.
ORBIT The ORBIT is a series of lighting fixtures with multi-functional optics and inserts. 063
ORBIT BIG LENS The BIG LENS features a large and flat optic, it is a three-quarters spherical accessory with a minimum beam angle of 10°. Optics available in 10°, 20°, 36° and 60° ORBIT BASE TR0143B ORBIT Trackspot 6W/9W 2700K Dimmable, black TR0144B ORBIT Track pendant 6W/9W 2700K Dimmable, black 8203430 ORBIT Pendant 6W/9W 2700K Dimmable, black 8203431 ORBIT Wall light 6W/9W 2700K Dimmable, black BIG LENS OPTICS 8202440-10 ORBIT Big lens 10° 8202440-20 ORBIT Big lens 20° 8202440-36 ORBIT Big lens 36° 8202440-60 ORBIT Big lens 60°
BIG LENS The BIG LENS features a large and flat optic, it is a three-quarters spherical accessory with a minimum beam angle of 10°. 065
ORBIT MINI LENS The MINI LENS is a spherical accessory with a mini recessed anti-glare reflector. Optics available in 18°, 30°, 42° and 55° ORBIT BASE TR0143B ORBIT Trackspot 6W/9W 2700K Dimmable, black TR0144B ORBIT Track pendant 6W/9W 2700K Dimmable, black 8203430 ORBIT Pendant 6W/9W 2700K Dimmable, black 8203431 ORBIT Wall light 6W/9W 2700K Dimmable, black MINI LENS OPTICS 8202441-18 ORBIT Mini lens 18° 8202441-30 ORBIT Mini lens 30° 8202441-42 ORBIT Mini lens 42° 8202441-55 ORBIT Mini lens 55° MINI LENS INSERTS 8202441-G ORBIT Mini lens insert Gold 8202441-W ORBIT Mini lens insert White 8202441-B ORBIT Mini lens insert Black 8202441-C ORBIT Mini lens insert Specular
MINI LENS The MINI LENS is a spherical accessory with a mini recessed anti-glare reflector. 067
ORBIT FLOOD LENS The FLOOD LENS is a spherical accessory providing ambient lighting and flood lighting with a milky white diffuser optic (150°). ORBIT BASE TR0143B ORBIT Trackspot 6W/9W 2700K Dimmable, black TR0144B ORBIT Track pendant 6W/9W 2700K Dimmable, black 8203430 ORBIT Pendant 6W/9W 2700K Dimmable, black 8203431 ORBIT Wall light 6W/9W 2700K Dimmable, black FLOOD LENS OPTIC 8202442 ORBIT Flood lens 150° White
FLOOD LENS The FLOOD LENS is a spherical accessory providing ambient lighting and flood lighting with a milky white diffuser optic. 069
ORBIT DECORATIVE LENS The DECORATIVE LENS is a spherical accessory featuring a flat cilinder optic with anti-glare, and a decorative reflector. Optics available in 15°, 24°, 36° and 60° ORBIT BASE TR0143B ORBIT Trackspot 6W/9W 2700K Dimmable, black TR0144B ORBIT Track pendant 6W/9W 2700K Dimmable, black 8203430 ORBIT Pendant 6W/9W 2700K Dimmable, black 8203431 ORBIT Wall light 6W/9W 2700K Dimmable, black DECORATIVE LENS OPTICS 8202443-15 ORBIT Decorative lens 15° 8202443-24 ORBIT Decorative lens 24° 8202443-36 ORBIT Decorative lens 36° 8202443-60 ORBIT Decorative lens 60° DECORATIVE LENS INSERTS 8202443-G ORBIT Decorative lens insert Gold 8202443-W ORBIT Decorative lens insert White 8202443-B ORBIT Decorative lens insert Black 8202443-C ORBIT Decorative lens insert Specular
DECORATIVE LENS The DECORATIVE LENS is a spherical accessory featuring a flat cilinder optic with anti-glare, and a decorative reflector. 071
Interchangeable modules and optics are easy to install using the F-Connect system. 1. Connect the safety cable 2. Rotate the module, wait for the click to secure it in place. The spot has a maximum 45° tilt 1. 2.
The precise tilt angle can be confirmed through the clock-ticking sound. 073
ORBIT TR0144B ORBIT Track pendant 6W/9W 2700K Dimmable, black 8203430 ORBIT Pendant 6W/9W 2700K Dimmable, black 8203431 ORBIT Wall light 6W/9W 2700K Dimmable, black TR0143B ORBIT Trackspot 6W/9W 2700K Dimmable, black 103mm 103mm 103mm 103mm Ø86,5mm Ø60mm Ø100mm Ø100mm Ø100mm Ø100mm 122,7mm 137,3mm 147,5mm 138,5mm 82,5mm 97,1mm 107,3mm 98mm 41mm Ø101mm 103mm 103mm 103mm 103mm Ø100mm Ø100mm Ø100mm Ø100mm 41mm Ø86,5mm Ø60mm Ø101mm 1618mm 1632mm 1624mm 1633mm 107,3mm 98mm Ø100mm Ø100mm Ø100mm Ø100mm Ø100mm Ø100mm Ø100mm Ø100mm Ø86,5mm Ø60mm Ø101mm Ø86,5mm Ø60mm Ø101mm Ø60mm Ø60mm Ø60mm Ø60mm 90,5mm 90,5mm 90,5mm 90,5mm 41mm 1636mm 1650mm 1660mm 1651mm 123mm 123mm 123mm 123mm 97,1mm 82,5mm 107,3mm 98mm 97,1mm 82,5mm 107,3mm 98mm 97,1mm 82,5mm 109,5mm 124,3mm 134,5mm 125,5mm 41mm
LED 9 Watt 2700K * 905 Lumen (120°) CRI > 90 Dimmable 0-100% * Material: aluminium Colour: matte black Inserts available in gold, white, black and chrome Power: 220-240 Volt * The LED chip can be switched between 6 and 9 Watt 100% 0% * Dimmable when used with the correct LED dimmer. 075
PURE - Super slim, light tapered design - Thinnest profile on the market - Less than 6 mm wide at the top - Same thin profile for all pendants and floorlamps - Dimmable * 105mm 5,9mm 9mm * Dimmable when used with the correct LED dimmer. 077
PURE - Design LED lighting - Dimmable - Warm white light - Available in three colours: matte black, matte white and dark copper brown - Different models available: square, round and long straight pendants, floor lamps and wall lights Wall light - up and down light: 3300678 PURE 11 Watt LED 770 Lumen, 3000K, dimmable, matte white 3300679 PURE 11 Watt LED 770 Lumen, 3000K, dimmable, matte black 3300680 PURE 11 Watt LED 770 Lumen, 3000K, dimmable, dark copper brown COB LED 11 Watt 770 Lumen 3000K Dimmable 0-100% * Dimmable driver included Material: aluminium Colour: dark copper brown, matte white, matte black Power: 220-240 Volt 100% 0% 106mm 116mm 106mm
079
PURE - Design LED lighting - Dimmable - Warm white light - Available in three colours: matte black, matte white and dark copper brown - Different models available: square, round and long straight pendants, floor lamps and wall lights Circular pendant Ø60cm: 3300686 PURE 22 Watt LED 1540 Lumen, 3000K, dimmable, dark copper brown 3300696 PURE 22 Watt LED 1540 Lumen, 3000K, dimmable, matte white 3300706 PURE 22 Watt LED 1540 Lumen, 3000K, dimmable, matte black SMD LED 22 Watt 1540 Lumen 3000K Dimmable 0-100% * Dimmable driver included Material: aluminium Colour: dark copper brown, matte white, matte black Power: 220-240 Volt 100% 0% 24mm 550mm 571mm 1200mm 60mm
081
PURE - Design LED lighting - Dimmable - Warm white light - Available in three colours: matte black, matte white and dark copper brown - Different models available: square, round and long straight pendants, floor lamps and wall lights Circular pendant Ø90cm: 3300687 PURE 35 Watt LED 2100 Lumen, 3000K, dimmable, dark copper brown 3300697 PURE 35 Watt LED 2100 Lumen, 3000K, dimmable, matte white 3300707 PURE 35 Watt LED 2100 Lumen, 3000K, dimmable, matte black SMD LED 35 Watt 2100 Lumen 3000K Dimmable 0-100% * Dimmable driver included Material: aluminium Colour: dark copper brown, matte white, matte black Power: 220-240 Volt 100% 0% 910mm 2500mm 60mm 24mm Ø910mm
083
PURE - Design LED lighting - Dimmable - Warm white light - Available in three colours: matte black, matte white and dark copper brown - Different models available: square, round and long straight pendants, floor lamps and wall lights Square pendant 60cm: 3300689 PURE 31 Watt LED 2170 Lumen, 3000K, dimmable, dark copper brown 3300699 PURE 31 Watt LED 2170 Lumen, 3000K, dimmable, matte white 3300709 PURE 31 Watt LED 2170 Lumen, 3000K, dimmable, matte black SMD LED 31 Watt 2170 Lumen 3000K Dimmable 0-100% * Dimmable driver included Material: aluminium Colour: dark copper brown, matte white, matte black Power: 220-240 Volt 100% 0% 24mm 60mm 1200mm 615mm 600mm
085
PURE - Design LED lighting - Dimmable - Warm white light - Available in three colours: matte black, matte white and dark copper brown - Different models available: square, round and long straight pendants, floor lamps and wall lights Square pendant 90cm: 3300690 PURE 42 Watt LED 2520 Lumen, 3000K, dimmable, dark copper brown 3300700 PURE 42 Watt LED 2520 Lumen, 3000K, dimmable, matte white 3300710 PURE 42 Watt LED 2520 Lumen, 3000K, dimmable, matte black SMD LED 42 Watt 2520 Lumen 3000K Dimmable 0-100% * Dimmable driver included Material: aluminium Colour: dark copper brown, matte white, matte black Power: 220-240 Volt 100% 0% 935mm 65mm 2500mm 60mm 904mm 904mm 904mm 35mm
087
PURE - Design LED lighting - Dimmable - Warm white light - Available in three colours: matte black, matte white and dark copper brown - Different models available: square, round and long straight pendants, floor lamps and wall lights Pendant 120cm: 3300683 PURE 26 Watt LED 1820 Lumen, 3000K, dimmable, dark copper brown 3300693 PURE 26 Watt LED 1820 Lumen, 3000K, dimmable, matte white 3300703 PURE 26 Watt LED 1820 Lumen, 3000K, dimmable, matte black SMD LED 26 Watt 1820 Lumen 3000K Dimmable 0-100% * Dimmable driver included Material: aluminium Colour: dark copper brown, matte white, matte black Power: 220-240 Volt 100% 0% 600mm 1200mm 1200mm 60mm 24mm
089
PURE - Design LED lighting - Dimmable - Warm white light - Available in two colours: matte black and matte white - Different models available: square, round and long straight pendants, floor lamps and wall lights Pendant 180cm: 3300694 PURE 37 Watt LED 2590 Lumen, 3000K, dimmable, matte white 3300704 PURE 37 Watt LED 2590 Lumen, 3000K, dimmable, matte black SMD LED 37 Watt 2590 Lumen 3000K Dimmable 0-100% * Dimmable driver included Material: aluminium Colour: matte white, matte black Power: 220-240 Volt 100% 0% 1800mm 900mm 1200mm 60mm 105mm 9mm 28mm
091
PURE - Design LED lighting - Dimmable on request - Warm white light - Available in two colours: matte black and matte white - Different models available: square, round and long straight pendants, floor lamps and wall lights Pendant 250cm: 3300695 PURE 42 Watt LED 2940 Lumen, 3000K, dimmable, matte white 3300705 PURE 42 Watt LED 2940 Lumen, 3000K, dimmable, matte black SMD LED 42 Watt 2940 Lumen 3000K Dimmable 0-100% * Driver included (dimmable driver on request) Material: aluminium Colour: matte white, matte black Power: 220-240 Volt 100% 0% 2500mm 1600mm 2500mm 60mm 105mm 9mm 28mm
093
PURE - Design LED lighting - Warm white light - Available in three colours: matte black, matte white and dark copper brown - Different models available: square, round and long straight pendants, floor lamps and wall lights Floorlamp 150cm: 3300682 PURE 23 Watt LED 1610 Lumen, 3000K, dark copper brown 3300692 PURE 23 Watt LED 1610 Lumen, 3000K, matte white 3300702 PURE 23 Watt LED 1610 Lumen, 3000K, matte black SMD LED 23 Watt 1610 Lumen 3000K Not dimmable Driver included Material: aluminium Colour: dark copper brown, matte white, matte black Power: 220-240 Volt 1517mm Ø250mm
095
PURE - Design LED lighting - Dimmable - Warm white light - Available in two colours: matte black and matte white - Different models available: square, round and long straight pendants, floor lamps and wall lights Floorlamp 180cm: 3300691 PURE 32 Watt LED 2200 Lumen, 3000K, dimmable, matte white 3300701 PURE 32 Watt LED 2200 Lumen, 3000K, dimmable, matte black SMD LED 32 Watt 2200 Lumen 3000K Dimmable 0-100% Dimmer included Material: aluminium Colour: matte white, matte black Power: 220-240 Volt 100% 0% 105mm 1800mm 280mm
097
TALU - Modern wall light with powerful uplighter for indoor use - Ultra slim design, only 21mm thick - Includes a 20 Watt integrated AC LED chip Available versions: 8202521 TALU 20 Watt LED Uplighter white 8202522 TALU 20 Watt LED Uplighter black 200mm 21mm 80mm 21mm
AC LED 20 Watt 1600 Lumen 2700K Warm White Dimmable 0-100% * Material: aluminium Colour: matte white, matte black Power: 220-240 Volt 100% 0% * Dimmable when used with the correct LED dimmer. 099
XANDAR - High-end modern monophase trackspot - Professional quality COB LED included: CRI>90 - Change the lens, filter and insert. Available versions: TR0142B XANDAR 10 Watt LED Trackspot matte black TR0142W XANDAR 10 Watt LED Trackspot matte white
101
XANDAR COB LED 10 Watt 2700K CRI>90 36°, 710 Lumen Dimmable bulb 0-100% * Dimmable driver included Material: aluminium Colour: matte white matte black Power: 220-240 Volt Reflectors: 8202420: 15° 8202421: 60° Inserts: 8202422: Gold 8202423: Honeycomb filter (anti-glare) 100% 0% 82,9mm Ø50mm 125mm 155,6mm 176,9mm * Dimmable when used with the correct LED dimmer. 103
XOLO - Modern LED pendant - Available in matte white or matte black - Available in 40cm and 50cm Matte black version: 3432170 XOLO Pendant 40cm 7 Watt LED 3432175 XOLO Pendant 50cm 12 Watt LED Matte white version: 3432171 XOLO Pendant 40cm 7 Watt LED 3432176 XOLO Pendant 50cm 12 Watt LED
105
XOLO LED 7 Watt 580 Lumen LED 12 Watt 990 Lumen 2700K Warm White Dimmable 0-100% * Dimmable driver included Material: aluminium Colour: matte white matte black Power: 220-240 Volt 100% 0% 400mm 500mm 297mm 371mm 3000mm 3000mm * Dimmable when used with the correct LED dimmer. 107
ZOLAN - Unique tubular design spots - Customizeable with different coloured Zoom inserts (black, white, dark copper brown, aluminium, gold) - 3 different sizes - Complete with dimmable replaceable LED spots - Warm white light - Available premade in matte black with gold insert and matte white with matte white insert Matte white + matte white insert version: 4014150 ZOLAN 1 light, GU10 5 Watt LED included, height 110 mm 4014151 ZOLAN 1 light, GU10 5 Watt LED included, height 180 mm 4014152 ZOLAN 1 light, GU10 5 Watt LED included, height 250 mm
109
ZOLAN - Unique tubular design spots - Customizeable with different coloured Zoom inserts (black, white, dark copper brown, aluminium, gold) - 3 different sizes - Complete with dimmable replaceable LED spots - Warm white light - Available premade in matte black with gold insert and matte white with matte white insert Matte black + gold insert version: 4014155 ZOLAN 1 light, GU10 5 Watt LED included, height 110 mm 4014156 ZOLAN 1 light, GU10 5 Watt LED included, height 180 mm 4014157 ZOLAN 1 light, GU10 5 Watt LED included, height 250 mm
111
ZOLAN - Transform the Zolan spot into a pendant using the Zolan pendant kit. - Extra long cable (3000mm) included - Cable strain relief included - Ready for use with monophase tracks and the INFINITUS profile, using a track adapter (TR0123) - Zolan spot not included! Pendant kit: 4014105 - Pendant kit, cable length max 3000mm, matte black canopy + black cable 4014106 - Pendant kit, cable length max 3000mm, matte white canopy + black cable 3000mm Installation guide:
113
ZOLAN 250mm Ø74,5mm GU10 LED (8202652) 5 Watt 400 Lumen 2700K Dimmable bulb 0-100% * Material: aluminium Colour: matte white + matte white insert matte black + gold insert Power: 220-240 Volt Compatible with Zoom inserts 100% 0% 180mm 110mm Ø74,5mm Ø74,5mm * Bulbs dimmable when used with the correct LED dimmer. Zolan / Zoom Inserts Zolan 115
ZOOM - Customizable colour schemes: choose your own colour combinations for the base and inserts - Bases available in matte black, matte white, aluminium and dark copper brown - Inserts available in matte black, matte white, aluminium, dark copper brown and gold - Square bases for 1, 2, 3, 4 lights - Round base for 1 light Aluminium: 4014070 ZOOM 1 light base square 4014090 Insert I, 30° rotation 4014074 ZOOM 1 light base round 4014095 Insert II, 30° rotation with bevel 4014071 ZOOM 2 light base square 4014100 Insert III, no rotation, full bevel 4014072 ZOOM 3 light base square 4014073 ZOOM 4 light base square
Create your own style! Choose the size of the base: 1,2,3 or 4 light Choose an insert: 3 distinct types and multiple colours available Pick and match different types and colours to create unique pieces. insert II insert III insert I 117
ZOOM - Customizable colour schemes: choose your own colour combinations for the base and inserts - Bases available in matte black, matte white, aluminium and dark copper brown - Inserts available in matte black, matte white, aluminium, dark copper brown and gold - Square bases for 1, 2, 3, 4 lights - Round base for 1 light Matte white: 4014075 ZOOM 1 light base square 4014091 Insert I, 30° rotation 4014079 ZOOM 1 light base round 4014096 Insert II, 30° rotation with bevel 4014076 ZOOM 2 light base square 4014101 Insert III, no rotation, full bevel 4014077 ZOOM 3 light base square 4014078 ZOOM 4 light base square
Create your own style! Choose the size of the base: 1,2,3 or 4 light Choose an insert: 3 distinct types and multiple colours available Pick and match different types and colours to create unique pieces. insert II insert III insert I 119
ZOOM - Customizable colour schemes: choose your own colour combinations for the base and inserts - Bases available in matte black, matte white, aluminium and dark copper brown - Inserts available in matte black, matte white, aluminium, dark copper brown and gold - Square bases for 1, 2, 3, 4 lights - Round base for 1 light Matte black: 4014080 ZOOM 1 light base square 4014092 Insert I, 30° rotation 4014084 ZOOM 1 light base round 4014097 Insert II, 30° rotation with bevel 4014081 ZOOM 2 light base square 4014102 Insert III, no rotation, full bevel 4014082 ZOOM 3 light base square 4014083 ZOOM 4 light base square
Create your own style! Choose the size of the base: 1,2,3 or 4 light Choose an insert: 3 distinct types and multiple colours available Pick and match different types and colours to create unique pieces. insert II insert III insert I 121
ZOOM - Customizable colour schemes: choose your own colour combinations for the base and inserts - Bases available in matte black, matte white, aluminium and dark copper brown - Inserts available in matte black, matte white, aluminium, dark copper brown and gold - Square bases for 1, 2, 3, 4 lights - Round base for 1 light Dark copper brown: 4014085 ZOOM 1 light base square 4014093 Insert I, 30° rotation 4014089 ZOOM 1 light base round 4014098 Insert II, 30° rotation with bevel 4014086 ZOOM 2 light base square 4014103 Insert III, no rotation, full bevel 4014087 ZOOM 3 light base square 4014088 ZOOM 4 light base square
Create your own style! Choose the size of the base: 1,2,3 or 4 light Choose an insert: 3 distinct types and multiple colours available Pick and match different types and colours to create unique pieces. insert II insert III insert I 123
Extra insert options: Gold insert: 4014099 Insert II, 30° rotation with bevel 4014104 Insert III, no rotation, full bevel insert II insert I
Extra insert options: Sonar insert: 4014111 SONAR matte white, GU10 not included 4014112 SONAR matte black, GU10 not included Extra insert options: Lopal insert: 4014113 LOPAL insert, 4,5 Watt AC COB LED, matte white 4014114 LOPAL insert, 4,5 Watt AC COB LED, matte black 125
95,5mm 190mm 190mm 285mm 80mm x 265mm 175mm x 175mm
ZOOM Bulbs not included Recommended bulb: Hybriz Gen 2 LED modules Optional bulb (GU10): 8202652 8202650 Material: aluminium Colour options: Base: matte white matte black aluminium dark copper brown Inserts: matte white matte black aluminium dark copper brown gold Power: 220-240 Volt Torsion springs and spring blades included for 1 light bases. Ø93,7mm 95,5mm 95,5mm 95,5mm 190mm Ø80mm Ø80mm 80mm x 175mm Zoom Base Zoom Inserts 127
ZOOM AR111 - Complete with dimmable driver and powerful replaceable AR111 LED spots - Warm white light, powerful lumen output - Available in matte white and matte black - 1 and 2 light versions Matte white version: 4014120 ZOOM AR111 1 light, 1x AR111 LED 12,4 Watt included 4014125 ZOOM AR111 2 light, 2x AR111 LED 12,4 Watt included Matte black version: 4014121 ZOOM AR111 1 light, 1x AR111 LED 12,4 Watt included 4014126 ZOOM AR111 2 light, 2x AR111 LED 12,4 Watt included
129
ZOOM AR111 AR111 LED 12,4 Watt 30° 2700K (8202705) 650 Lumen with lens cover 1386 Lumen without lens cover AR111 LED bulb overview: page 140 Dimmable bulb 0-100% * Dimmable driver included (3419052) Material: aluminium Colour: matte white matte black Power: 220-240 Volt 100% 0% 59mm 180mm 180mm 59mm 350mm 180mm Ø155mm 320mm x 155mm * Bulbs dimmable when used with the correct LED dimmer. 131
HYBRIZ GEN2 Introduction Instead of just being a simple request for energy efficiency, lighting nowadays is faced with more and more demands. It is very difficult, for traditional integrated lighting products, to offer every solution in different categories, from optical operation, light texture, light tone to appearance. Hybriz generation 2 LED modules are intended to bring a new all-round product to the market. These new modules have high quality internal components with a high CRI (>90), LEDs from Bridgelux, a long warranty of 5 years AND a flicker-free triac dimming system. LED modules are sold without drivers or lenses. Available drivers: triac dimmable, dali dimmable, 0-10V dimmable. Recommended for use with Zoom and most other recessed spotlights for GU10. Low profile In addition to the standard 6W LED module, the 10W LED module with its low profile is perfect for rooms with limited ceiling installation depth. The LED module + Low Profile Lens has a maximum height of 35mm. 6 Watt module: 500-580 Lumen (2700K, 3000K, 4000K) 10 Watt module: 770-850 Lumen (2700K, 3000K, 4000K) The Low Profile Lens (LPL) is available in 15 °, 24 °, 36 ° and 60 ° * 6 Watt LED module available / other modules (9, 13, 18, 10 Watt) available on demand, contact us for more details. 35mm 6 Watt 9 Watt* 13 Watt* 18 Watt* 10 Watt*
F-Connect Connect LED modules and lenses in a quick and easy way. All lenses are quickly replaced with the patented F-connect technology. Thus, the modules can easily meet the needs of different types of customers, and serve specific application areas. Heatsink The addition of a heat sink on the LED module offers the module maximum space to optimally release heat. The heat can be quickly dissipated via non-parallel heat fins and great air convection. The temperature of the LED module averages 60°C and has a maximum temperature of 70°C. The temperature will be lowered again if a lens is installed. The lenses are all made of aluminum, the same material as the heatsink. turn to lock in place 133
Ø49.8mm Lenses High efficiency lens* High efficiency reflector* Low profile lens Low glare lens* Architectural design lens All lenses are made of aluminum and have a diameter of 50mm, ready for use in most recessed spotlights suitable for GU10. HYBRIZ GEN2
High Efficiency Lens Series (HEL)* Classic reflector-like design provides high lighting transmittance. 15° 24° 36° 60° High Efficiency Reflector Series (HER)* Similar to a traditional halogen lamp finish. The reflector surface is vacuum plated aluminum which creates a strong metal texture. 15° 25° 38° 60° Low Profile Lens Series (LPL) Designed with Fresnel & Calculus optical processing technology. The lens is very thin with good light control and is perfect for use in ultra slim luminaries. 15° 24° 36° 60° Low Glare Lens Series (LGL)* Designed with focus on comfort and suitable for professional anti-glare lamps. 18° 28° 38° 50° Architectural Design Lens Series (ADL) ADL uses crossing light distribution technology which can greatly reduce the glare index. The anti-glare ring is available in 4 colours to meet the needs of different architectural styles. Available with white, black, gold and silver finish. 36° * Low profile and architectural lens available / other lenses available on demand, contact us for more details. 135
8300000 Low Profile LED Module 6 Watt 40° 2700K 500 Lumen CRI >90 Dimmable bulb 0-100% Dimmable driver sold separately Lenses sold separately 8300001 Low Profile LED Module 6 Watt 40° 3000K 540 Lumen CRI >90 Dimmable bulb 0-100% Dimmable driver sold separately Lenses sold separately 8300002 Low Profile LED Module 6 Watt 40° 4000K 580 Lumen CRI >90 Dimmable bulb 0-100% Dimmable driver sold separately Lenses sold separately 8300003 LED Module 9 Watt 40° 2700K 770 Lumen CRI >90 Dimmable bulb 0-100% Dimmable driver sold separately Lenses sold separately Available on demand, contact us for more details 8300004 LED Module 9 Watt 40° 3000K 830 Lumen CRI >90 Dimmable bulb 0-100% Dimmable driver sold separately Lenses sold separately Available on demand, contact us for more details 8300005 LED Module 9 Watt 40° 4000K 850 Lumen CRI >90 Dimmable bulb 0-100% Dimmable driver sold separately Lenses sold separately Available on demand, contact us for more details HYBRIZ GEN2 LED module overview 5 years warranty on all LED modules.
8300006 Low Profile LED Module 10 Watt 40° 2700K 770 Lumen CRI >90 Dimmable bulb 0-100% Dimmable driver sold separately Lenses sold separately Available on demand, contact us for more details 8300007 Low Profile LED Module 10 Watt 40° 3000K 830 Lumen CRI >90 Dimmable bulb 0-100% Dimmable driver sold separately Lenses sold separately Available on demand, contact us for more details 8300008 Low Profile LED Module 10 Watt 40° 4000K 850 Lumen CRI >90 Dimmable bulb 0-100% Dimmable driver sold separately Lenses sold separately Available on demand, contact us for more details 8300009 LED Module 13 Watt 40° 2700K 1020 Lumen CRI >90 Dimmable bulb 0-100% Dimmable driver sold separately Lenses sold separately Available on demand, contact us for more details 8300010 LED Module 13 Watt 40° 3000K 1170 Lumen CRI >90 Dimmable bulb 0-100% Dimmable driver sold separately Lenses sold separately Available on demand, contact us for more details 8300011 LED Module 13 Watt 40° 4000K 1300 Lumen CRI >90 Dimmable bulb 0-100% Dimmable driver sold separately Lenses sold separately Available on demand, contact us for more details HYBRIZ GEN2 LED module overview 5 years warranty on all LED modules. 137
8300012 LED Module 18 Watt 2700K 1450 Lumen CRI >90 Dimmable bulb 0-100% Dimmable driver sold separately Lenses sold separately Available on demand, contact us for more details HYBRIZ GEN2 LED module overview 8300013 LED Module 18 Watt 3000K 1570 Lumen CRI >90 Dimmable bulb 0-100% Dimmable driver sold separately Lenses sold separately Available on demand, contact us for more details 8300014 LED Module 18 Watt 4000K 1700 Lumen CRI >90 Dimmable bulb 0-100% Dimmable driver sold separately Lenses sold separately Available on demand, contact us for more details The following LED modules are also available on demand for projects: Dim To Warm LED Module Dim your lights to change the light colour from 3000K to 1800K, CRI >95 Available in 6 Watt and 13 Watt Sunlike LED Module Light with a high CRI (97+), comparable to natural sunlight Available in 6 Watt and 13 Watt, 2700K, 3000K, 4000K Tuneable White LED Module Freely change the light colour from 2700K to 6500K, CRI >90 Available in 6 Watt and 13 Watt 5 years warranty on all LED modules.
DRIVERS TRIAC Dimmable 8300200 6 Watt DC34V / 130mA 8300201 9 Watt DC36V / 210mA * 8300202 10 Watt DC36V / 210mA * 8300203 13 Watt DC34V / 300mA * 8300204 18 Watt DC34V / 420mA * 8300205 6 Watt For Dim To Warm DC17V / 270mA * 3419055 Dali 2.0 Dimmable 3419056 0-10V Dimmable LENSES High Efficiency Lens (HEL) * 8300100: 15° 8300101: 24° 8300102: 36° 8300103: 60° h: 26,5mm High Efficiency Reflector (HER) * 8300104: 15° 8300105: 25° 8300106: 38° 8300107: 60° h: 26,5mm Low Profile Lens (LPL) 8300108: 15° 8300109: 24° 8300110: 36° 8300111: 60° h: 15,5mm Low Glare Lens (LGL) * 8300112: 18° 8300113: 28° 8300114: 38° 8300115: 50° h: 30mm Architectural Design Lens (ADL) 8300116: white 8300117: black 8300118: gold 8300119: silver h: 40,5mm HYBRIZ GEN2 Accessories overview * Drivers 8300200, 3419055, 3419056 available / other drivers available on demand, contact us for more details. * Low profile and architectural lens available / other lenses available on demand, contact us for more details. 3 years warranty on all drivers. 139
BULBS 8202705 AR111 LED 12,4 Watt 30° 2700K CRI>80 650 Lumen with lens cover 1386 Lumen without lens cover Dimmable bulb 0-100% * Requires dimmable driver 3419052 Ø104mm - L54mm 8202650 GU10 LED 4,5 Watt 36° 2700K 246 Lumen (90°) CRI >90 Dimmable bulb 0-100% * Ø50mm - L60mm 8202652 GU10 LED 5 Watt 30° 2700K 400 Lumen CRI >80 Dimmable bulb 0-100% * Ø50mm - L55mm Recommended for: Nysit Zoom Recommended for: Zoom Zolan Recommended for: Aeon Box Zoom AR111 Also available: 8202704: 15° 2700K CRI>80 8202706: 15° 3000K CRI>80 8202707: 30° 3000K CRI>80 8202708: 15° 4000K CRI>80 8202709: 30° 4000K CRI>80 * Bulbs dimmable when used with the correct LED dimmer.
DISCLAIMER Fantasia Verlichting® n.v. has realized this catalogue for any person involved in the lighting business. Our hope is that it will be an efficient tool that can contribute to the creativity of the lighting designers. All designs are protected by deposit of the models and © COPYRIGHT. All products in this catalogue are made according to CE regulations. © COPYRIGHT Fantasia Verlichting® n.v. No part of this catalogue may be copied or reproduced without written approval of Fantasia Verlichting® n.v. Information in this catalogue is without engagement and may be subject to changes without notice. Premium Collection edition 2023 Fantasia Verlichting® n.v. stelde deze catalogus samen voor iedereen die in contact komt met de verlichtingswereld. Het is onze hoop dat dit een efficiënte “tool” en inspiratiebron wordt. Alle designs zijn beschermd door het © COPYRIGHT en deposito bij een merkenburo. Alle producten in deze catalogueus zijn vervaardigd volgens de algemeen geldende europese normen. © COPYRIGHT Fantasia Verlichting® n.v. Niets uit deze catalogus mag gekopieerd of verveelvoudigd worden zonder de uitdrukkelijke schriftelijke toestemming van Fantasia Verlichting® n.v. Informatie in deze catalogueus is op geen enkele manier bindend en kan gewijzigd worden zonder voorafgaande kennisgeving. Premium Collection editie 2023 Fantasia Verlichting® n.v. a créé ce catalogue pour toutes les personnes qui s’intéressent à l’éclairage. Nous espérons que cet outil contribuera à créer un atmosphère plus efficace et plus créatif. Tous les modèles de sont protégés par un © COPYRIGHT et ont été déposés auprès d’un bureau de marques. Tous les produits repris dans ce catalogue ont été fabriqués conformément aux normes CE. © COPYRIGHT Fantasia Verlichting® n.v. Le contenu de ce catalogue ne peut être copié et/ou multiplié et/ou publié sous aucune forme et sur aucun support, sans l’autorisation spécifique écrite de Fantasia Verlichting® n.v. Les renseignements repris dans ce catalogue sont données à titre informatif et peuvent être modifiés sans avertissement préalable. Premium Collection édition 2023 141
COMING SOON NOMA Ready for E27 bulbs Available in matte black with gold and matte white with gold
AKO With dimmable led and dimmer included Available in matte black with gold and matte white with gold Scan to discover more new items. Updated regularly! 143
Telephone: +32 59 70 40 70 Fax: +32 59 70 77 33 E-mail: info@fantasia.be Website: www.fantasia.be VAT: BE0407 820 266 Showroom Fantasia Verlichting® n.v. Torhoutsesteenweg 437 B-8400 Oostende Belgium Warehouse & Offices Fantasia Verlichting® n.v. Archimedesstraat 58 B-8400 Oostende Belgium Registered Office Fantasia Verlichting® n.v. Torhoutsesteenweg 437 B-8400 Oostende Belgium
® Fantasia Verlichting NV - Torhoutsesteenweg 437 - 8400 Oostende - Belgium www.fantasia.be - info@fantasia.be Tel: +3259 704070 - Fax: +3259 707733
