Lighting System Magnetic OKT 24
LOW VOLTAGE 48V TRACKLIGHTING 2 LOW V Magnet Laagspa Laagspanning geschikt zijn o De armaturen magnetische De laagspann lichten kan aa Dimmingstec als Tunable W de afstandsbe TUNABLE W Alle verlichtin van 3 jaar pro De gebruikte een hoge CRI INTERLUXX Light on Track
LOW VOLTAGE 48V TRACKLIGHTING 3 48V MAGNETIC VOLTAGE LIGHTING SYSTEM tic Tracks & Spots 48VDC anning 48V magnetische tracks/rails & LEDspots gsproducten zijn zeer klein van formaat en hebben een minimalistische design, waardoor ze uitermate om in moderne residentiële woningen en appartementen toe te passen. n kunnen eenvoudig worden verplaatst: eenvoudig verschuiven in de magnetische rail. Bovendien maken deze armaturen gebruik van blokkerende clips voor een maximale veiligheid en gebruiksgemak. ningsrails kunnen eenvoudig worden gebruikt voor slimme verlichting waarmee je het hele systeem van alle ansturen. chnieken zoals RF en DALI zijn beschikbaar. De spots zijn verkrijgbaar met een vaste lichtkleur 3000k, alsook White (TW) waarbij men zowel perfect kan dimmen maar tevens ook de lichtkleur met ediening kan aanpassen naar elke witkleur tussen koudwit en warmwit. Standaard bieden wij deze laatste optie WHITE aan. ngsarmaturen zijn perfect afgewerkt en de onderdelen zoals driver en led genieten bovendien oductgarantie. e LED chips hebben een zeer lange levensduur van 50000 uren en meer. Ze worden gekenmerket door I>90 voor een perfecte kleurweergave.
4 LOW VOLTAGE 48V TRACKLIGHTING Sterk in & Con Superieure Lichtkwaliteit Magnetisch kliksysteem
5 LOW VOLTAGE 48V TRACKLIGHTING n Design ncept Dimming RF & DALI Veelzijdige montagemogelijkheden
Magnetisch tracksysteem 48V • Veilig: alle armaturen klikken eenvoudig in de 48V-tracks. Ze hebben een magnetische basis waardoor ze duurzaam en veilig in de tracks vastgeklikt blijven. • Flexibiliteit: men kan LEDspots en armaturen verschuiven, verplaatsen, bijplaatsen of richten naar keuze. • Uitbreidbaar met eenvoudig ‘inklikken’ in de magnetische rail, elke voet heeft bovendien een handige klik-beveiliging. «easy click-in» «easy click-in» magnetisch magnetisch
7 LOW VOLTAGE 48V TRACKLIGHTING 20 WATT 1800 Lumen
LOW VOLTAGE 48V TRACKLIGHTING 8 TL01 SERIES HIGH CRI 48V MAGNETIC LIGHTING SYSTEM Mini Spot Ø30mm TL01 D30A Target Spot Ø40mm TL01 D40A Spot Ø40mm TL01 D40B TL01 SERIES MINI RF LM10.1.013 3000k RF TW LM10.1.015 TW 4 WATT 360 Lumen 6 WATT 520 Lumen 10 WATT 780 Lumen TARGET S RF LM10.1.023 3000k RF TW LM10.1.025 TW FOCUS-I S RF LM10.3.033 3000k RF TW LM10.3.035 TW Art. nummer extensie BL = BLACK WH = WHITE Standaard (voorraad) 3000k 12W WH TW 12W WH (WH/GL/BR) TW 20W WH
LOW VOLTAGE 48V TRACKLIGHTING 9 48V MAGNETIC Spot Ø50mm TL01 D50B Spot Ø90mm TL01 D90A 12 WATT 1000 Lumen 20 WATT 1800 Lumen FOCUS-II S RF LM10.1.041 2700k RF LM10.1.042 3000k RF LM10.1.043 4000k RF TW LM10.1.044 TW POWER L RF LM10.1.092 3000k RF LM10.1.093 4000k RF TW LM10.1.094 TW S = korte hals T1, T4 Binnenring (inner colour) 3000k 12W WHITE 3000k 12W GOLD 3000k 12W BRASS
LOW VOLTAGE 48V TRACKLIGHTING 10 TL01 SERIE LOW VOLTAGE MAGNETIC LIGHTING SYSTEM 48V - 4 WATT REFLECTOR TL01 4W MINI TL01 4W MINI 4W
LOW VOLTAGE 48V TRACKLIGHTING 11 48V MAGNETIC LICHTHOEK 36° CRI >90 LIGHT WARM WHITE HIGH CRI>90 3000k Tunable White 2700k - 5700k - standaard TLO1 MINI SPOT HIGH CRI 4W Afmetingen Ø30 x H50mm 4 WATT WHITE Type/Model S LM10.1.013 TL01 Target 30A RFB S 4 Watt 36° 3000k 360 Lumen WHITE RF Dimbaar LM10.1.015 TL01 Target 30A RFC S 4 Watt TW 36° 300 Lumen WHITE RF Tunable White BLACK Type/Model S LM10.3.013 TL01 Target 30A RFB S 4 Watt 36° 3000k 360 Lumen WHITE RF Dimbaar LM10.3.015 TL01 Target 30A RFC S 4 Watt TW 36° 300 Lumen WHITE RF Tunable White
LOW VOLTAGE 48V TRACKLIGHTING 12 TL01 SERIE LOW VOLTAGE MAGNETIC LIGHTING SYSTEM 48V - 6 WATT REFLECTOR TL01 6W TARGET 6W
LOW VOLTAGE 48V TRACKLIGHTING 13 48V MAGNETIC WHITE Type/Model S Dimming Lichthoek LM10.1.023 TL01 Target 40A RFB S 6 Watt 3000k 520 Lumen WHITE RF Dimbaar 36° LM10.1.025 TL01 Target 40A RFC S 6 Watt TW 480 Lumen WHITE RF Tunable White 36° BLACK Type/Model S LM10.3.023 TL01 Target 40A RFB S 6 Watt 3000k 520 Lumen BLACK RF Dimbaar 36° LM10.3.025 TL01 Target 40A RFC S 6 Watt TW 480 Lumen BLACK RF Tunable White 36° LIGHT WARM WHITE HIGH CRI>90 3000k Tunable White 2700k - 5700k TLO1 ‘TARGET’ SPOT HIGH CRI 6W S = korte hals Afmetingen Ø40 x H70mm LICHTHOEK 36° CRI >90 6 WATT
LOW VOLTAGE 48V TRACKLIGHTING 14 TL01 SERIE LOW VOLTAGE MAGNETIC LIGHTING SYSTEM 48V - 10 WATT REFLECTOR TL01 10W FOCUS-I 10W
LOW VOLTAGE 48V TRACKLIGHTING 15 48V MAGNETIC LIGHT WARM WHITE HIGH CRI>90 2700k / 3000k Tunable White 2700k - 5700k TLO1 FOCUS-1 SPOT HIGH CRI 10W S = korte hals Afmetingen Ø40 x H105mm WHITE Type/Model S Dimming LM10.1.033 TL01 FOCUS-I 40A RFB S 10 Watt 3000k 36° 780 Lumen WHITE RF Dimbaar LM10.1.035 TL01 FOCUS-I 40A RFC S 10 Watt TW 36° 700 Lumen WHITE RF Tunable White BLACK Type/Model S LM10.3.033 TL01 FOCUS-I 40A RFB S 10 Watt 3000k 36° 780 Lumen BLACK RF Dimbaar LM10.3.035 TL01 FOCUS-I 40A RFC S 10 Watt TW 36° 700 Lumen BLACK RF Tunable White LICHTHOEK 36° CRI >90 10 WATT FOCUS-I S RF HW483033 3000k RF TW HW483035 TW
LOW VOLTAGE 48V TRACKLIGHTING 16 TL01 SERIE LOW VOLTAGE MAGNETIC LIGHTING SYSTEM 48V - 12 WATT REFLECTOR TL01 12W FOCUS-II 12W
LOW VOLTAGE 48V TRACKLIGHTING 17 48V MAGNETIC LIGHT WARM WHITE HIGH CRI>90 2700k / 3000k / 4000k - op bestelling Tunable White 2700k - 5700k standaard TLO1 FOCUS-II HIGH CRI 12W S = korte hals Afmetingen Ø50 x H110mm WHITE Type/Model S Dimming LM10.1.041 TL01 FOCUS-II 50B RFB S 12 Watt 2700k 36° 1000 Lumen WHITE RF Dimbaar op bestelling LM10.1.042 TL01 FOCUS-II 50B RFB S 12 Watt 3000k 36° 1000 Lumen WHITE RF Dimbaar op bestelling LM10.1.043 TL01 FOCUS-II 50B RFB S 12 Watt 4000k 36° 1000 Lumen WHITE RF Dimbaar op bestelling LM10.1.044 TL01 FOCUS-II 50B RFC S 12 Watt TW 36° 850 Lumen WHITE RF Tunable White voorraadartikel BLACK Type/Model S LM10.3.041 TL01 FOCUS-II 50B RFB S 12 Watt 2700k 36° 1000 Lumen BLACK RF Dimbaar op bestelling LM10.3.042 TL01 FOCUS-II 50B RFB S 12 Watt 3000k 36° 1000 Lumen BLACK RF Dimbaar op bestelling LM10.3.043 TL01 FOCUS-II 50B RFB S 12 Watt 4000k 36° 1000 Lumen BLACK RF Dimbaar op bestelling LM10.3.044 TL01 FOCUS-II 50B RFC S 12 Watt TW 36° 850 Lumen BLACK RF Tunable White voorraadartikel STANDAARD (VOORRAADPRODUCT) TUNABLE WHITE 2.4Ghz LM10.1.044-WH/WH met WITTE BINNEN-RING - TUNABLE WHITE LM10.1.044-WH/GL met GOUDKLEURIGE BINNEN-RING - TUNABLE WHITE LM10.1.044-WH/BR met BRASS BINNEN-RING - TUNABLE WHITE LM10.3.044-WH/BL met ZWARTE BINNEN-RING - TUNABLE WHITE LICHTHOEK 36° CRI >90 12 WATT
LOW VOLTAGE 48V TRACKLIGHTING 18 TL01 SERIE LOW VOLTAGE MAGNETIC LIGHTING SYSTEM 48V - 20 WATT LENS TL01 20W POWER 20W
LOW VOLTAGE 48V TRACKLIGHTING 19 48V MAGNETIC WARM WHITE HIGH CRI>90 3000k / 4000k Tunable White 2700k - 5700k INTERLUXX «POWER» SPOT HIGH CRI 20W Dimensions Ø90 x H47mm WHITE Type/Model L Dimming LM10.1.092 TL01 POWER-9 90A RFB L 20 Watt 3000k 36° 1800 Lumen WHITE RF Dimbaar LM10.1.093 TL01 POWER-9 90A RFB L 20 Watt 4000k 36° 1800 Lumen WHITE RF Dimbaar LM10.1.094 TL01 POWER-9 90A RFC L 20 Watt TW 36° 1600 Lumen WHITE RF Tunable White BLACK Type/Model L LM10.3.092 TL01 POWER-9 90A RFB L 20 Watt 3000k 36° 1800 Lumen BLACK RF Dimbaar LM10.3.093 TL01 POWER-9 90A RFB L 20 Watt 4000k 36° 1800 Lumen BLACK RF Dimbaar LM10.3.094 TL01 POWER-9 90A RFC L 20 Watt TW 36° 1600 Lumen BLACK RF Tunable White LICHTHOEK 36° CRI >90 20 WATT 1800 LUMEN 1600 Lm TW OP AANVRAAG SUR DEMANDE ON REQUEST
LOW VOLTAGE 48V TRACKLIGHTING 20
LOW VOLTAGE 48V TRACKLIGHTING 21 48V MAGNETIC Tunable White De lichtkleur kan perfect met afstandsbediening of bedieningsknop ingesteld worden van warmwit (2700k) tot koudwit (5700k) Track Lighting Series Track Single Colour Tunable White (CW/WW) 4W Mini 360 Lumen 300 Lumen 6W Target 520 Lumen 420 Lumen 10W Focus-I 780 Lumen 700 Lumen 12W Focus-II 1000 Lumen 850 Lumen 20W Power 1800 Lumen 1600 Lumen Zoomable (Zoom-II & Zoom-III) De lichthoek is instelbaar door de ingebouwde lichthoek-ring in- of uit te draaien. Gallery / Zoomable Series Hyro Single Colour Tunable White (CW/WW) 12W Zoom-II 550 Lumen 440 Lumen 15W Zoom-III 820 Lumen 660 Lumen 12W Monro Fix 1200 Lumen 900 Lumen 20W Washer-Fix 2000 Lumen 1600 Lumen Spot Design - Hyro vs. TL01-Series Bij de TL01-series is de ‘spothals’ in het midden van de spot geplaatst. Bij de HYRO-series is de ‘spothals’ aan de zijkant inklikbaar in de spot en kan de spot nog beter gericht worden.
LOW VOLTAGE 48V TRACKLIGHTING 22 LINEAR LIGHTS 48V MAGNETIC LIGHTING SYSTEM Linear Light Brede Lichthoek LINEAR LL22 Linear Light Low UGR LINEAR LS22 24 LEDs LINEAR-I 20 WATT 20 WATT LINEAR FOLD-I LINEAR-II 800 Lumen 1000 Lumen 90° 30° LICHTHOEK 36° CRI >90 20 WATT
LOW VOLTAGE 48V TRACKLIGHTING 23 48V MAGNETIC Richtbare vouwspot LA22 LINEAR LA22 6 LEDs Richtbare vouwspot LA22 LINEAR LA22 12 LEDs 12 WATT 6 WATT LINEAR FOLD-I LINEAR FOLD-II 500 Lumen 1000 Lumen 32° 32° LICHTHOEK 32° CRI >90 12 WATT 6 WATT 500 LUMEN 1000 LUMEN
LOW VOLTAGE 48V TRACKLIGHTING 24 LL22 LINEAR LIGHT 90D 48V MAGNETIC LIGHTING SYSTEM LINEAR-I
LOW VOLTAGE 48V TRACKLIGHTING 25 48V MAGNETIC WARMWIT LEDLICHT 2700k / 3000k / 4000k LINEAR LIGHT 90° HIGH CRI ONLY DIMMING / NO TUNABLE WHITE INTERLUXX LL22 90° WHITE BLACK Type/Model Linear Flood 20W Dimming LM30.1.004 LM30.3.004 LL22B LV26DAB Linear 90° 20W 2700k 800 Lm 90° 48V RF Dimbaar LM30.1.005 LM30.3.005 LL22B LV26DAB Linear 90° 20W 3000k 800 Lm 90° 48V RF Dimbaar LM30.1.006 LM30.3.006 LL22B LV26DAB Linear 90° 20W 4000k 800 Lm 90° 48V RF Dimbaar WHITE BLACK Type/Model Linear Flood 30W Dimming LM30.1.007 LM30.3.007 LL22B LV26DAB Linear 90° 30W 2700k 1100 Lm 90° 48V RF Dimbaar LM30.1.008 LM30.3.008 LL22B LV26DAB Linear 90° 30W 3000k 1100 Lm 90° 48V RF Dimbaar LM30.1.009 LM30.3.009 LL22B LV26DAB Linear 90° 30W 4000k 1100 Lm 90° 48V RF Dimbaar LICHTHOEK 90° CRI >90 30 WATT 20 WATT 800 LUMEN 1100 LUMEN
LOW VOLTAGE 48V TRACKLIGHTING 26 Linear Spot L 22 48V 10W 20W 30W S LS22 LINEAR LIGHT 90D 48V MAGNETIC LIGHTING SYSTEM LINEAR-II
LOW VOLTAGE 48V TRACKLIGHTING 27 48V MAGNETIC WHITE BLACK Type/Model 20W Dimming LM30.1.014 LM30.3.014 LS22B LV26RFB Linear 30° RF 20 Watt 2700k 1000 Lm 30° 48V RF Dimbaar LM30.1.015 LM30.3.015 LS22B LV26RFB Linear 30° RF 20 Watt 3000k 1000 Lm 30° 48V RF Dimbaar LM30.1.016 LM30.3.016 LS22B LV26RFB Linear 30° RF 20 Watt 4000k 1000 Lm 30° 48V RF Dimbaar WHITE BLACK Type/Model 30W Dimming LM30.1.017 LM30.3.017 LS22C LV26RFB Linear 30° RF 30 Watt 2700k 1400 Lm 30° 48V RF Dimbaar LM30.1.018 LM30.3.018 LS22C LV26RFB Linear 30° RF 30 Watt 3000k 1400 Lm 30° 48V RF Dimbaar LM30.1.019 LM30.3.019 LS22C LV26RFB Linear 30° RF 30 Watt 4000k 1400 Lm 30° 48V RF Dimbaar WARMWIT & NEUTRAALWIT LEDLICHT 2700k / 3000k / 4000k LINEAR LIGHT 30° HIGH CRI LOW UGR NO TUNABLE WHITE INTERLUXX LS22 30° LICHTHOEK 30° CRI >90 30 WATT 20 WATT 1000 LUMEN 1400 LUMEN
LOW VOLTAGE 48V TRACKLIGHTING 28 Adjustable Spot LA22 48V 6W LA22 LINEAR LIGHT COMPACT-1 48V MAGNETIC LIGHTING SYSTEM LINEAR FOLD-I
LOW VOLTAGE 48V TRACKLIGHTING 29 48V MAGNETIC WHITE Type/Model L Watt Lumen Dimming Lichthoek LM30.1.702 LA22A LV26RFB 6 Watt 500 Lm RF Dimbaar 32° WARMWIT LEDLICHT 3000k Standaard Lichthoek 32° LINEAR LIGHT FOLDABLE HIGH CRI LOW UGR INTERLUXX LA22A 32° LICHTHOEK 32° CRI >90 6 WATT 500 LUMEN BLACK Type/Model L Watt Lumen Dimming Lichthoek LM30.3.702 LA22A LV26RFB 6 Watt 500 Lm RF Dimbaar 32°
LOW VOLTAGE 48V TRACKLIGHTING 30 Adjustable Spot LA22 48V 12W LA22 LINEAR LIGHT COMPACT-2 48V MAGNETIC LIGHTING SYSTEM LINEAR FOLD-II
LOW VOLTAGE 48V TRACKLIGHTING 31 48V MAGNETIC Artikel-nr Type/Model 12W Fold Lichthoek LM30.1.712 Linear Foldable LA22B LV26RFB 12W 3000K 1000 Lm RF Dimbaar 48V WHITE 32° LM30.3.712 Linear Foldable LA22B LV26RFB 12W 3000K 1000 Lm RF Dimbaar 48V BLACK 32° WARMWIT LEDLICHT 3000k LINEAR LIGHT COMPACT-2 HIGH CRI LOW UGR INTERLUXX LA22B 32° LICHTHOEK 32° CRI >90 12 WATT 1000 LUMEN
LOW VOLTAGE 48V TRACKLIGHTING 32
LOW VOLTAGE 48V TRACKLIGHTING 33 48V MAGNETIC
LOW VOLTAGE 48V TRACKLIGHTING 34 HANGLAMPEN FINO-I 6 Watt White FINO-I 6 Watt Gold
LOW VOLTAGE 48V TRACKLIGHTING 35 48V MAGNETIC TL01 SERIES HIGH CRI 48V MAGNETIC LIGHTING SYSTEM Hanglamp Ø30mm TL01 D30C Hanglamp Ø40mm TL01 D40C Hanglamp Ø100mm TL01 D100A 6 WATT 520 Lumen 10 WATT 780 Lumen 6 WATT 500 Lumen FINO-I FINO-II BOLO Kleuren: Black White Gold Kleuren: Black White Gold Kleuren: Gold/Brass
LOW VOLTAGE 48V TRACKLIGHTING 36 TL01 HANGLAMP Ø30 HIGH CRI 48V MAGNETIC LIGHTING SYSTEM HANGLAMPEN FINO-I
LOW VOLTAGE 48V TRACKLIGHTING 37 48V MAGNETIC WARMWIT & NEUTRAALWIT LEDLICHT 2700k / 3000k / 4000k Tunable White 2700k-5700k Standaard Lichthoek 36° Behuizingen: BLACK / GOLD - WHITE / GOLD HANGLAMP FINO TRACKLIGHT HIGH CRI INTERLUXX FINO-1 WHITE BLACK GOLD Type/Model Lichthoek LM40.1.211 LM40.3.211 LM40.5.211 FINO-I TL01 30C LV26RFB 6 Watt 2700k 520 Lm RF Dimbaar 48V 15° / 24° / 36° LM40.1.212 LM40.3.212 LM40.5.212 FINO-I TL01 30C LV26RFB 6 Watt 3000k 520 Lm RF Dimbaar 48V 15° / 24° / 36° LM40.1.213 LM40.3.213 LM40.5.213 FINO-I TL01 30C LV26RFB 6 Watt 4000k 520 Lm RF Dimbaar 48V 15° / 24° / 36° LM40.1.214 LM40.3.214 LM40.5.214 FINO-I TL01 30C LV26RFB 6 Watt TW 420 Lm RF Tunable White 48V 15° / 24° / 36° LICHTHOEK 36° CRI >90 6 WATT 520 LUMEN
LOW VOLTAGE 48V TRACKLIGHTING 38 TL01 HANGLAMP Ø40 HIGH CRI 48V MAGNETIC LIGHTING SYSTEM HANGLAMPEN FINO-II
LOW VOLTAGE 48V TRACKLIGHTING 39 48V MAGNETIC WARMWIT & NEUTRAALWIT LEDLICHT 2700k / 3000k / 4000k Tunable White 2700k-5700k Lichthoeken 15° / 36° (standaard) Behuizingen: BLACK / GOLD - WHITE / GOLD HANGLAMP FINO-2 Ø40mm TRACKLIGHT HIGH CRI 90 INTERLUXX FINO-2 WHITE BLACK Type/Model Lichthoek CRI LM40.1.311 LM40.3.311 FINO-II TL01 40C LV26RFB 10 Watt 2700k 780 Lm RF Dimbaar 48V 15° / 36° Ra90 LM40.1.312 LM40.3.312 FINO-II TL01 40C LV26RFB 10 Watt 3000k 780 Lm RF Dimbaar 48V 15° / 36° Ra90 LM40.1.313 LM40.3.313 FINO-II TL01 40C LV26RFB 10 Watt 4000k 780 Lm RF Dimbaar 48V 15° / 36° Ra90 LM40.1.314 LM40.3.314 FINO-II TL01 40C LV26RFB 10 Watt TW 700 Lm RF CCT Dimbaar 48V 15° / 36° Ra90 LICHTHOEK 36° CRI >90 10 WATT 780 LUMEN
LOW VOLTAGE 48V TRACKLIGHTING 40 TL01 HANGLAMP Ø100 BOLO HIGH CRI 48V MAGNETIC LIGHTING SYSTEM HANGLAMP BOLO
LOW VOLTAGE 48V TRACKLIGHTING 41 48V MAGNETIC WARMWIT & NEUTRAALWIT LEDLICHT 2700k / 3000k / 4000k Lichthoek 150* Standaard Finish: BLACK - Optioneel: WHITE HANGLAMP BOLO Ø100mm TRACKLIGHT HIGH CRI INTERLUXX BOLO-100 WHITE BLACK Type/Model LM40.1.525 LM40.3.525 TL01100A LV26RFB 6W 2700k 500Lm 150° RF Dimbaar 48V LM40.1.526 LM40.3.526 TL01100A LV26RFB 6W 3000k 500Lm 150° RF Dimbaar 48V LM40.1.527 LM40.3.527 TL01100A LV26RFB 6W 4000k 500Lm 150° RF Dimbaar 48V LM40.1.528 LM40.3.528 TL01100A LV26RFB 6W 150_ TW RF CCT TW Dimbaar 48V 150° LICHTHOEK 150° CRI >90 6 WATT 500 LUMEN
LOW VOLTAGE 48V TRACKLIGHTING 42 ART GALLERY LIGHTING ART & ANTIQUES
LOW VOLTAGE 48V TRACKLIGHTING 43 Gallery Lighting op bestelling SPECIAL SECTION
LOW VOLTAGE 48V TRACKLIGHTING 44 HYRO GALLERY SERIES A10-A11 48V MAGNETIC LIGHTING SYSTEM Hyro Spot Ø55mm HYRO D55 12 WATT 550 Lumen ZOOM-II Hyro Spot Ø55mm HYRO D55 15 WATT 820 Lumen ZOOM-III
LOW VOLTAGE 48V TRACKLIGHTING 45 Gallery Lighting op bestelling Hyro Spot Ø55mm VARIANTEN Hyro Spot Ø55mm met Honingraat voorzet ANTI VERBLINDING Hyro Spot Ø55mm met schuin voorzetstuk ANTI VERBLINDING & TARGET Hyro Spot Ø55mm met voorzet 4-blad ANTI VERBLINDING & THEATER LOOK Project Lighting OP AANVRAAG SUR DEMANDE ON REQUEST GALLERY LIGHTING ON REQUEST
LOW VOLTAGE 48V TRACKLIGHTING 46 HYRO GALLERY SERIES A10-A11 48V MAGNETIC LIGHTING SYSTEM ZOOMBAAR HYRO A10 VASTE LENS HYRO A11 MINI 4 Watt 160 Lm MINI-ZOOM GALLERY A1045A A1055A A1045A A1055A
LOW VOLTAGE 48V TRACKLIGHTING 47 Gallery Lighting op bestelling Artikel-nr Type/Model L Dimming Lichthoek CRI LM20.1.723 Zoomable A10 35A RFB 4W 160Lm RF Dimbaar 12-43° Zoom Ra90 LM20.1.724 Zoomable A10 35A RFC 4W 130Lm RF Tunable White 12-43° Zoom Ra90 WARMWIT LEDLICHT 2700k / 3000k / 3500k / 4000k Tunable White 2700k - 5700k ZOOMABLE SPOT HIGH CRI 4W MINI-ZOOM HYRO A10 Afmetingen Ø35 x H86mm 48V MAGNETIC Zoom 12-43° MINI-ZOOM GALLERY GARANTIE 5 JAAR HIGH CRI
LOW VOLTAGE 48V TRACKLIGHTING 48 Artikel-nr Type/Model L Watt Lumen Dimming Lichthoek CRI LM20.1.733 Zoomable A10 45A RFB 10 Watt 350 Lm RF Dimbaar 8-40° Zoom Ra90 LM20.1.734 Zoomable A10 45A RFC 10 Watt 280 Lm RF Tunable White 8-40° Zoom Ra90 WARMWIT LEDLICHT 2700k / 3000k / 3500k / 4000k Tunable White 2700k - 5700k ZOOMABLE SPOT HIGH CRI 10W ZOOM-I HYRO A10 Afmetingen Ø45 x H114mm Zoom 8°-40° TARGET-ZOOM GALLERY TARGET-ZOOM GALLERY GARANTIE 5 JAAR HIGH CRI 48V MAGNETIC
LOW VOLTAGE 48V TRACKLIGHTING 49 Gallery Lighting op bestelling Artikel-nr Type/Model L Watt Lumen Dimming Lichthoek CRI LM20.1.743 Zoomable A10 55A RFB 12 Watt 550 Lm RF Dimbaar 8-50° Zoom Ra90 LM20.1.744 Zoomable A10 55A RFC 12 Watt 440 Lm RF Tunable White 8-50° Zoom Ra90 WARMWIT LEDLICHT 2700k / 3000k / 3500k / 4000k Tunable White 2700k - 5700k ZOOMABLE SPOT HIGH CRI 12W ZOOM-II HYRO A10 Afmetingen Ø55 x H142mm Zoom 8°-50° TARGET-ZOOM GALLERY GARANTIE 5 JAAR HIGH CRI 48V MAGNETIC
LOW VOLTAGE 48V TRACKLIGHTING 50 Artikel-nr Type/Model L Watt Lumen Dimming Lichthoek CRI LM20.1.753 Zoomable A10 55A RFB 15 Watt 820 Lm RF Dimbaar 15-50° Zoom Ra90 LM20.1.754 Zoomable A10 55A RFC 15 Watt 660 Lm RF Tunable White 15-50° Zoom Ra90 WARMWIT LEDLICHT 2700k / 3000k / 3500k / 4000k Tunable White 2700k - 5700k ZOOMABLE SPOT HIGH CRI 15W ZOOM-III HYRO A10 Afmetingen Ø55 x H142mm Zoom 15°-50° TARGET-ZOOM GALLERY GARANTIE 5 JAAR HIGH CRI 48V MAGNETIC
LOW VOLTAGE 48V TRACKLIGHTING 51 Gallery Lighting op bestelling HYRO POWER SERIES A20-A21 48V MAGNETIC LIGHTING SYSTEM Hyro Spot Ø62mm HYRO D62 ZOOM Hyro Spot Ø62mm HYRO D62 ZOOM Hyro Spot Ø62mm HYRO D62 ZOOM
LOW VOLTAGE 48V TRACKLIGHTING 52 Lifetime Quality Lighting
LOW VOLTAGE 48V TRACKLIGHTING 53 Gallery Lighting op bestelling Gallery LED Lighting Solutions op aanvraag - sur demande korte leveringstermijn / délais de livraison réduits
LOW VOLTAGE 48V TRACKLIGHTING 54 Zoom 11-50° HYRO SERIES 12W ZOOMABLE MONRO-ZOOM12 MONRO-ZOOM GALLERY
LOW VOLTAGE 48V TRACKLIGHTING 55 Gallery Lighting op bestelling Artikel-nr Type/Model S Watt Lumen Dimming Lichthoek LM20.1.761-S Monro Zoom A20 62A RFB S 12 Watt 920 Lm RF Dimbaar 11-50° Zoom LM20.1.762-S Monro Zoom A20 62A RFC S 12 Watt 700 Lm RF Tunable White 11-50° Zoom WARMWIT LEDLICHT 2700k / 3000k / 3500k / 4000k Tunable White 2700k - 5700k ZOOMABLE SPOT MONRO HIGH CRI 12W S = korte hals HYRO A20 Afmetingen Ø62 x H120mm L = korte hals Artikel-nr Type/Model L Watt Lumen Dimming Lichthoek LM20.1.761-L Monro Zoom A20 62A RFB L 12 Watt 920 Lm RF Dimbaar 11-50° Zoom LM20.1.762-L Monro Zoom A20 62A RFC L 12 Watt 700 Lm RF Tunable White 11-50° Zoom S = korte hals L = lange hals GARANTIE 5 JAAR HIGH CRI 48V MAGNETIC
LOW VOLTAGE 48V TRACKLIGHTING 56 HYRO SERIES 12W VASTE LENS MONRO-FIX12 MONRO-FIX GALLERY
LOW VOLTAGE 48V TRACKLIGHTING 57 Gallery Lighting op bestelling GARANTIE 5 ANS HIGH CRI Artikel-nr Type/Model S Dimming Lichthoek LM20.1.771-S Monro-Fix A21 62L RFB S 12W 1200Lm RF Dimbaar 15° / 36° / 60° LM20.1.772-S Monro-Fix A21 62L RFC S 12W 900 Lm TW RF Tunable White 15° / 36° / 60° WARMWIT LEDLICHT 2700k / 3000k / 3500k / 4000k Tunable White 2700k - 5700k SPOT MONRO-FIX HIGH CRI 12W MONRO-I S = korte hals HYRO A20 Afmetingen Ø62 x H120mm L = korte hals Artikel-nr Type/Model L Dimming Lichthoek LM20.1.771-L Monro-Fix A21 62L RFB L 12W 1200Lm RF Dimbaar 15° / 36° / 60° LM20.1.772-L Monro-Fix A21 62L RFC L 12W 900Lm TW RF Tunable White 15° / 36° / 60° S = korte hals L = lange hals 15° 24° 36° 60° 48V MAGNETIC
LOW VOLTAGE 48V TRACKLIGHTING 58 HYRO SERIES 20W FIXED LENS WASHER-FIX WASHER-FIX GALLERY
LOW VOLTAGE 48V TRACKLIGHTING 59 Gallery Lighting op bestelling Artikel-nr Type/Model S Dimming Lichthoek CRI LM20.1.781-S Washer-Fix A21 90L RFB S 20W 2000Lm RF Dimbaar 15° / 36° / 60° Ra90 LM20.1.782-S Washer-Fix A21 90L RFC S 20W TW 1600Lm RF Tunable White 15° / 36° / 60° Ra90 WARMWIT LEDLICHT 2700k / 3000k / 3500k / 4000k Tunable White 2700k - 5700k SPOT FIXED LENS HIGH CRI 20W WASHER-FIX HYRO A2190L Afmetingen Ø90 x H83mm S = korte hals L = korte hals Artikel-nr Type/Model L Dimming Lichthoek CRI LM20.1.781-L Washer-Fix A21 90L RFB L 20W 2000Lm RF Dimbaar 15° / 36° / 60° Ra90 LM20.1.782-L Washer-Fix A21 90L RFC L 20W TW 1600Lm RF Tunable White 15° / 36° / 60° Ra90 S = korte hals L = lange hals 15° 24° 36° 60° GARANTIE 5 JAAR HIGH CRI 48V MAGNETIC
LOW VOLTAGE 48V TRACKLIGHTING 60 MAGNETIC TRACKS
LOW VOLTAGE 48V TRACKLIGHTING 61
LOW VOLTAGE 48V TRACKLIGHTING 62 MAGNETIC TRACKS T4 Opbouw Standaard 19.0 mm 16.5 mm 26.4 mm 26.8 mm MAGNETIC TRACK 48V MAGNETIC LIGHTING SYSTEM T1 Opbouw Compact WIT ZWART Compact LM50.1.501 LM50.3.501 Track T1 100cm LM50.1.502 LM50.3.502 Track T1 200cm LM50.1.503 LM50.3.503 Track T1 300cm WIT ZWART Standaard LM50.1.541 LM50.3.541 Track T4 100cm LM50.1.542 LM50.3.542 Track T4 200cm LM50.1.543 LM50.3.543 Track T4 300cm 26,2 16,4 21,9
LOW VOLTAGE 48V TRACKLIGHTING 63 T2 Opbouw Hoog T3 Inbouw Trimless HOGE PROFIELEN 48V MAGNETIC ENKEL VOOR SPOTS MET LANGE HALS EN LINEAIRE VERLICHTINGS-ELEMENTEN WIT ZWART Opbouw Hoog LM50.1.521 LM50.3.521 Track T2 100cm LM50.1.522 LM50.3.522 Track T2 200cm LM50.1.523 LM50.3.523 Track T2 300cm WIT ZWART Inbouw Hoog LM50.1.531 LM50.3.531 Track T3 100cm LM50.1.532 LM50.3.532 Track T3 200cm LM50.1.533 LM50.3.533 Track T3 300cm 23,2 26,2 47,2 16,4 23,2 74 46,9 25
LOW VOLTAGE 48V TRACKLIGHTING 64 MAGNETIC TRACKS VERBINDINGSSTUKKEN 48V MAGNETIC LIGHTING SYSTEM Horizontaal Hoekstuk HT1 OPBOUW MINI Horizontaal Hoekstuk HT2 OPBOUW HOOG Horizontaal Hoekstuk HT3 INBOUW Horizontaal Hoekstuk HT4 OPBOUW STANDAARD Verticaal Hoekstuk VT1 OPBOUW MINI Verticaal Hoekstuk VT2 OPBOUW HOOG Verticaal Hoekstuk VT3 INBOUW Verticaal Hoekstuk VT4 OPBOUW STANDAARD WIT Type/Model T1 LM50.1.511 Powergear Live end connector LEFT White PRO-N131L-W LM50.1.512 Powergear Live end connector RIGHT White PRO-N131R-W LM50.1.514 Powergear T1 Hoek 90° White FL PRO-N135FL-W LM50.1.515 Powergear T1 Hoek 90° White FR PRO-N135FR-W LM50.1.516 Powergear T1 Endcap White PRO-N132-W LM50.1.517 Powergear T1/2/3 I-Connector White PRO-N133-W LM50.1.518 Powergear T1 L-90°-Connector White PRO-N135-W LM50.1.520 Powergear Afdekking 200cm for 48V T1 White PRO-CSN20-W LM50.1.521 Powergear Ceiling Clamp Spacer WHITE PRO-N1SK-W BLACK Type/Model T1 LM50.3.511 Powergear Live end connector LEFT Black PRO-N131L-B LM50.3.512 Powergear Live end connector RIGHT Black PRO-N131R-B LM50.3.514 Powergear T1 Hoek 90° Black FL PRO-N135FL-B LM50.3.515 Powergear T1 Hoek 90° Black FR PRO-N135FR-B LM50.3.516 Powergear T1 Endcap Black PRO-N132-B LM50.3.517 Powergear T1/2/3 I-Connector Black PRO-N133-B LM50.3.518 Powergear T1 L-90°-Connector Black PRO-N135-B LM50.3.520 Powergear Afdekking 200cm for 48V T1 Black PRO-CSN20-B LM50.3.521 Powergear Ceiling Clamp Spacer Black PRO-N1SK-B
LOW VOLTAGE 48V TRACKLIGHTING 65 Endcap ET1 OPBOUW MINI Endcap ET2 OPBOUW HOOG Endcap ET3 INBOUW Endcap ET4 OPBOUW STANDAARD Connector PTX OPBOUW Connector ITX INNER Connector LTX Flexi INNER Afdekking CT2 OPBOUW AFDEKKINGEN & CONNECTOREN 48V MAGNETIC LIGHTING SYSTEM WIT ZWART HW451114 HW451414 Power Feed PTX (all tracks) HW451115 HW451415 Straight Connector ITX (all tracks) HW451116 HW451416 Flexible Connector LTX (all tracks) HW451117 HW451417 Aluminium connector CT2 (tracks type T2, T3, T4) HW451118 HW451418 Suspension pendant kit PT2 WIT ZWART HW451109 HW451409 Endcap T1 for mini track HW451110 HW451410 Endcap T2 for standard track HW451111 HW451411 Endcap T3 for high surface mounted track HW451112 HW451412 Endcap T4 for high recessed mounted track Ophangkabel PT2 HOOG & UP-DOWN Afdekking DS1000/2000/3000 OPBOUW WIT ZWART HW440220 HW441220 Dust Cover 1.0m HW440221 HW441221 Dust Cover 2.0m HW440222 HW441222 Dust Cover 3.0m
LOW VOLTAGE 48V TRACKLIGHTING 66 MAGNETIC TRACKS POWER SUPPLY LEDVOEDINGEN 48V MAGNETIC LIGHTING SYSTEM LED Voedingen 48 VDC OPBOUW Artikelnr. Type/Model LM60.3.601 100W Power Supply (inside track all models) LM60.3.602 100W Power Supply (inside track T2, T3) LM60.3.603 250W Power Supply (inside track T2, T3) LM60.3.604 150W Power Supply (outside track all models) LM60.3.605 250W Power Supply (outside track all models) LEDVOEDINGEN mogelijkheden afhankelijk van de installatie: - Voeding 48 Volt in de electriciteitskast, met ‘losse’ transfo - Voeding 48 Volt in de electriciteitskast, met transfo op DIN RAIL - Voeding 48 Volt in het aluminium profiel: deze voeding ligt gelijk met het profiel en past dus mooi in het 48V-profiel (dit geldt voor het lage profiel T1 en het standaardprofiel T4 - Voeding 48 Volt in het aluminium profiel: deze voeding ligt verborgen in het hogere profiel en wordt aldus perfect verborgen in het 48V-profiel. Hierdoor kan men aansluiten op het electriciteitspunt 230V (dit geldt voor het lage profiel T1 en het standaardprofiel T4 NDR-120-48 DIN RAIL MEANWELL NDR-240-48 DIN RAIL MEANWELL VOEDING OP DIN RAIL EXTERNE VOEDING SS60-48VL non dim SS150-48VL non dim SS200-48VL-1 non dim Art. Type/Model OUTSIDE TRACK LM60.1.610 Snappy 60W Transfo 48V (outside track all models) SS60-48VL LM60.1.613 Snappy 150W Transfo 48V (outside track all models) SS150-48VL LM60.1.617 Snappy 200W Transfo 48V (outside track all models) SNP200-48VL-1
LOW VOLTAGE 48V TRACKLIGHTING 67 POWER SUPPLY / VOEDINGEN 48V MAGNETIC LIGHTING SYSTEM
LOW VOLTAGE 48V TRACKLIGHTING 68
LOW VOLTAGE 48V TRACKLIGHTING 69 48V MAGNETIC Controlling & Dimming
LOW VOLTAGE 48V TRACKLIGHTING 70 DALI Controlling & Dimming CONTROLLING & DIMMING 48V MAGNETIC LIGHTING SYSTEM DALI Artikel-nr Features HY9D101A DALI Dimmer+Bus Power Built-in 100mA DALI bus power. Tunable White+ Dimbaar Dimming - built-in 100mA DALI bus power under AC mains. - on/off, Dimbaar dimmable and tunable white control. - standard size design. - can be powered by DALI bus while not connected with AC mains. DALI Dimmer TW + Bus Power Artikel-nr Features HY9D102A DALI Keypad A Tunable White+ Dimbaar Dimming - 8 keys, power supplied by DALI bus. - on/off, Dimbaar dimmable and tunable white control. - can set 2 scenes, standard size, easy DALI Keypad Type A Tunable White Artikel-nr Features HY9D103A DALI Keypad B Tunable White+ Dimbaar Dimming - 8 keys, power supplied by DALI bus. - on/off, Dimbaar dimmable and tunable white control. - can set 2 scenes, standard size, easy installation. DALI Keypad Tunable White TUNABLE WHITE (2700k-5700k) TUNABLE WHITE (2700k-5700k) TUNABLE WHITE (2700k-5700k)
LOW VOLTAGE 48V TRACKLIGHTING 71 Artikel-nr Features HY9D101B DALI Keypad A Dimbaar Dimming Only - built-in 100mA DALI bus power under AC mains. - on/off, Dimbaar dimmable only - can be powered by DALI bus while not connected with AC mains. DALI Dimmer + Bus Power Artikel-nr Features HY9D102B DALI Keypad A Only Dimbaar Dimming - 8 keys, power supplied by DALI bus. - on/off, Dimbaar dimmable only. - can set 4 scenes, standard size, easy installation. DALI Keypad Type A Dimbaar Artikel-nr Features HY9D103A DALI+ Push AC Phase Cut Dimmer 200W - 8 keys, power supplied by DALI bus. - on/off, Dimbaar dimmable only. - can set 4 scenes, standard size, easy installation. DALI Keypad Dimbaar DIMMING Dimbaar DIMMING Dimbaar DIMMING
LOW VOLTAGE 48V TRACKLIGHTING 72 DALI Controlling & Dimming CONTROLLING & DIMMING 48V MAGNETIC LIGHTING SYSTEM DALI Artikel-nr Features HY9D110A 4 Group DT8 DALI CCT Dual Color Touch Controller 4 Group DT8 DALI CCT Dual Colour Touch Controller - Built-in 100mA DALI bus power under AC mains - Powered by DALI bus while not connected to AC mains. - DALI consumption 4 mA DALI 4 Group DT8 CCT Dual Colour Artikel-nr Features HY9D110B 4 Group DT6 DALI DIM Single Color Touch Controller 4 Group DT6 DALI DIM Single Color Touch Controller - Built-in 100mA DALI bus power under AC mains - Powered by DALI bus while not connected to AC mains. - DALI consumption 4 mA DALI 4 Group DT6 Single Colour TUNABLE WHITE (WW/CW) Dimbaar DIMMING DALI
LOW VOLTAGE 48V TRACKLIGHTING 73 Artikel-nr Features HY9D105 DALI Bus Power Supply - max. output current 250mA for DALI bus. - DIN RAIL installation. DALI Bus Power Supply Artikel-nr Features HY9D106 DALI Phase Dimmer DIN RAIL - AC-AC, 4 channels output, Triac dimmable and mosfet dimmable, Forward-phase and reverse-phase, Minimum Dimbaar setting, DIN RAIL installation. DALI Bus Power Supply Artikel-nr Features HY9D108 DALI Relay Module+ DALI to 0/1-10V Converter - Powered by DALI bus, Capacitive/Resistive loads, DALI bus consumption: 3mA - Max. load AC200-240V LED 300W / incandescent and halogen 1000W. - Output 0/1-10V current 10mA for 0/1-10V LED driver 1mA/piece, Max capacity 10pcs. DALI Relay Module 0/1-10V Converter Artikel-nr Features HY9D109 DALI+ Push AC Phase Cut Dimmer 200W DALI+Push AC Phase Cut Dimmer 200W - AC100-240VAC, DALI consumption 2 mA - Compatible Load Types Triac Dimmable LED lamps 220-240V 200W DALI Push AC Phase Cut Dimmer Artikel-nr Features HY9D111 Mini DALI Power Supply 100mA Mini DALI Power Supply 100mA - AC100-240VAC, Mini DALI power supply, max. 100mA output - Match all DALI system in the market - Mini size, easy installation into existing wall boxes DALI Mini Power Supply 100mA
LOW VOLTAGE 48V TRACKLIGHTING 74 DALI Controlling & Dimming CONTROLLING & DIMMING 48V MAGNETIC LIGHTING SYSTEM DALI
LOW VOLTAGE 48V TRACKLIGHTING 75 BASIC PARAMETERS of DALI PROTOCOL DALI Signal Voltage High Voltage: 9.5-22.5V Low Voltage: -6.5 - +6.5V System Current Max. 250mA Data Transmission Speed 1200 bps Maximum Cable Length 300m, related to wire diameter Cable Type 1.5mm², related to wire diameter Maximum number of address / devices per single system 64 Maximum number of lighting scenes per single system 16 Maximum number of groups per single system 16
LOW VOLTAGE 48V TRACKLIGHTING 76 DALI Controlling & Dimming CONTROLLING & DIMMING 48V MAGNETIC LIGHTING SYSTEM DALI
LOW VOLTAGE 48V TRACKLIGHTING 77
LOW VOLTAGE 48V TRACKLIGHTING 78 RF2.4Ghz Controlling & Dimming CONTROLLING & DIMMING 48V MAGNETIC LIGHTING SYSTEM RF 2.4GHz Artikel-nr Afstandsbediening RF Tunable White 1-ZONE HY9J101 Control: 1 Zone Tunable White + Dimbaar Dimming, 0.1%~100% smooth dimming Working voltage: 3VDC by CR2032 battery Connection: RF 2.4G Wireless, 30m remote distance from controller to LED light. No limit to the number of lights. RF 2.4G Single Zone TW/Dimbaar TUNABLE WHITE (WW/CW) Artikel-nr Multi-Channel REMOTE / Afstandsbediening HY9J104 Control: 8 Zone Dimbaar Dimming Tunable White RGB RGBW RGB+CCT RF LED Working voltage: 3VDC by 2 pcs AAA battery Connection: RF 2.4G Wireless 30m remote distance from controller to LED light No limit to the number of lights. RF 2.4G EIGHT-Zone TW/Dimbaar RF Technologie: veelzijdig en bedrijfszeker • Duurzaam en betrouwbare oplossing voor slimme ledverlichting. • Uitstekende verhouding prijs / dimmingstechniek. • Max. controlling afstand 30m RF technologie wordt toegepast bij applicaties die signalen in de radioband produceren of gebruiken binnen een frequentie bereik van ongeveer 20 kHz tot 300 GHz. Hierbinnen vallen ook veel bekende toepassingen van radiogolven zoals mobiele telefoons, wifi of radio.
LOW VOLTAGE 48V TRACKLIGHTING 79 Artikel-nr Tunable White - Wandpaneel 4-ZONES Opbouw LM70.9.224 Batterijen Control: 4 Zones Dimbaar Dimming 0.1%~100% smooth dimming Connection: RF 2.4G Wireless 30m remote distance from controller to LED light No limit to the number of lights. Codes HY9J102-1 batteries RF2.4Ghz Panel CCT / Dimbaar dimming RF2.4Ghz Panel Dimbaar dimming Single Colour Artikel-nr Single Colour - Wandpaneel 4-ZONES Opbouw LM70.9.222 Batterijen Control: 4 Zones Dimbaar Dimming 0.1%~100% smooth dimming Connection: RF 2.4G Wireless 30m remote distance from controller to LED light No limit to the number of lights. Codes HY9J102-3 batteries Wandpanelen / Wall Panels RF2.4Ghz
LOW VOLTAGE 48V TRACKLIGHTING 80 RF2.4Ghz Controlling & Dimming CONTROLLING & DIMMING 48V MAGNETIC LIGHTING SYSTEM RF 2.4GHz Artikel-nr Description Dimbaar DIMMING HY9J103-4 1-ZONE Dimbaar Dimming, 0.1%~100% smooth dimming HY9J103-2 4-ZONE Dimbaar Dimming, 0.1%~100% smooth dimming HY9J103-5 8-ZONE Dimbaar Dimming, 0.1%~100% smooth dimming 1-ZONE 4-ZONE 8-ZONE Protocol: RF 2.4G Wireless 30m remote distance from controller to LED light Aansluiting van aantal spots: onbeperkt. Single Colour
